Image preview - the first page of the document
>> Download 3800 documenatation <<
Text preview - extract from the document
Contents: Dell Inspiron 3800 System Reference
DellTM InspironTM 3800 System Reference
Conventions
Technical Overview
Using the Computer
Utilities and Drivers for Microsoft Windows 98
Utilities and Drivers for Microsoft Windows NT
Utilities and Drivers for Microsoft Windows 2000
Technical Specifications
System Setup Program
System Error Messages
Passwords and Security
Ports and Connectors
Power Sources
Power Conservation
Removing and Replacing Parts
Pentium are registered trademarks, and Celeron and SpeedStep are trademarks of Intel Corporation; Adobe is a trademark of
Adobe Systems Incorporated, which may be registered in certain jurisdictions.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names
or their products. Dell Computer Corporation disclaims any proprietary interest in trademarks and trade names other than its
own.
file:///F|/Service%20Manuals/Dell/Inspiron/3800/index.htm (1 of 2) [2/28/2004 6:58:30 AM]
Conventions: Dell Inspiron 3800 System Reference
Back to Contents Page
Conventions: DellTM InspironTM 3800 System
Reference
Notes, Notices, and Cautions
Typographical Conventions
Notes, Notices, and Cautions
Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type
or in italic type. These blocks are notes, notices, and cautions, and they are used as follows:
NOTE: A NOTE indicates important information that helps you make better
use of your computer system.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and
tells you how to avoid the problem.
CAUTION: A CAUTION indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate injury.
Typographical Conventions
The following list defines (where appropriate) and illustrates typographical conventions used as
visual cues for specific elements of text throughout this document:
q Interface components are window titles, button and icon names, menu names and
selections, and other options that appear on the monitor screen or display. They are
presented in bold.
Example: Click OK.
file:///F|/Service%20Manuals/Dell/Inspiron/3800/convent.htm (1 of 2) [2/28/2004 6:58:46 AM]
Conventions: Dell Inspiron 3800 System Reference
q Keycaps are labels that appear on the keys on a keyboard. They are enclosed in angle
brackets.
Example:
q Key combinations are series of keys to be pressed simultaneously (unless otherwise
indicated) to perform a single function.
Example:
q Commands presented in lowercase bold are for reference purposes only and are not
intended to be typed when referenced.
Example: "Use the format command to . . . ."
In contrast, commands presented in the Courier New font are part of an instruction
and intended to be typed.
Example: "Type format a: to format the diskette in drive A."
q Filenames and directory names are presented in lowercase bold.
Examples: autoexec.bat and c:\windows
q Screen text is a message or text that you are instructed to type as part of a command
(referred to as a command line). Screen text is presented in the Courier New font.
Example: The following message appears on your screen:
No boot device available
Example: "Type md c:\programs and press ."
q Variables are placeholders for which you substitute a value. They are presented in italics.
Example: DIMM_x (where x represents the DIMM socket designation)
Back to Contents Page
file:///F|/Service%20Manuals/Dell/Inspiron/3800/convent.htm (2 of 2) [2/28/2004 6:58:46 AM]
Technical Overview: Dell Inspiron 3800 System Reference
Back to Contents Page
Technical Overview: DellTM InspironTM 3800 System Reference
System Features IRQ Line Assignments
Video Memory
System Features
This section describes the major hardware and software features of your computer. Figure 1 and Figure 2 show the front and back view of
the computer, respectively.
Figure 1. Front View of the Computer
1 Display latch 9 DualPointTM buttons
2 Air intake 10 Battery bay
3 Modem connector 11 Touch pad
4 TV-out S-video connector 12 Keyboard
5 Audio connectors (3) 13 Track stick
6 Integrated microphone 14 Power button
7 Speaker 15 Keyboard status indicators
8 Media bay 16 Display
Figure 2. Back View of the Computer
file:///F|/Service%20Manuals/Dell/Inspiron/3800/overview.htm (1 of 10) [2/28/2004 6:58:48 AM]
Technical Overview: Dell Inspiron 3800 System Reference
1 Speaker 9 PS/2 connector
2 Security cable slot 10 USB connector
3 Hard-disk drive 11 Docking connector
4 PC Card slot 12 Device access/status indicators
5 Security cable slot 13 Parallel port connector
6 Infrared port 14 Video connector
7 AC adapter connector 15 Fan exhaust
8 Serial port connector
Hardware Features
