r/i~ HEWLETT
Distributed Systems Network ~~ PACKARD

Terminal (TERMDSM)
On-Line Diagnostic/Support Monitor
reference manual

t 1t --.l..------I-

---+---
Distributed Systems Network

TERMINAL (TERMDSM) ON-LINE
DIAGNOSTIC/SUPPORT MONITOR

Reference Manual

I...

FliiW HEWLETT
.:~ PACKARD
19420 HOMESTEAD ROAD CUPERTINO, CA. 95014

Part No. 30144-90013 Printed in U.S.A. 02/84
E0284
}

)

NOTICE

The information contained in this document is subject to change without notice.

HEWLETT-PACKARD MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS
MATERIAL, INCLUDING, BUT NOT LIMITED TO) THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Hewlett-Packard shall not
be liable for errors contained herein or for incidental or consequential damages in connection with the
furnishing) performance or use of this material.

Hewlett-Packard assumes no responsibility for the use or reliability of its software on equipment that
is not furnished by Hewlett-Packard.

This document contains proprietary information which is protected by copyright. All rights are
reserved. No part of this document may be photocopied, reproduced or translated to another language
without the prior written consent of Hewlett-Packard Company.

\
New editions are complete revisions of the manual. Update packages, which are issued between editions,
contain additional and replacement pages to be merged into the manual by the customer. The dates on
the title page change only when a new edition or a new update is published. No information is
incorporated into a reprinting unless it appears as a prior update; the edition does not change when an
update is incorporated.

The software code printed alongside the date indicates the version level of the software product at the
time the manual or update was issued. Many product updates and fixes do not require manual changes
and, conversely, manual corrections may be done without accompanying product changes. Therefore, do
not expect a one to one correspondence between product updates and manual updates.

First Edition Feb 1984 30196G. 04. 06

111
,:)

('(~y ..:

..... _t
LIST OF EFFECTIVE PAGES

~
" ........

\
The List of Effective Pages gives the date of the most recent version of each page of the manual. Within
the manual, changes since the most recent edition are indicated by printing the date of the update on the
bottom of the page, and by marking the changes with a vertical bar in the margin. If an update is
incorporated when an edition is reprinted, these bars are removed but the dates are retained. No
information is incorporated into a reprinting unless it appears as a prior update. To verify that your
manual contains the most current information, check that the date printed at the bottom of the page
matches the date listed below for that page.

Effective Pages Date

all Feb 1984

v
.,/
PREFACE

\
This manual describes the On -Line Diagnostics and Support functions for the Advanced Terminal
Processor (ATP) and the Asynchronous Data Communications Controller (ADCC). This manual should be
used with systems that are currently running with MPE V (Version G. 00. 00 or later) operating system. If
you are on MPE V (Version E. 00. 00 or F. 00.00 or earlier) refer to the Advanced Terminal Processor
(DSN/ATP) On-Line Diagnostics Manual (part number 30144-90004) for the ATPDSM program.

The ATP is an asynchronous device controller for HP 3000 Series 44, 48, 64 and 68 computer systems. A
minimum ATP subsystem consists of one System Interface Board (SIB), one Asynchronous Interface Board
(AlB), and one Hardwired Port Controller or one Modem Port Controller. It requires two I/O slots, uses
one 1MB channel address and can support twelve terminal ports. A maximum subsystem uses one System
Interface Board (SIB) and eight Asynchrouous Interface Boards (AlB's), requires nine slots, uses one 1MB
channel address, and can support 96 terminal ports. A Series 68 computer may have a maximum of 3
ATP subsystems installed. Each ATP subsystem requires one unique 1MB channel address.

The ADCC is an asynchronous device controller for HP 3000 Series 30, 33, 40, 42, 44 and 48 computer
systems. It is an interface for low-speed bit-serial asynchronous devices. Each interface consists of an
ADCC main and, optionally, one extend PCA. Each PCA multiplexes data transmission for four ports
which may be hardwired or modem connected or any mix thereof. Thus, each interface can support eight
terminal ports and requires one 1MB channel address.

This manual is written for the HP Customer Engineer, the HP System Engineer and the HP customer user,
with the assumption that the reader has a good working knowledge of the HP 3000 System environment,
and is trained in working with on -line diagnostics. This manual may be used in conjunction with related
documentation for the HP 3000 Series 30, 33, 40, 42, 44, 48, 64 and 68 Computer Systems. Related
\ documents include the following technical manuals:
