Agilent
PNA-L Network Analyzers
Application Note




On-Wafer SOLT Calibration Using
4-port PNA-L Network Analyzers
(N5230A Options x4x)
Introduction   This application note is intended for on-wafer applications using the 4-port, PNA-L
               network analyzers with two dual probes to achieve full 4-port on-wafer calibrations
               manually. 4-port PNA-L network analyzers are available in 13.5 or 20 GHz models.
               PNA-L firmware revision must be 6.03 or higher.

               This documentation provides step-by-step instructions needed to set up a calibration
               kit before a 4-port SOLT (Short-Open-Load-Thru) calibration can be performed. The steps
               outlined here can be applied toward nearly any kind of non-coaxial application, of which
               on-wafer is one.

               Equipment used:
