Image preview - the first page of the document
an_346-3


>> Download an_346-3 documenatation <<

Text preview - extract from the document
                              H


Effective Impedance Measurement
Using OPEN/SHORT/LOAD
Correction



Application Note 346-3
  Introduction

  Generally, impedance measurement instruments have a reference plane to
  define the measurement accuracy at the UNKNOWN terminals of its front
  panel. HP impedance measurement instruments have a cable length correc-
  tion function which is applicable for defining the reference plane at the end
  of the HP test leads. In the actual measurement, a test fixture is connected
  to the reference plane. Test fixtures degrade the total measurement accura-
  cy by their residual impedance. To improve this degradation, error correc-
  tion should be applied. The OPEN/SHORT correction is the most popular
  correction technique used in recent impedance measurement instruments,
  But when complicated residuals exist (for example, when a scanner or a
  handler is used), or when using an extension cable whose length cannot be
  compensated with the cable length correction function, the OPEN/SHORT
  correction cannot minimize error sufficiently. To minimize these errors, the
  OPEN/SHORT/LOAD correction is very effective. This application note
  describes effective impedance measurements using the
  OPEN/SHORT/LOAD correction.

  How OPEN/SHORT/LOAD correction differs from
  OPEN/SHORT correction
  Here we compare the principle of the OPEN/SHORT/LOAD correction with
  the OPEN/SHORT correction.

1. OPEN/SHORT correction
   In the OPEN/SHORT correction, the residuals of a test fixture can be mod-
   eled as an equivalent circuit shown in Figure 1.




                                                                                  Figure 1. OPEN/SHORT
                                                                                  Correction Model


  Since Zs <<1/Yo, stray admittance Yo can be measured when the test termi-
  nals are open. Similarly residual impedance Zs can be measured when the
  test terminals are shorted. using this correction data, Device-Under-
  Test(DUT) measurement data Zm can be compensated with the following
  equation. Then a true value, Zdut, can be derived from Zm by removing the
  residuals of a test fixture.

                                                         1
                        Zm-Zs
          Zdut= ----------------------------------
                    l-(Zm-Zs)Yo

 where,
          Zdut: True value of DUT
          Zm: Measurement value of DUT
          Yo: Admittance of OPEN condition
          Zs: Impedance of SHORT condition
                (Note that each parameter has real and imaginary components.)


 As it has been shown, simple measurement errors can be mathematically
 compensated by using the OPEN/SHORT correction. However, this specific
 technique is usable only when performing measurements under the follow-
 ing test conditions:

       s Using an HP test fixture
       s Measurements at the front panel terminals
       s Measurements using an HP test cable compensated for
         electrical length

 There are numerous test conditions where complicated impedance
 parasitic cannot be modeled as the simple equivalent circuit in Figure 1.
 The OPEN/SHORT correction will not truly compensate for errors
 introduced in the following test situations:

       s Scanner/multiplexer/matrix switches
       s Component handlers
       s Custom-made test fixture
       s Non-standard length cable test leads
       s External DC bias circuitry
       s Balun transformer
       s Additional filters and amplifiers


 In addition, the OPEN/SHORT correction has the following
 severe limitations:

       s Not able to correlate measurement values from different
         test instruments
       s Not able to improve measurement repeatability


 To solve these test limitations and issues, the OPEN/SHORT/LOAD correc-
 tion is necessary.

2. OPEN/SHORT/LOAD correction

 The OPEN/SHORT/LOAD correction requires the measurement data of a
 standard DUT with known values in addition to the OPEN/SHORT measure-
 ment data. The residuals of a test fixture can be defined as a four-terminal
 network expressed with A, B, C, D parameters as shown in Figure 2.

                                                        2
                                                                                          Figure 2. OPEN/SHORT/LOAD
                                                                                          Correction Model

With the assumption that a DUT with an impedance of Z2 is connected to
the front panel terminals, the instrument would measure an impedance val-
ue of Z1. The following relationship defines Z1.

       Given:Z1=V1/I1 and Z2=V2/I2

            AV2+BI2                        AZ2+B
       Z1= -------------------------- = --------------------------
            CV2+DI2                         CZ2+D

The parameters of A,B,C and D can be removed when using the
following definitions:

       Zo: Measured value when the instrument terminals are open.
       Zs: Measured value when the terminals are shorted.
       Zsm: Measured value of the standard DUT when connected to the
             test setup.
       Zstd: True (or expected) value of the reference DUT.
       Zxm: Measured value of DUT.
       Zdut: Corrected value of DUT.


All of the analysis yields an equation that corrects for impedance parasitcs:

                  Zstd(Zo-Zsm) (Zxm-Zs)
       Zdut= ----------------------------------------------------------------------
                        (Zsm-Zs) (Zo-Zxm)

(Note that each parameter has real and imaginary components.)

The OPEN/SHORT/LOAD correction function is built into the following HP
LCR meters/analyzers:

       s HP 4263B                            s HP 4286A
       s HP 4278A                            s HP 4291B
       s HP 4279A                            s HP 4395A with opt. 010 and HP 43961A
       s HP 4284A                            s HP 4396B with opt. 010 and HP 43961A
       s HP 4285A
                                                                                      3
 Otherwise, when using other LCR meters or analyzers, a computer can be
 programmed to make the OPEN/SHORT/LOAD corrections through HP-IB.

 Consideration with OPEN/SHORT/LOAD correction
 When performing OPEN/SHORT/LOAD correction, the following points
 should be considered.

1. OPEN correction

 It is important to measure the stray admittance of a test fixture accurately
 in the OPEN correction. When getting the OPEN correction data, the dis-
 tance between measurement terminals should be the same as the distance
 that is required for actually holding the DUT.

2. SHORT correction

  It is important to measure the residual impedance of a test fixture accu-
 rately in the SHORT correction. When getting the SHORT correction data,
 the measurement terminals should be shorted or connected to a shorting
 device. When using the shorting device, the residual impedance must be
 much less than impedance value of DUT.

3. LOAD correction

 In the LOAD correction, selection and measurement of the standard DUT
 should be considered carefully.

 (1) Selection of standard DUT

 When selecting the standard DUT, there is no restriction that inductor must
 be used for inductance measurement, or capacitor must be used for a
 capacitance measurement. Any device can be used if its impedance value is
 accurately known. It is important to use a stable DUT not susceptible to
 influences of environment such as temperature or magnetic fields. From
 this viewpoint, capacitors or resistors are better sited than inductors which
 are more susceptible to the environment .
 Especially in the case of measuring low loss (low D, high Q, low ESR)
 DUTs, it is necessary to use as low loss standard DUT as possible. Since it
 is difficult to get low loss inductor but easy to get capacitor, low loss
 capacitors are recommended for the standard DUT.

 (2) Impedance value of standard DUT

 When measuring a DUT's various impedance values, it is recommended to
 use a 100 to 1k device as the standard DUT. It can be measured accu-
 rately by impedance measurement instruments and is not susceptible to
 contact resistance or residuals.
 When measuring a DUT of one impedance value, it is recommended that
 the standard DUT have a impedance value close to that of the DUT. By
 using a standard DUT, we can reduce the non-linear errors near its

                                                         4
 impedance value. However, when the DUT's impedance value is very low
 or very high, it is recommended to use a standard DUT of 100 or 1k ,
 whose value isn't close to the impedance of the DUT.
 When a low or high impedance standard DUT is used, the reference value
 (described later) of the standard DUT cannot be obtained accurately, and it
 may cause the abnormal measurement results, not the true value
 of the DUT.

 (3) Referencing the standard DUT

 To perform the OPEN/SHORT/LOAD correction, it is necessary to measure
 the standard DUT for a reference value (known value) beforehand. When
 measuring it, it is important to use a high accuracy instrument and to set
 its measurement conditions (such as integration time or averaging time) so
 that it can measure as accurately as possible. To minimize the measure-
 ment error, the standard DUT should be measured using a direct-
 connected test fixture after performing the OPEN/SHORT correction.

4. Measurement condition of impedance measurement instruments
   when performing the OPEN/SHORT/LOAD correction

 Impedance measurement equipment with the OPEN/SHORT/LOAD correc-
 tion function will automatically set the measurement condition (such as
 integration time or averaging time) so that it can perform error correction
 with highest accuracy.
 If performing the OPEN/SHORT/LOAD correction for instruments not
 equipped with the OPEN/SHORT/LOAD correction function using an exter-
 nal controller, the measurement conditions should be set to measure cor-
 rection data as accurately as possible.

 Example of actual OPEN/SHORT/LOAD correction

 Figure 3 shows the measurement example to extend the HP 4285A's
 measurement terminal using 16048E(4m cable). In this case, it is necessary
 to perform the OPEN/SHORT/LOAD correction since the HP 4285A cannot
 compensate the 4m extension cable with its cable length correction func-
 tion. Figure 4 shows the comparison of measurement error between 100pF
 capacitor measurement with the OPEN/SHORT correction and that with




                                                                          Figure 3. Cable Extension
                                                                          Using an HP 16048E (4m)


                                                       5
the OPEN/SHORT/LOAD correction. A 47pF capacitor is used as a stan-
dard DUT. This measurement result shows the error cannot be minimized
sufficiently with the OPEN/SHORT correction, but can be compensated
with an OPEN/SHORT/LOAD correction as shown by the plot.




                                                                        Figure 4. Comparison
                                                                        Between OPEN/SHORT Correction
                                                                        and OPEN/SHORT/LOAD Correction


OPEN/SHORT/LOAD correction with an external controller

The OPEN/SHORT/LOAD correction can be accomplished with simple key
operation when using an impedance measurement instruments equipped
with the OPEN/SHORT/LOAD correction function. When using instruments
not equipped with the OPEN/SHORT/LOAD correction function, it is possi-
ble to perform the OPEN/SHORT/LOAD correction by executing the correc-
tion calculation with an external controller. But this method has the
following tradeoff problems as the comparison with the correction of a
measurement instrument alone.

      s   Complicated operation
      s   Slow measurement speed due to data transfer time

Figure 5 shows an example program to execute the OPEN/SHORT/LOAD
correction for capacitor measurement using the HP 4194A Impedance Ana-
lyzer. In this program, the measurement is performed at one frequency
point with a manual trigger mode.

Line 130-190     setting measurement condition.
Line 210-270     Measuring impedance of OPEN condition in G-B mode.
Line 300-330     Measuring impedance of SHORT condition in R-X mode.
Line 350-610     Measuring impedance of the standard DUT after inputting
                 Cs-D or Cp-D value of valued standard DUT.
Line 660-690     selecting DUT mode(Cs-D or Cp-D),
Line 710-10l0    Executing correction calculation after measuring
                 impedance of DUT, then displaying the result.

                                                     6
Conclusion

This application note shows the principle of the OPEN/SHORT/LOAD
correction and some points to be considered in the execution. With the
proper OPEN/SHORT/LOAD correction, measurement comes
higher in accuracy.


"Reference" Impedance measurement handbook (5091-3000)




                                                     7
Figure 5. Sample Program for HP 4194A OPEN/SHORT/LOAD Correction




                                                      8
9
Appendix. Correction Capability of HP Instruments


  Model No.             Correction Capability                Cable Length Correction

  HP 4192A              OPEN/SHORT Correction                0m/1m

  HP 4194A              OPEN/SHORT Correction                0m/1m

  HP 4195A(*)           OPEN/SHORT Correction                none (Electrical Length Correction)
  with HP 41951A

  HP 4263A(*)           OPEN/SHORT Correction                0m/lm/2m
                        OPEN/SHORT/LOAD Correction
                        (via HP-IB)

  HP 4263B              OPEN/SHORT/LOAD Correction           0m/1m/2m/4m

  HP 4274A(*)           OPEN/SHORT Correction                0m /lm
  /HP 4275A(*)

  HP 4276A(*)           OPEN/SHORT Correction                0m/1m
  /HP 4277A(*)

  HP 4278A              OPEN/SHORT/LOAD Correction           0m/1m/2m
                        Multi Channel Correction (Opt.301)

  HP 4279A              OPEN/SHORT/LOAD Correction           0m/1m/2m
                        Multi Channel Correction

  HP 4284A              OPEN/SHORT/LOAD Correction           0m/lm
                        Multi Channel Correction (Opt.301)   0m/1m/2m/4m (Opt.006)

  HP 4285A              OPEN/SHORT/LOAD Correction           0m/1m/2m
                        Multi Channel Correction (Opt.301)

  HP 4286A              OPEN/SHORT/LOAD Correction           none (Electrical Length Correction)

  HP 4291A(*)           OPEN/SHORT/LOAD Correction           none (Electrical Length Correction)

  HP 4291B              OPEN/SHORT/LOAD Correction           none (Electrical Length Correction)

  HP 4395A with         OPEN/SHORT/LOAD Correction           none (Electrical Length Correction)
  Opt.010,43961A

  HP 4396B with          OPEN/SHORT/LOAD Correction          none (Electrical Length Correction)
  Opt.010,43961A

  (*) Obsolete




                                                        10
H


For more information about Hewlett-
Packard test & measurement products,
applications, services, and for a
current sales office listing, visit
our web site, http://www.hp.com/go/tmdir.
You can also contact one of the following
centers and ask for a test and
measurement sales representative.

United States:
Hewlett-Packard Company
Test and Measurement Call Center
P.O. Box 4026
Englewood, CO 80155-4026
1 800 452 4844

Canada:
Hewlett-Packard Canada Ltd.
5150 Spectrum Way
Mississauga, Ontario
L4W 5G1
(905) 206 4725

Europe:
Hewlett-Packard
European Marketing Centre
P.O. Box 999
1180 AZ Amstelveen
The Netherlands
(31 20) 547 9900

Japan:
Hewlett-Packard Japan Ltd.
Measurement Assistance Center
9-1, Takakura-Cho, Hachioji-Shi,
Tokyo 192-8510, Japan
Tel: (81) 426 56 7832
Fax: (81) 426 56 7840

Latin America:
Hewlett-Packard
Latin American Region Headquarters
5200 Blue Lagoon Drive
9th Floor
Miami, Florida 33126
U.S.A.
Tel: (305) 267-4245
     (305) 267-4220
Fax: (305) 267-4288

Australia/New Zealand:
Hewlett-Packard Australia Ltd.
31-41 Joseph Street
Blackburn, Victoria 3130
Australia
Tel: 1800 629 485 (Australia)
     0800 738 378 (New Zealand)
Fax: (61 3) 9210 5489

Asia Pacific:
Hewlett-Packard Asia Pacific Ltd.
17-21/F Shell Tower, Times Square,
1 Matheson Street, Causeway Bay,
Hong Kong
Tel: (852) 2599 7777
Fax: (852) 2506 9285

Data subject to change
Copyright



◦ Jabse Service Manual Search 2024 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
