Image preview - the first page of the document



>> Download a-142 documenatation <<

Text preview - extract from the document

    MEASUREMENT CONSIDERATIONS
               FOR
         NETWORK ANALYSIS
                AT
      MILLIMETER FREQUENCIES


                         Bob Dildine
                 Network Measurements Division
                 1400 Fountain Grove Parkway
                    Santa Rosa, CA 95401




      RF & Microwave
;
      Measurement
      Symposium
      and
      Exhibition


      Flin-   HEWLETT
      ~~ PACKARD




                    www.HPARCHIVE.com
                   MEASUREMENT CONSIDERATIONS FOR NETWORK
                      ANALYSIS AT MILLIMETER FREQUENCIES




    This paper discusses the considerations for making accurate vector network measurements
with the HP8510 in the wa veguide bands between 26.5 G Hz and lOO G Hz. Methods of calibra-
tion, including one not requiring the use of a sliding load, types of calibration standards, flange
repeatability, and other factors affecting system performance will be discussed. Measurement
results for a variety of devices and calibration methods will be shown at frequencies up to 100
GHz.




    Author: Bob Dildine, R&D Engineer, HP Network Measurements Division, Santa Rosa, Ca.
BS Electrical Engineering (1967), San Diego State College and MS Electrical Engineering and
Computer Science (1973), University of California, Berkeley. The author has been with HP
since 1973. The majority of that time was spent as a member of a lab team developing the HP
8510 microwave network analyzer. Since 1980 he has been Project Manager for the HP
8511-8515 test sets for the HP 8510 and is currently involved with the extension of the HP 8510
to millimeter-wave frequencies.




                                         www.HPARCHIVE.com
Measurement Considerations
           For
     Network Analysis
            At
  Millimeter Frequencies


                               4361



                                             This paper discusses methods for making accurate
     System Overview                     millimeter-wave vector network measurements with
                                         the HP 8510 Network Analyzer in the waveguide
     Systematic Errors                   bands between 265 GHz and 100 GHz. Factors af-
                                         fecting system performance such as systematic and
        Calibration                      non-correctable errors, calibration methods, and
                                         flange performance will be discussed and measure-
   Non-correctable Errors                ment results for a variety of devices up to 100 GHz
                                         will be shown.
    System Performance
  Measurement Examples
         Summary


                                4362




     System Overview




                                4363


                                   1

                           www.HPARCHIVE.com
                                                                                       The system that will be described allows most of
                                                                                   the features of the HP 8510 to be used at millimeter-
                                                                                   wave frequencies. Vector error correction and time
                          Features                                                 domain are available. Due to the band-pass nature
                                                                                   of waveguide, only the band-pass mode of time
