Image preview - the first page of the document
haier_ld2010a_179


>> Download haier_ld2010a_179 documenatation <<

Text preview - extract from the document
SERVICE MANUAL
   FOR LD2010A




  TFT-LCD TV
   Haier Group
                                       Content
CONTENTS -----------------------------------------------------------------------------------------------1

Main Unit Description----------------------------------------------------------------------------------2

Features----------------------------------------------------------------------------------------------------4

Warning and Cautions---------------------------------------------------------------------------------6

Replacement of Memory IC--------------------------------------------------------------------------8

Net Dimension-------------------------------------------------------------------------------------------9

Remote Controller Functions----------------------------------------------------------------------10

ICs function description ----------------------------------------------------------------------------13

Block Diagram------------------------------------------------------------------------------------------21




Trouble Shooting---------------------------------------------------------------------------------------26
Front Panel Controls



                2    3       4                5       1




               TV/AV MENU VOL-   VOL+   CH-       CH+ POWER




                                                              6
                                                              7




Control Panel Function

1. Power supply switch
2.TV/AV    Selects the input signals: PC/COMPONENT/AV/SV/TV
3. MENU Press to select the main menu
4. VOL- Volume down / Left orientation to adjust the item in the OSD
   VOL+ Volume up / Right orientation to adjust the item/Press to enter

5. CH- TV channel down / to select the item in the menu
   CH+ TV channel up / to select the item in the menu
6. Power indicator
   Illuminates red in standby mode, illuminates green when the display is
   turned on
7.Remote Sensor        Receives the signals from the remote control
Connection Options
                                                                                    DVD
 ANT IN




                                                                                  STOP PLAY/PAUSE OPEN/CLOSE
 PC AUDIO IN

                R
 AUDIO IN




                                                                                           PREW      NEXT
                L
 VIDEO IN

                V
 S-VIDEO


                    Pr
 COMPONENT IN


                    Pb
                    Y




                                                                                            DVD insert
 VGA IN




                         The figure is just for reference, please see the real.




Antenna Input
Connect cable or
antenna signals to
                                                ANT IN




the TV, either direc-
tly or through your
cable box.                                                                         Earphone port
                                                PC AUDIO IN




PC Audio Input
Connect the PC output                                                              AV/S-VIDEO/
connector from a PC to                                                             COMPONENT Audio
the audio input port                                                               Input
                                                               R
                                                AUDIO IN




                                                                                   Connect audio output
                                                                                   from an external device
                                                               L




                                                                                   to these jacks
Video Input
                                                VIDEO IN

                                                               V




Connect video output
from an external
                                                S-VIDEO




                                                                                   S-Video Input
device to this jack
                                                                                   Connect S-Video out
                                                                                   from an S-Video device
                                                                                   to the jacks.
                                                                   Pr
                                                COMPONENT IN




                                                                                   DVD/DTV Input
                                                                   Pb




                                                                                   Connect a component
                                                                                   video/audiodevice to
VGA Input
                                                                   Y




                                                                                   these jacks
Connect to the VGA
15PIN analog output
connector of a PC
                                                VGA IN




display card to use set
as a PC display
Features
                                           Model
 NO.           Functions
                                        LD2010A
  1                 TFT                     AU
  2             Screen size                20inch
  3             Aspect ratio                16:9
  4             Resolution              1366
