Image preview - the first page of the document



>> Download 5988-0200EN documenatation <<

Text preview - extract from the document

Agilent
New Generation Analyzer
Offers Exceptional and Powerful
Analysis Functions for
RF Impedance Measurement
Product Note E4991A-1




              Agilent E4991A
              RF Impedance/Material Analyzer
    Introduction                        Features of the E4991A
    With the trend of wireless          Highly accurate RF
    communications and digital
    equipment operating at higher       impedance measurement
    frequencies, the need to evaluate   The E4991A uses the RF I-V
    RF components under higher          technique for highly accurate
    and wider frequencies is            impedance measurement in the
    increasingly important not only     RF frequency range. As figure 1
    for R&D engineers of component      shows, the E4991A achieves a
    manufacturers but also circuit      wider and accurate impedance
    designers of equipment              measurement up to 3 GHz. The
    manufacturers. The E4991A RF        RF I-V technique is different
    Impedance/Material Analyzer         from the reflection coefficient
    offers 3 GHz measurement            method used by a network
    frequency range that covers hot     analyzer. This technique
    applications such as W-CDMA,        measures voltage and current
    BluetoothTM and wireless LAN.       directly at the DUT (Device
    The E4991A offers impedance         Under Test) thus the E4991A
    measurement capabilities for        can achieve higher and wider
    your needs today and into the       impedance measurement range
                                                                             Figure 1. Impedance measurement range
    future.                             when compared to a network
                                        analyzer.
    This product note describes the
                                        The E4991A can calibrate with
    following topics.
                                        the low-loss air capacitor
                                        standard in addition to the
