                    Embest STDV750F Evaluation Board
- Evaluation Board for STMicroelectronic's STR750FV2T6 ARM7TDMI-S Microcontroller
(STR750 series)
- RS232, USB device, CAN, LCD, Audio, I2C, Jtag, uCos, ...
- Plenty of software examples, all in source code




                                   Embest STDV750F Evaluation Board

Description
The STR750FV2T6 is among STR750F family, which is a new series of super-integrated, single-chip 32-bit
ARM7-based MCUs from STMicroelectronics. Based on an ARM7TDMI-S core, the device has embedded
256KB of Flash plus an additional 16K bank of Read-While-Write Flash for EEPROM emulation. It can be
used with either a 3.3V or a 5V power supply and is able to offer high performance with 54MIPS at 60MHz and
low power consumption down to 10
