Gaggia_CLASSIC_Parts_Diagram


>> Download Gaggia_CLASSIC_Parts_Diagram documenatation <<

Text preview - extract from the document
                                                                                                           1
                                                                                                           3
                                                                  2




                                                              6
                                                              7
                        63                                                           4
                                                              8                          5
                                                  14
                                                  15
                        64                  17    16                       12
                                             6                             13
                                                                                   10
                                                                                 9   11
                                       41
                       65                                                       26 27 28
                                                                                                               41 49
                                                 42 32
                        66
                                                                                             32 33 34
                                                    19
                                                                      29
                  70                                20
                             43
                             44
                              1                                                 30   31                             54
                             46
                             47                     21
                                                    22                          36
                                  35
                                                    23
                                                    24                                           35
                                       67
                                                    25
                                       71 37
                                       72 38
                                       69 39
                                                                                                      61
73                                     68 40

                                                                                                           62

             45
                       48
     18 50                                                                                            52

                                                                                                               51
                                                                                                      53
                                   56 55


58
59
60




                                                         57
ER0182                                                                 CLASSIC, CLASSIC COFFEE GAG
Pos   Article-Nr.     Description                                Pos   Article-Nr.   Description
1     DI7981-         SCREW TCB 3,5X9,5 DIN 7981 C NICK          50    WGADM1319     GALV.SPECIAL SCREW M6X16
      3.5X9.5N
2     CF0113          LID                                        51    CC5070/A/IL   CLASSIC BODY W. POLISHED ST. STEEL
3     CF0115          FUNNEL                                     51    CC5070/A/IS   CLASSIC BODY W. SATIN-FINISH ST. ST
4     CF0108/01       TOP COVER W/O HOLES                        51    CC5071/A/IS   CLASSIC UL BODY W. SATIN-FINISH ST.
5     DI7981P2.9X6.   STAIN STEEL 2,9X6,5THREAD SCRE             52    CC5074        BLENDE CLASSIC GAGGIA
      5I
6     UN5931-6X16Z    GALV.SCREW M 6X16                          53    CC5021        BLACK RUBBER FOOT
7     11012628        TEA/BRASS FAUCET ASSY.                     54    227431350     BLACK/BLACK PANNARELLO G100 ASSY.
8     DM0041/081      O-RING 112 IN EPDM 70
