Image preview - the first page of the document



>> Download a-135 documenatation <<

Text preview - extract from the document

t
I
1
     PRACTICAL APPLICATION
         OF TIME DOMAIN
        IN THE DESIGN OF
    MICROWAVE COMPONENTS
            TO 50 GHz



                    Julius Botka
           Network Measurements Division
            1400 Fountaingrove Parkway
            Santa Rosa, California 95403




    RF & Microwave
    Measurement
    Symposium
    and
    Exhibition

    r'i;' PACKARD
    ~~
          HEWLETT




                   www.HPARCHIVE.com
                                   ABSTRACT

This paper describes a HP8510B Network Analyzer measurement system that has
been configured with 2.4mm coaxial connectors to take advantage of higher
resolution time domain measurements achievable by sweeping .045 to 40, or 50
GHz. High resolution provides improved ability to accurately identify closely
spaced discontinuities, which is critical to the successful design of next-
generation broadband components.
A comparison of measurement results is shown using the 2.4mm and K connector
to 40 GHz, and with the 2.4mm connector to 50 GHz.


                                    AUTHOR

Julius Botka was born and educated in Hungary. He joined HP in 1966 and has
worked on the development of microwave components and standards for the HP
8407, HP 8755, HP 8505, and HP 8510A/B Network Analyzers. Recent achievements
include the design of the .045-26.5 GHz Directional Bridge for the HP 8513A
and HP 8515A test sets, t~e concept of the 2.4mm connector family, and the HP
PSC Precision Slotless Connectors in type N, 3.5 and 2.4mm. Julius is cur-
rently R&D Project Manager for Microwave Components and Standards at HP's Net-
work Measurements Division, Santa Rosa, California.




                                   www.HPARCHIVE.com
                                                             Broadening continuous frequency
                                                             capability in network measurements
                                                             is making high resolution time
                                                             domain a reality. This paper will
                                                             give an overview of the capability
                                                             and how it may be used in the
                                                             design of the next generation of
                                                             microwave components.




                                                   7101

                                                             The paper is divided into four
                                                             sections. The first section talks
                                                             about the 2.4 mm connector, used
                                                             on most 40/50 GHz HP instrumenta-
