Image preview - the first page of the document
HAIER+HL47E+lcd


>> Download HAIER+HL47E+lcd documenatation <<

Text preview - extract from the document
HL47E




        TV-8888-119
    1. Features-------------------------------------------------3

    2. Safety Precautions----------------------------------5

    3. Images of Module and Circuit Boards--------7

    4. Key IC Description& Trouble Shooting Guide
                                  -----------------------10
    5.Signal Flowing Chart-------------------------------14
    6. Bus Control Adjustment-------------------------15

    7. Circuit Diagram ------------------------------------30

    8. Connection Sketch Interpretat----------------49




-
          Features
                   Factory model(reference only)                     L47A18
                   HAC model                                         HL47E
       Options     Functions
                   Screen size (inches)                                   47
       General     Display type                                          LCD
                   Aspect ratio                                          16:9
                   Resolution                                        1920*1080
                   Brightness                                         550 cm/2
                   Contrast                                             800:1
                   Response time(ms)                                     8ms
        Video      Display Capabilities                     480i/480P/720P/1080i/1080P
                   Viewing Angle                                    H:178/V:178
                   Color display                                     16.7million
                   Active Matrix TFT                                     yes
                   PC mode (VGA, SVGA, XVGA)                   SXGA\XGA\SVGA\VGA
                   Tuner                                      Integrated NTSC&ATSC
                   HD-ready                                              yes
                   Video Signal System                     NTSC/ATSC(8VSB,Clear QAM)
                   Color Temperature                            Standard,Cool,Warm
                   Progressive Scan                                      yes
                   Digital Comb Filter                                    3D
                   Video Noise Reduction                                 yes
    Video Features Picture Modes                             standard,vivid,mild,custom
                   # of preset channels                                  181
                   Screen Mode (4:3)                                     yes
                   Wide Mode (16:9)                                      yes
                   Wide Mode (PC)                                        yes
                   Auto adjustment (PC)                                  yes
                   Phase (PC) Only                                       yes
                   H\V edge correction                                   yes
                   Number Of Speakers                                      2
                   Speakers Type                                  Separate(bottom)
        Audio      Speaker Size                                     2 3/4" (4 pcs)
                   Watts Per Channel                                    10W
                   Audio Power Output                                  10W*2
                   Stereo Surround Sound                                 yes
                   MTS Stereo                                            yes
                   Sound Mode                               Live POP Rock Custom
    Audio Features
                   Tone Control                                          yes
                   Speakers ON/OFF                                       N/A
                   Mute                                                  yes
     Convenience Semi transparent Menu                                   yes
       Features    Zoom                                                  yes
                   V-Chip                                                yes
                   Close Caption (Basic,Digital,Advance)                 yes
                   Teletext                                              N/A


-
                   Multilingual Display                                   E/F/S
                   Auto Channel Programming                                yes
                   Channel Caption                                         yes
                   Channel Label                                           yes
                   Channel Skip/Add                                        yes
                   Favorite Channel                                        yes
                   Program Guide Access(TV guide)                          N/A
                   Clock                                                   yes
                   Programmable Timer                                      yes
                   Sleep Timer                                             yes
                   Alarm (Auto timer on/off)                               yes
                   Picture-In-Picture                                      N/A
                   Freeze Picture                                          yes
                   Remote Control                                HTR-282E (Universal)
                   ATSC/NTSC Tuner                                          1
                   HDMI Input                                               2
                   Component Video Input                                    2
                   Composite Video Input                                    2
                   S-Video Input                                            1
                   RF Input                                                 1
    Input \ Output PC Input                                                 1
                   USB Port                                                 2
                   Analog Audio Input                 2 for component, 2 for composite and S-video
                   PC Audio Input                              1 (VGA and HDMI-to-DVI)
                   Audio Out (Fixed/Variable)                          1(optical)
                   Headphone jack                                           1
                   AV Output                                                1
     Compliance Vesa                                                 yes(400*200)
                   Internal power Supply                                   yes
                   Power Consumption (in Operation)                       300W
        Power      Power Consumption (in Standby)                           1W
                   Power Voltage                                          120V
                   Power Frequency                                        60Hz
                   Panel Supplier                                          LG
     Information
                   Chipset                                             BCM3551




-
Safety Precautions
    -




-
                                        -




      Images of Module and Circuit Boards
a: Signal flow-chart
                              -




b. Printed Circuit IC Board
1) head-on board
                  -




2) rear   board
                                      -




    Key IC Description& Trouble Shooting Guide
1. Key IC Description
1   BCM3551
              -




2   MSP3460
           -




3)AD9880
                            -




2. Trouble Shooting Guide
                       -




Signal Flowing Chart
                                                         -




     Bus Control Adjustment
1 Factory Mode
Using the romote controller to enter into Factory Menu.
   Press Menu to call main menu displaying on the screen. And then press "8"," 8","9","3","OK" in turn.You will see
the screen displaying as following.You can check the version of the software,adjust some settings.But we don't
advise you change this settings.because of the TV has already hold in the state of optimality.If you have to chang
this settings,please connect with the local service center.

   1. Factory menu
                                                     -




2.Image Version, Atmega Version
   Image Version: This is the current software version.
   Atmega Version: The serial number, it is recorded for this board.
                                                    -




3.OK MENU EXIT
  OK: press OK to submenu
  MENU: return to upper menu
  EXIT: Press "EXIT" of the romote controller to exit from factory menu
                                                     -




    4. Operate in Factory Menu
    There are 5 items in the root Product Mode, Aging Mode, Shop End, Service Mode, Design Mode.
    1) Product Mode includes 3 items, White Balance Setting, Back Light Set to Factory Default Value.Do not
change the value commonly.
                                                     -




2)Aging Mode   This is for factory run-in testing.
                                                -




3) Shop End is for debuging, and do not change anything commonly.
                                                -




4)Service Mode is for debugging, and do not change anything commonly.
                                                  -




5) Design Mode includes 4 items, Video Setting, Audio Setting, Screen Setting, Others
                                                     -




     a. Video Setting includes 4 items, Threshold, Picture Mode, ADC Auto Adjust, Gray Step.
     Threshold allows you to change the adjustable range of brightness, contrast, chroma, hue and sharpness.
Picture Mode allows you to change the state of picture mode, such as Vivid mode, Standard mode and Mild mode.
ADC Auto Adjust and Gray Step are for debugging, and do not change anything.
                                                   -




    b. Audio Setting includes 4 items, Sound Effect, Sound Mode, Sound Curve, Headphone Sound curve. All
these items are for debugging,and do not change anything commonly.
                                                    -




   c. Screen Setting allows you to change V-SIZE, V-POSITION, H-SIZE, H-POSITION of the screen displaying.
Normally you need not to change anything.
                                                        -




     d. Others including 2 items, Audio Output and Set E2prom to default. Audio Output allows you to change the
volume of Audio Output. Set E2prom to default will Clear all changing you have made to the TV set's software
setting, such as Channel list you have tuned, volume, brightness, and etc. and initialize TV set's software to the
state like a new TV set buyed right now.




Remark:
The date of the chart only is a example,please don't adjust the factory mode base on it.
             -




2   Others
Connection Options
 Left side connetions




                    Antenna Input
                    Connect cable or antenna
                    signals to the TV, either




                                                     ANT IN
                    directly or through your
                    cable box.
                                                                     HDMI2




                                                      HDMI2
                                                                     connect a signal to
                                                                     HDMI/DVI.
                    PC VIDEO Input
                    Connect the monitor




                                                       PC
                    output connector from
                    a PC to the jack



                                                   1 Y
                                                   2
                                                                     DVD/DTV Input
                                                   COMPONENT
                                                   Pb
                                                                      (Component )
                                                                     Connect a component
                                                       Pr


                                                                     video device to these
                                                                     jacks.
                                                   R       L




                    S-Video Input
                                                      S-VIDEO




                    Connect S-Video out from
                    an S-VIDEO device to the
                    S-VIDEO input.
                                                     VIDEO1 L




                                                                     VIDEO Input
                                                                     Connects the
                                                                      video signal
                                                                      from a video
                                                     R




                                                                           device.



                    HDMI1
                                                      HDMI1




                    connect a signal to
                    HDMI/DVI.

                                                                     Earphone jack:
                                                                     Earphone audio
                    DVI/PC Audio Input                               output terminal.
                                                  AUDIO IN
                                                  PC/DVI




                    Connect the audio out from
                    the external device, used                        Power Cord Socket
                    while using a DVI to HDMI                        This TV operates on AC
                                                           OPTICAL




                    connector.                                       power.
                                                                     The voltage is indicated on
                                                                     the Specifications page.
                                                                     Never attempt to operate
                                                                     the TV on DC power
                    Power Cord Socket
                    This TV operates on AC
                                                      AC IN




                    power.
                    The voltage is indicated on
                    the Specifications page.
                    Never attempt to operate
                    the TV on DC power
                                                                                                                                                    Introduction


 Remote Controller
- The remote controller cannot be operated unless the batteries are properly loaded.
- When using the remote control, aim it at the remote control sensor on the TV.

 Function introduction                                                                                       TV USB
                                                                                                             Press the SELECT button repeatedly to select one of the
                                                                                                             system modes in which the remote control can be used.
                                                                                                             When the desired device is selected, the corresponding
                                    POWER                                                                    LED lights on 5seconds.
 Turns your TV or any other programmed
equipment on or off, depending on mode.                                                                      FAVORITE
                                                                                                             Open the favorite channel list.
                                                                                                             AUDIO.LIST
                                 CH.LIST                                                                     Open the audio channellist.
                                                           TV   M OD E                 MO D E
                     Open the channel list.                                                                  ZOOM( only SUB System)
                                                   C H LI S T    F AV . LI S T   A U D I O LI S T
                                                                                                             To enlarge or lessen the picture
                                         USB                                                                 HOTKEY ( only SUB System)
                                                                                                    HOTKEY
                    Press to enter USB signal         TV                             ZOOM
                                                                                                             .
                                                                                                             Call up the menu
                                                                                                                   /   Rewind / Fast
                                                                                                                   /   backward /Forward
                                           TV                                                                          Play
                      Press to enter TV signal                                                      RETURN
                                                                                                              II       Pause
                                                                                                             RETURN

                                                                                                             S.MODE
                                    P.MODE                                                                   Selects the sound appropriate for the program's
              Selects the picture appropriate                                                                character.
                for the program`s character.
                                                                       E                                     FREEZE
                                                                   TI M E
                                                                   TI M                                      Freezes the currently-viewed picture, but audio continues.
                  CC(closed caption)                                                                         Press FREEZE button again to resume the normal picture.
                    Select a closed caption:
                 CC MUTE, CC ON, CC OFF.                                                                     INPUT
                                                                                                             show the input source mode.
                                    TIME
                               Shows time.                                                                   INFO
                                                                                                             When you watch the TV, press the key, the information
                                                                                                             displays on bottom of the screen.
                                     MENU
Brings up the main menu to the screen.
                                                                                                             THUMBSTICK
                                       EXIT                                                                  (Up/Down/Left/Right/OK)
                                                                                                             Allows you to navigate the on-screen menus and adjust
     Clears all on-screen displays and
                                                                                                             the system settings to your preference.
  returns toTV viewing from any menu.
                                                                                                             SLEEP button
                                                                                                             Displays the Sleep Timer option.
                                      MUTE
            Switches the sound on or off
                                                                                                             LIGHT
                                                                                                             Press the light button, white LED will be ON, release
                               ARC                                                                           this key, white LED will be OFF.
              (Aspect Ratio Control)
               Changes the aspect ratio.                                                                     SAP
                                                                                                             Selects MTS sound: Mono, Stereo, and SAP in Analog
                                                                                                             mode. Change the audio language in DTV mode.


                   VOLUME UP/DOWN
  Increases/decreases the sound level.                                                                       CHANNEL UP/DOWN
                                                                                                             Selects available channels
                    Numeric buttons
            press to change the channel.

                                   - button                                                                  Q.VIEW
          Press to select additional channels
                           (digital and analog)                                                              Switch the current channel to the last channel
        being broadcast by the same station.                                                                 you have viewed.
               For example, to select channel
     "54-3", press "54", then press "-" and "3".



   Note: For DVD function see page 35.



8 TV LCD-TFT
                                -




 Circuit Diagram

1. BCM signal   flowing chart

2. Circuit Diagram
                                              5                                          4                                                        3                                                                 2                                                                               1




                                                                                                         BCM3560B0 Digital High Definition, LCD_TV
                                                                                                                                                                           DDR-SDRAM                 DDR-SDRAM                                                                     MAIN
                                                              Ethernet                                                                                                     16Mx16                    16Mx16
                                                                                                               BCM4401
                                                              DTE Device
D                                                 Headphone                                                                                                                                                                                                                                                                         D
                                                  Amp
                                                  RC4580ID                                                                                                                             32-bit DDR-SDRAM
                                                                                                               Flash                                   EBI/PCI
                                                                                                               8Mx16



                                                   D-AMP                                                               RF Cable/ Antenna

                                                  TPA3004D2
                                                                                                                          DTT7608                          VSB / QAM / NTSC-BTSC
                                                                                                                         ATSC/NTSC Tuner                   IF Demodulators

                                                                                                                                                                                                                 CVBS OUT
                                                                                                                                                       SD_L
    S-Video 1:                      Luma-Chroma
                                                                                                                                    CVBS1/Luma1
                                                                                                                                                       SD_C                        BCM3560B0
    Video1,                         CVBS                                                                                                               ES_CVBS0
    Stereo Audio                    Audio
                                                                                                                                                       ES_CVBS1
                                    L-R
                                                                                                                                                       SD_CVBS


    Video 2:                        CVBS

C
    Composite,                      Audio                                                                                                                                                                                                                                                                                           C
                                    L, R
    Stereo Audio

                                                                                              Audio
                                                                                             Processor
                         PC Audio
                                                                                             MSP3460G
                          L-R


                                                                                                                                                                                                                                                                             USB
                                                                CD4052                                                                                 I2S Out

                                                                                                                                                                                                                  EJTAG
                                                                                                                                                       Audio L-R                                                                                  Vision Probe
                                    Y

                                    Pb                                                                                                                                             TV on a Chip                   Test BSC                        Broadband
                                                                                                                                                                                                                                                    Studio
    HD Component1,                  Pr                                                                                                                 BSC
    Stereo Audio                                                                                                                                       Masters
                                    Audio                                                                                                              (control)
                                    L-R


                                    Y                                                                                                                  Y
    HD Component2,                  Pb
    Stereo Audio                                                                                                                                       Pb
                                    Pr

                                                                                                                                                       Pr
                                    Audio
                                    L-R
                                                                                                                                                                                                                                                                           Flat Panel Display
B                                                                                                                                                                                                                                                                                                                                   B



                                                                                                                                                                                                                                     LVDS Tx                     LVDS
    Main Out:                                                                                                                                          SPDIF Out                                                  HD_DVO
    Digital Audio                                                                                                                                                                                                              DS90C385MTD
                                                                                                                                                                                                                        RGB
         HDMI1                                                                                                                                         HDMI In



         HDMI2                                                             ADC+HDMI_Rx                                                                 I2S In
                                                                            AD9880
                                                                                                                                                       Digital-in

               VGA
                                                                                                                                                                                                                              UART
                                                                                                                                                                                                                                               ATMEGA48V
                    Front Panel                                                                                                                                                                                                                 MCU
                    Keypad, LED,IR




                                                                                                                                                            5V-cpu
A                                                                                                                                                                                                                                                                                                                                   A

                                                                                                                                                                    12V

                                                                                                                                                                    1.2v
                                                   SMPS                                                        POWER
                                                                                                               NCP5422                                LDO
                                                   POWER                                                 12V                                                        2.6v

                                                                                                                                                                    5v                                                                                      Title
                                                                                                                                                      LDO
                                                                                                                                                                    3.3v
                                                                                                                       POWER                                                                                                                                Size
                                                                                                                                                                                                                                                               C
                                                                                                                                                                                                                                                                        Document Number
                                                                                                                                                                                                                                                                        <Doc>
                                                                                                                                                                                                                                                                                                                              Rev
                                                                                                                                                                                                                                                                                                                                <RevCode>

                                                                                                                                                                                                                                                            Date:          Tuesday, November 07, 2006   Sheet   1   of   18
                                              5                                          4                                                        3                                                                 2                                                                               1
                                          5                                                                                                                                                                                                                                                                                                         4                                                                                                                                    3                                                                                                    2                                                                                                                              1

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                           U22F
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                           BCM3551KPB5G
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                               BGA676_35X35
                                                         Use 75 ohm matched impedance traces.                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                  HD_DVI0                                    B23
                                                                                                                                                                                                                                                                                                                                                                                                R195                                                                                                                                                                                                                                           HD_DVI1                                    A23           HD_DVI[0]/VI_656_0
                                                                                                                                                                                                                                                                                                                                                                                              100   0.047uF                   C135                                   B_AVID_IN_AC                                                                                                                                                              HD_DVI2                                                  HD_DVI[1]/VI_656_1
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          D22
                                                                120OHM_100MHZ                                                                                                           FB101                                                                                                                                                                                                                                                                        Pb_AVID_IN_AC                                                                                                                                                             HD_DVI3                                                  HD_DVI[2]/VI_656_2
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          C22
                                                                                                                                                                                              R_AVID_IN                                                                                                                                                                                           R197                                                                                                                                                                                                                                         HD_DVI4                                    E23           HD_DVI[3]/VI_656_3
      (5)      R_AVID_IN_CON                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            HD_DVI[4]/VI_656_4
      (5)      G_AVID_IN_CON                                    120OHM_100MHZ                                                                                                           FB102 G_AVID_IN                                                                                                                                                                                         100                         C145                                     G_AVID_IN_AC                                                                                                                                                              HD_DVI5                                    A25
                                                                                                                                                                                              B_AVID_IN                                                                                                                                                                                                                   0.047uF                                    Y_AVID_IN_AC                                                                                                                                                              HD_DVI6                                                  HD_DVI[5]/VI_656_5
      (5)      B_AVID_IN_CON                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                              D23
                                                                120OHM_100MHZ                                                                                                           FB103                                                                                                                                                                                                   R200                                                                                                                                                                                                                                           HD_DVI7                                                  HD_DVI[6]/VI_656_6
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          B24
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                        HD_DVI[7]/VI_656_7




                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            Digital Video Input
                                                                                                                                                                                                                                                                                                                                                                                              100                           C147                                     R_AVID_IN_AC                                                                                                                                                              HD_DVI8                                    F22
                                                                                                                                                                                                                                                                                               R102       R116                               R140                                                                         0.047uF                                    Pr_AVID_IN_AC                                                                                                                                                             HD_DVI9                                                  HD_DVI[8]/VI_656_8
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          A24
                                                                                                                                                                                                                                                                                               75         75                                 75                                                                                                                                                                                                                                                                                                HD_DVI10                                                 HD_DVI[9]/VI_656_9
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          C23
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                        HD_DVI[10]/GPIO_62
                                                     Isolate the HSYNC input as much as possible                                                                                                                                                                                               5%         5%                                 5%
                                                                                                                                                                                                                                                                                                                                                                                                                                                                     VID_HSYNC0
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                               HD_DVI11                                   E22
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                        HD_DVI[11]/GPIO_63
D
                                                     from any other digital signals and minimize the                                                                                                                                                                                                                                                                                                                                                                 VID_VSYNC0                                                                                                                                                                HD_DVI_DE                                  C25                                                                                                   D
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                        HD_DVI_DE
                                                     trace length for the HSYNC input.                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                         HD_DVI_CLK_P
                                                                                                                                                                                                                                                                                           A                                                                                                                                                                                                                                                                                                                                                                                              C24
                                                     VID_HSYNC0                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                         HD_DVI_CLK_P/VI_656_CLK
             (5)       VID_HSYNC0                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                         D24
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                        HD_DVI_CLK_N




                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                               A
                                                     VID_VSYNC0                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                        R303    1K
             (5)       VID_VSYNC0
                                                                                                                                                                                                                                                                                                                                                                                                                   R163                                                                                                                                                                                                                        HD_DVI_HSYNC                               G22
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                        HD_DVI_HSYNC
                                                      Minimize the trace length running                                                                                                                                                                                                                                                                                                                        0                                            1000pF C143 G_AVID_SOGIN                                                                                                                                                           HD_DVI_VSYNC                               F23
                                                                                                                                                                                                                                                                                                                                                                                                                                            </pre><br><br>
<script async src="//pagead2.googlesyndication.com/pagead/js/adsbygoogle.js"></script>
<!-- ManualsDLHorizontal -->
<ins class="adsbygoogle"
     style="display:block"
     data-ad-client="ca-pub-2156279550025329"
     data-ad-slot="1406759947"
     data-ad-format="auto"
     data-full-width-responsive="true"></ins>
<script>
(adsbygoogle = window.adsbygoogle || []).push({});
</script>
<br>
<span style="font-size:11px;color:#777;">◦ Jabse Service Manual Search 2020 ◦ <a href="http://pravopis.jabse.com/">Jabse Pravopis</a>  ◦  Other service manual resources online : <a href="http://www.fixya.com/">Fixya</a> ◦ <a href="https://www.eserviceinfo.com/">eServiceinfo</a>
</span></div>
<br>
</body>
</html>
