Image preview - the first page of the document
DAEWOO_DWD-FD1451_1452_1453_1454_1455


>> Download DAEWOO_DWD-FD1451_1452_1453_1454_1455 documenatation <<

Text preview - extract from the document
 DWD-FD145X SERIES
                                               HOT
                                           (OPTION)              COLD



                       INLET HOSE




      DETERGENT CASE

                                                                                   POWER CORD




                                                                                  CONTROL PANEL


          DOOR
                                                                                 HOSE DRAIN




                                                                        ADJUSTABLE LEG
                           LOWER COVER




              MODEL                                   DWD-FD1451/1452/1453/1454/1455
 POWER SOURCE                                                220-240V/50-60Hz
 DiMENSION (WXDXH)                                       595mm x 540mm x 850mm
 WEIGHT                                                             58 kg
 WATER CONSUMPTION                                                 56.1
 POWER CONSUMPTION                                                 2200W
 MAXIMUM MASS              WASH                                     7 kg
 OF TEXTILE                SPIN                                     7 kg
 WASHER TYPE                               DRUM TYPE (FRONT LOADING WASHING MACHINE)
 OPERATING WATER PRESSURE                               0.3 ~ 8kgf/cm2 (29.4 ~ 784kPa)




 Accessories
     Hose drain               Inlet hose                  Manual                 Cap holder(3EA)




                                                                                          SPECIFICATIONS   5
    2. INSTALLATION

     Transit bolts
       The appliance is fitted with transit bolts to prevent internal damage during transport.


     Removing transit bolts
       1. To prevent internal damage during transport, the          2. Unscrew the 3 bolts with the 10mm hex wrench
          special 3 bolts are locked. Before operating the             or spanner or cross-tip screwdriver.
          washer, remove the bolts along with the rubber               Keep the 3 bolts for a later time.
          bungs.
