Image preview - the first page of the document
>> Download 5988-2923EN documenatation <<
Text preview - extract from the document
Agilent
Balanced Measurement Example:
Differential Amplifiers
Application Note 1373-7
Introduction
Agilent Technologies has developed a solution that
allows the most accurate method available for measuring
differential RF circuits. The approach uses Agilent
N444x-series Balanced-Measurement Systems, which
provide the ability to test multiport (single-ended)
devices to the level of accuracy of traditional two-port
systems. The systems can also test differential devices
and show the performance under balanced (differential-
and common-mode stimulus and response) operating
conditions using mixed-mode S-parameters.
Mixed-mode S-parameter analysis brings a great deal
of insight to differential circuit design. The following
figures provide a simple example.
The sample circuit A, illustrated in Figure 1, consists
of two gain channels that are perfectly symmetrical,
and completely isolated from each other. Its multiport
single-ended S-parameters are shown in Figure 2.
The amplifier is perfectly matched on all ports, and
the gain in each channel (S21 and S43) is about 8 dB.
Since this is a differential amplifier, it is also interesting Figure 1: Sample circuit A
to consider how the circuit behaves with differential
and common-mode stimuli. This can be determined
from the mixed-mode S-parameters shown in Figure 3.
Again, both the input and output ports are matched
for both differential and common-mode signals. The
differential and common mode gains are also the same,
about 8 dB of gain.
Figure 2: Single-ended S-parameters of sample circuit A Figure 3: Mixed-mode S-parameters of sample circuit A
2
If the ideal ground is removed, the two channels will no
longer be isolated. Figure 4 illustrates the new sample
circuit B, schematically. In this example, each port is
coupled to each other port when the circuit is viewed as a
single-ended device.
The impedance seen at each port is now 150 ohms, and the
single-ended gain is only about 2 dB, as shown in Figure 5.
By looking only at the single-ended S-parameters, it is
natural to assume that this circuit is not as good as the
previous one. This conclusion would be misleading, as the Figure 4: Sample circuit B, device without channel isolation
mixed-mode S-parameters show in Figure 6.
Because of the virtual ground that is present with a
differential stimulus, the ports are matched, and the gain is Contrary to the indications of the single-ended data,
again 8 dB. With a common-mode stimulus, the ports are this is actually a much better device than the previous
open circuited and the device has no gain. Therefore, the example because it has a very high common-mode
single-ended performance is reflecting a composite of the rejection (ratio of differential-to-common mode gain).
differential-mode and the common-mode performance. This
underscores the importance of representing the data in the
mode of operation in which the device will be used.
Figure 5: Single-ended S-parameters of sample circuit B Figure 6: Mixed-mode S-parameters of sample circuit B
3
Differential amplifier measurement
The information available from mixed-mode S-parameter
analysis can be further understood by examining data
from a four-terminal device. One such device is shown
in Figure 7.
Figure 7: A four-port single-ended device
Single-ended performance
Measured on the Agilent N4444A balanced-measurement
system, a sample device exhibited the performance
shown in Figure 8.
Used as a single-ended circuit, this amplifier has about
14 dB of gain in each of its two channels (S21 and
S43). The input impedances of the two channels (S11
and S33) are similar, as are the two output impedances
(S22 and S44).
The isolation between the two input ports (S13 and
S31), and between the two output ports (S24 and S42),
is less than 10 dB at some frequencies, indicating a
moderate amount of coupling.
Mixed-mode performance
Because of the similarity in performance of the two
channels and the moderate isolation between them, one
would expect the differential-mode and common-mode
performance to be different. The S-parameters in
Figure 9 show the mixed-mode performance of this
device.
Figure 8: Single-ended parameters of the single-ended device
As expected, the 2x2 sub-matrix in the upper left
quadrant is very different than the 2x2 sub-matrix in
the lower right quadrant, showing that the differential-
mode performance is not the same as the common-mode
performance.
The device used in this example is the Analog Devices
AD8350-20, a high-performance, fully-differential
amplifier for use in RF and IF circuits. For more
information on this device, please see
www.analogdevices.com.
Figure 9: Mixed-mode S-parameters of the single-ended device
4
Common-mode rejection ratio (CMRR) The significance of mode conversion in balanced
A balanced system is normally designed to operate in devices
differential mode because of the performance attributes The degree of circuit symmetry is very important
that this mode offers. However, although not intended, for differential applications since symmetry is the
common-mode signals, are always present on the device fundamental assumption needed to realize such
along with the intended differential-mode signal. Ideally, benefits as electromagnetic interference immunity,
a differential should respond only to the differential- power supply noise immunity, even-order harmonic
mode signal. One way of quantifying how well a suppression, and more. A perfectly symmetrical circuit
differential device discriminates between modes is the will have no mode conversion. This means, for example,
Common-mode rejection ratio (CMRR). This is a ratio that a differential stimulus will elicit a response with
of the differential-mode gain (Sdd21) to the common- a differential-mode component, but no common-mode
mode gain (Scc21). If a device has equal gain in component, and vice versa. Therefore, the mode
common- and differential-modes, then Sdd21= Scc21, conversion terms in the mixed-mode S-parameter
and the CMRR= 0 dB. matrix are all equal to zero in a perfectly symmetrical
circuit. Examining these terms provides a direct
A device will respond the same to each mode when measurement of the degree of symmetry of the device.
there is high isolation between the two sides of the
balanced pair. Differential- to common-mode terms
An example of a mode-conversion term is Scd21, shown
Figure 10 shows the CMRR of the differential device in the upper right quadrant of Figure 11. The data shows
described earlier. This device has a CMRR of better than that if the circuit is stimulated with a pure differential-
35 dB in the band of operation below 500 MHz. This says mode input signal, some of the power will be converted
that if the input to the amplifier is a signal with equal to a common-mode component at the output. The
common- and differential-mode components, the output common-mode signal that is generated will also appear
will be almost purely differential. This is because the on a ground return and could potentially radiate.
differential-mode component is being amplified, while Therefore, differential-to-common mode conversion
the common-mode component is being attenuated. can potentially be a source of EMI.
The ratio Sdd21/Scd21 - shown in the lower left quadrant
of Figure 11 - is more than 30 dB in the operating band,
so less than 1% of the available differential input power
of this device is being converted to a common-mode
output.
Similar analyses can be performed on the reflection
parameters.
Figure 10: Common-mode-rejection-ratio (CMRR)
5
Common-to-differential mode terms Conclusion
It is also possible to analyze the behavior of the circuit
with a common-mode stimulus, examining the common- Agilent has developed a solution has that provides
mode and differential-mode responses at each port. the most accurate, commercially available method for
measuring differential RF circuits. The approach uses
As described earlier (in Mixed-mode performance) the Agilent N444x Series of Balanced Measurement
because of the nature of the device used in this Systems. All of these solutions characterize differential
example, the Sdc parameters are approximately equal devices by representing the data in terms of mixed-
to the Scd parameters. In general, this equality does mode S-parameters that describe the behavior of the
not hold. circuit with differential-mode and common-mode
stimuli and responses.
Having a common-mode signal converted to a differential-
mode can have a significant impact on overall system
performance, and indicates a potential susceptibility
to performance degradation due to EMI. In differential
circuits therefore, characterization of low-mode
conversion (in relation to circuit symmetry) is critical,
and until now, extremely difficult.
Figure 11: Mode conversion terms
6
Related literature
Agilent Balanced Measurement Example: SAW Filters,
Application Note 1373-5, publication # 5988-2922EN
Agilent Balanced Measurement Example: Baluns,
Application Note 1373-6, publication # 5988-2924EN
Measurement Solutions for Balanced Components,
Product Overview, publication # 5988-2186EN
Key web resources
For more information on Agilent's balanced
solutions please visit:
www.agilent.com/find/balanced
Visit our component manufacturer industry area at:
www.agilent.com/find/component_test
