Image preview - the first page of the document
>> Download HTC_Blackstone_Service_Manual_ENG documenatation <<
Text preview - extract from the document
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 1 of 96
Blackstone
Service Manual
HTC Proprietary
U
Confidential Treatment Requested
Rev. A01
HTC Corp.
Engineering Mobility
HTC CONFIDENTIAL
SM-TP001-0704
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 2 of 96
REVISION CONTROL TABLE
REV DATE CONTENTS DEPT. REVISED STAGE
AX01 2008/8/21 Fist Draft. PSE Leo Wei DVT
AX02 2008/10/21 Chapter 3 to 10 are created in SM. PSE Leo Wei PVT
1. Chapter 4.1 added the engineer ID in
diagnostic program.
A01 2008/11/06 2. Chapter 5.2 added the value for Idle/sleep PSE Leo Wei MV
current test.
3. Chapter 9.2 revised the L2.5 component part.
HTC CONFIDENTIAL
SM-TP001-0704
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 3 of 96
1. INTRODUCTION ....................................................................................................................................................................4
1.1 PRODUCT FEATURES ..........................................................................................................................................5
1.2 PRODUCT OVERVIEW ........................................................................................................................................10
2. DEVICE DISASSEMBLING AND ASSEMBLING PROCEDURE ................................................................................17
2.1 TOOLS LIST ......................................................................................................................................................17
2.2 DISASSEMBLING PROCEDURE............................................................................................................................18
2.3 ASSEMBLING PROCEDURE ................................................................................................................................28
3. ROM RE-FLASH PROCEDURE ........................................................................................................................................42
3.1 ROM UPGRADE THRU RUU (RE-FLASH UPGRADE UTILITY) ................................................................................42
3.2 ROM IMAGE UPGRADE THRU SD CARD .............................................................................................................46
4. DIAGNOSTIC PROGRAM ..................................................................................................................................................48
4.1 LIST OF DIAGNOSTIC TEST ITEMS ......................................................................................................................48
5. POWER MEASUREMENT TEST ......................................................................................................................................62
5.1 MAIN BOARD LEAKAGE CURRENT TEST PROCEDURE ..........................................................................................62
5.2 BATTERY RUNDOWN TEST PROCEDURE ..............................................................................................................66
6. COSMETIC INSPECTION CRITERIA...............................................................................................................................71
6.1 CLASSES DEFINITION OF INSPECTIVE AREA.........................................................................................................71
6.2 DISPLAY INSPECTION ........................................................................................................................................74
6.3 MAIN UNIT INSPECTION .....................................................................................................................................75
7. GENERIC TROUBLESHOOTING .....................................................................................................................................78
8. GENERIC LABELING PLAN..............................................................................................................................................83
9. GENERIC SPARE PART LIST AND PHOTOS................................................................................................................87
9.1 SPL FOR REPAIR..............................................................................................................................................87
9.2 BOARD LEVEL 2.5 REPAIRS ..............................................................................................................................92
10. RF ANTENNA SPECIFICATION ...................................................................................................................................95
HTC CONFIDENTIAL
SM-TP001-0704
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 4 of 96
1. Introduction
This manual provides the technical information to support the service activities of this product.
This document contains highly confidential information, so any or all of this document should not be revealed to
any third party.
Chapter 1: Introduction-This Chapter is about Products features and basic Product function. After
reading this chapter, you will know what feature the product has and basic hardware
operation. Also you will know how to perform soft-rest and hard-rest in this chapter.
Chapter 2: Device Disassembling and Assembling Procedure- After reading this chapter, you will
learn how to disassemble and assemble the product. Also, you will know what tools to
use and the torque. Please follow the instruction to disassemble the unit to prevent
from damaging the unit.
Chapter 3: ROM Re-flash Procedure- After reading this chapter, you will learn how to perform
the ROM image re-flesh by using RUU and SD-Card. Also you can find the steps of
enter the boot loader mode.
Chapter 4: DIAGNOSTIC PROGRAM- After reading this chapter, you will learn
How to use the diagnostic program to perform unit function test
How to test some functions in Windows Mobile mode (ex. WLAN, Bluetooth, and
USB etc...)
Chapter 5: Power measurement test- After reading this chapter, you will learn how to use MB
leakage test procedure and battery run-down test (Battery Capacity Measurement).
Chapter 6: Cosmetic Inspection Criteria- After reading this chapter you will learn the appearance
quality inspection criteria, ex. Display, bezel, and housing etc...
Chapter 7: Generic Troubleshooting- After reading this chapter, you will learn how to do generic
trouble-shooting.
Chapter 8: Generic Labeling Plan- In this chapter, you will find generic labels for reference, ex.
Regulation label, and battery label etc...
Chapter 9: Generic Spare Part List and Photos- In this chapter, you will find Spar parts reference
list and photos for repairing, including unit and Board level.
Chapter 10: RF Antenna Specification- Reference Spec for RF test.
HTC CONFIDENTIAL
SM-TP001-0704
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 5 of 96
1.1 Product Features
HTC CONFIDENTIAL
SM-TP001-0704
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 6 of 96
HTC CONFIDENTIAL
SM-TP001-0704
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 7 of 96
HTC CONFIDENTIAL
SM-TP001-0704
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 8 of 96
HTC CONFIDENTIAL
SM-TP001-0704
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 9 of 96
HTC CONFIDENTIAL
SM-TP001-0704
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 10 of 96
1.2 Product overview
HTC CONFIDENTIAL
SM-TP001-0704
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 11 of 96
HTC CONFIDENTIAL
SM-TP001-0704
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 12 of 96
HTC CONFIDENTIAL
SM-TP001-0704
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 13 of 96
HTC CONFIDENTIAL
SM-TP001-0704
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 14 of 96
To remove the Battery cover
To install / remove the SIM card
To install / remove the SD card
HTC CONFIDENTIAL
SM-TP001-0704
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 15 of 96
To install / remove the battery
Charging the battery
HTC CONFIDENTIAL
SM-TP001-0704
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 16 of 96
To perform a soft reset
1. Remove the back cover.
2. Pull out the stylus.
3. Use the stylus to press the RESET button located between the SIM card and the storage card slots.
Your device restarts and displays the Today screen.
To perform a hard reset
Warning! Your device will be set back to factory default settings. Make sure that any additional installed
programs and/or user data have been backed up before you perform a hard reset.
1. Pull out the stylus
2. With the device turned off, press and hold the VOLUME UP and VOLUME DOWN buttons, then briefly
press the POWER button.
3. Continue pressing the VOLUME UP and VOLUME DOWN buttons until you see this message on the
screen:
4. Release the VOLUME UP and VOLUME DOWN buttons.
5. Press the VOLUME UP button to perform the hard reset, or press any other button to cancel the reset.
To clear storage
You can also use Clear Storage to reset your device back to factory default settings.
1. On the Home screen, slide to the Settings tab and then tap All Settings.
2. On the System tab, tap Clear Storage.
3. Enter "1234" and then tap Yes.
HTC CONFIDENTIAL
SM-TP001-0704
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 17 of 96
2. Device Disassembling and Assembling Procedure
2.1 Tools list
level No. Item Vendor P/N
1 Mini USB DATA interface Cable
2 Earphone Headset
3 AC Adapter
4 WLAN AP
Memory Card with Diag. test program (need be
5 HTC design
encoded by HTC)
L1 Memory card for ROM code re-flash ( must be
6 HTC design
encoded by HTC)
7 3pin battery holder HTC special tools MLT-00008
8 Universal Leakage Current Tester HTC special tools MLT-00001
9 Power supply
10 Current Meter
11 Mobile tester
12 Special Made Plastic Stick HTC special tools RTT-00006
13 Hand tools
L2
14 Oven for rework purpose HTC special tools RTT-00007
15 Barcode label printer (400dpi resolution and up)
16 Lead-free Soldering station
L 2.5
17 Hot air gun
HTC CONFIDENTIAL
SM-TP001-0704
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 18 of 96
2.2 Disassembling procedure
1. PHILLIPS SCREW-DRIVER 00X50
2. TORX SCREW-DRIVER T5X50
3. FLAT PLASTIC STICK (P/N:
RTT-00006)
4. CLEANING CLOTH
5. PLASTIC TWEEZERS
6. ESD WRIST STRAP.
Take out the stylus
Remove the battery cover
as shown
HTC CONFIDENTIAL
SM-TP001-0704
Doc. No. DOC-00045694 REV.
HTC Corporation Issued Date 2008/8/21
A01
. Revised Date 2008/11/6
Doc. Title Blackstone Service Manual Page 19 of 96
Take out the battery as
shown
Unfasten the screw at the
location indicated
Tool: Phillips screw-driver 0
P/N: 72H02916-00M
Torque: 0.7◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
