Image preview - the first page of the document
HTC_Niki_Service_Manual_ENG


>> Download HTC_Niki_Service_Manual_ENG documenatation <<

Text preview - extract from the document
                                                                               Doc. No.     DOC-00034195   REV.

                                              HTC Corporation                Issued Date     2007/9/27
                                                                                                           A07
                                    .                                        Revised Date    2008/4/21

                       Doc. Title         Nike Service Manual                   Page             1 of 89




                                                    Nike
                                               Service Manual




                                                  HTC Proprietary
                                                  U




                                        Confidential Treatment Requested
                                                          Rev. A07




                                                 HTC Corporation.
                                                      Engineering Mobility


            HTC CONFIDENTIAL
                                                                                                SM-TP002-0706
6/30/2008 2:47:10 PM
                                                                                           Doc. No.     DOC-00034195      REV.

                                                      HTC Corporation                    Issued Date       2007/9/27
                                                                                                                          A07
                                          .                                              Revised Date      2008/4/21

                       Doc. Title                Nike Service Manual                        Page                2 of 89


            REVISION CONTROL TABLE

                           REV        DATE                   CONTENTS                    DEPT      REVISED        STAGE

                           AX01     2007/9/26    First Draft                             PSE       Justin_Lai      DVT
                                                 1. Modify chapter 3.
                           AX02     2007/10/11                                           PSE       Justin_Lai       PVT
                                                 2. Modify chapter 10.
                                                 1. Change Screw P/N from
                                                     72H02246-00M to
                                                     72H02310-00M.
                           A01      2007/10/25                                           PSE       Justin_Lai       MV
                                                 2. Modify chapter 7.3
                                                 3. Modify chapter 9. Update NIKI100
                                                     & NIKI300 label
                                                 1. As EN-00006960, change
                           A02      2007/11/8        72H02245-00M*572h02373-00           PSE       Justin_Lai       MV
                                                     m*3+ 72H02287-00M*2
                                                 1. Add chapter 6.1 leakage current
                                                     test procedure.
                                                 2. Modify chapter 3 change some
                           A03      2007/11/14                                           PSE       Justin_Lai       MV
                                                     assembly pictures.
                                                 3. Modify chapter 10.1 change P/N
                                                     and SPL pictures.
                                                 1. Modify L2.5 component
                                                 2. Change the screw torque from 0.3
                           A04      2007/12/17                                           PSE       Justin_Lai       MV
                                                     to 0.4 KGF-CM.(72H02373-00M &
                                                     72H02287-00M) .
                                                 1. Modify the assembly process at
                           A05       2008/1/2        page 29.                            PSE       Justin_Lai       MV
                                                 2. Change the picture of front cover.
                                                 1. Add on LCM assembly process.
                           A06      2008/1/31                                            PSE       Justin_Lai       MV
                                                 2. Revise spare part.
                                                 1. Change 76H02285-00M to
                           A07      2008/4/21        76H02281-00M at page78.             PSE       Justin_Lai       MV
                                                 2. Modify L2.5 at page84.




            HTC CONFIDENTIAL
                                                                                                                SM-TP002-0706
6/30/2008 2:47:10 PM
                                                                                                                                            Doc. No.             DOC-00034195                 REV.

                                                                              HTC Corporation                                            Issued Date                 2007/9/27
                                                                                                                                                                                               A07
                                                           .                                                                            Revised Date                 2008/4/21

                       Doc. Title                                   Nike Service Manual                                                        Page                          3 of 89




            1. INTRODUCTION ....................................................................................................................................................................4

                       1.1     PRODUCT FEATURES .......................................................................................................................................................5
                       1.2     PRODUCT OVERVIEW .....................................................................................................................................................11

            3. DEVICE DISASSEMBLING AND ASSEMBLING PROCEDURE ................................................................................19

                       3.1     DISASSEMBLING PROCEDURE ........................................................................................................................................19
                       3.2     ASSEMBLING PROCEDURE .............................................................................................................................................28

            4. ROM RE-FLASH PROCEDURE ........................................................................................................................................37

                       4.1     ROM UPGRADE THRU RUU (RE-FLASH UPGRADE UTILITY) ........................................................................................37
                       4.2     ROM IMAGE UPGRADE THRU SD CARD..........................................................................................................................41

            5. DIAGNOSTIC PROGRAM ..................................................................................................................................................43

                       5.1     LIST OF DIAGNOSTIC / WINCE TEST ITEMS ..................................................................................................................43

            6. POWER MEASUREMENT TEST ......................................................................................................................................55

                       6.1     MAIN BOARD LEAKAGE CURRENT TEST PROCEDURE ...................................................................................................55
                       6.2     BATTERY RUNDOWN TEST PROCEDURE .........................................................................................................................59

            7. COSMETIC INSPECTION CRITERIA...............................................................................................................................63

                       7.1     CLASSES DEFINITION OF INSPECTIVE AREA ...................................................................................................................63
                       7.2     DISPLAY INSPECTION .....................................................................................................................................................64
                       7.3     MAIN UNIT INSPECTION ..................................................................................................................................................65

            8. GENERIC TROUBLESHOOTING .....................................................................................................................................67

            9. GENERIC LABELING PLAN..............................................................................................................................................72

            10.            GENERIC SPARE PART LIST AND PHOTOS...........................................................................................................78

                       10.1 SPL FOR REPAIR ...........................................................................................................................................................78
                       10.2 BOARD LEVEL 2.5 REPAIRS ...........................................................................................................................................85

            11.            RF ANTENNA SPECIFICATION ...................................................................................................................................88




            HTC CONFIDENTIAL
                                                                                                                                                                           SM-TP002-0706
6/30/2008 2:47:10 PM
                                                                                                   Doc. No.      DOC-00034195      REV.

                                                          HTC Corporation                        Issued Date       2007/9/27
                                                                                                                                   A07
                                             .                                                  Revised Date       2008/4/21
                       Doc. Title                   Nike Service Manual                              Page                4 of 89




            1. Introduction
                         This manual provides the technical information to support the service activities of this product.
                         This document contains highly confidential information, so any or all of this document should not be revealed to
                         any third party.
                              Chapter 1: Introduction-This Chapter is about Products features and basic Product function. After
                                         reading this chapter, you will know what feature the product has and basic hardware
                                         operation. Also you will know how to perform soft-rest and hard-rest in this chapter.
                              Chapter 2: Device Disassembling and Assembling Procedure- After reading this chapter, you will
                                         learn how to disassemble and assemble the product. Also, you will know what tools to
                                         use and the torque. Please follow the instruction to disassemble the unit to prevent
                                         from damaging the unit.
                              Chapter 3: ROM Re-flash Procedure- After reading this chapter, you will learn how to perform
                                         the ROM image re-flesh by using RUU and SD-Card. Also you can find the steps of
                                         enter the boot loader mode.
                              Chapter 4: DIAGNOSTIC PROGRAM- After reading this chapter, you will learn
                                              How to use the diagnostic program to perform unit function test
                                              How to test some functions in Windows Mobile mode (ex. WLAN, Bluetooth, and
                                              USB etc...)
                              Chapter 5: Power measurement test- After reading this chapter, you will learn how to use MB
                                         leakage test procedure and battery run-down test (Battery Capacity Measurement).
                              Chapter 6: Cosmetic Inspection Criteria- After reading this chapter you will learn the appearance
                                         quality inspection criteria, ex. Display, bezel, and housing etc...
                              Chapter 7: Generic Troubleshooting- After reading this chapter, you will learn how to do generic
                                         trouble-shooting.
                              Chapter 8: Generic Labeling Plan- In this chapter, you will find generic labels for reference, ex.
                                         Regulation label, and battery label etc...
                              Chapter 9: Generic Spare Part List and Photos- In this chapter, you will find Spar parts reference
                                         list and photos for repairing, including unit and Board level.
                              Chapter 10: RF Antenna Specification- Reference Spec for RF test.




            HTC CONFIDENTIAL
                                                                                                                       SM-TP002-0706
6/30/2008 2:47:10 PM
                                                                                         Doc. No.       DOC-00034195      REV.

                                                         HTC Corporation                Issued Date       2007/9/27
                                                                                                                          A07
                                              .                                      Revised Date         2008/4/21
                       Doc. Title                    Nike Service Manual                   Page                5 of 89



                         1.1 Product Features
            Platform                                                       HSDPA / UMTS
                         PDA form factor integrated dual modes                   3GPP Release 5 compliant
                         UMTS/HSDPA and Tri-band GSM/EDGE, Bluetooth,            UE category 6, 3.6Mbps peak rate (7.2Mbps if
                         2 mega-pixel camera, and one stop sliding phone         available)
                         keypad                                                  Concurrent : DL up to 3.6Mbps (7.2Mbps if
                         Windows Mobile 6 Professional                           available) and UL up to 384Kbps
            Dimension                                                      Global roaming
                         107 mm(L) x 55 mm(W) x 15.8 mm(T)                 Auto band switching
                         120 g with battery pack                           Handover and cell selection between GSM/EDGE
            Processor/Chipset                                              and UMTS
                         Qualcomm MSM 7200                                 DTM
                         TI 6300                                           SAIC (Circuit Switch only)
            Memory                                                         Audio codec: AMR, EFR, FR, HR
                         ROM: 128/ 256 (main SKU) MB (for programs and     SMS (MO, MT), concatenated SMS (640 characters)
                         users' storage)                                   Generic services:
                         RAM: 64/128 (main SKU) MB DDR RAM (96+160               Call holding/waiting/forwarding
                         MB)                                                     Call barring
            LCD Module                                                           CLI (Calling Line Identity)
                         2.6" QVGA dots resolution                               Display own number
                         262K-color TFT LCD with LED back light                  Network selection
                         Sensitive Touch Screen                                  Cell broadcast
            WCDMA/HSDPA (available when ready)/GSM/EDGE                          Multi-party conference call
            Function                                                             Spool icon
                         Internal antenna                                        Phase 2+ unstructured supplementary service
                         Dual mode HSDPA/UMTS 2100MHz and                        data
                         GSM/GPRS/EDGE Tri-band (900/1800/1900)                  Network Lock
                               HSDPA/UMTS                                        CPHS (partial support)
                                    2100:1920-1980MHz, 2110-2170MHz        EGPRS Functionality
                               GSM/GPRS/EDGE                                     EGPRS class B
                                    900: 880-915, 925-960MHz                     Multi-slot standard class 10 (Class 12- carrier
                                    1800: 1710-1785, 1805-1880MHz                dependent)
                                    1900: 1850-1910, 1930-1990MHz                PBCCH


            HTC CONFIDENTIAL
                                                                                                               SM-TP002-0706
6/30/2008 2:47:10 PM
                                                                                                    Doc. No.     DOC-00034195         REV.

                                                              HTC Corporation                    Issued Date        2007/9/27
                                                                                                                                        A07
                                                  .                                              Revised Date       2008/4/21
                       Doc. Title                      Nike Service Manual                           Page                  6 of 89


                                 Link Adaptation and Incremental Redundancy           Back / Clear button (Dialing pad area)
                         USIM/SIM                                                           Non-Text mode: Back key
                                 1.8/3V of UICC                                             Text Editing mode: short press: clear one
                                 USIM Application at least according to 3GPP                character or number; long press; clear
                                 TS 31.102                                                  continually characters or numbers
                                 SIM Application Tool Kit release 96 complete,        Smart Launcher button (Grid menu) (Left soft key)
                                 98 class 3, and 99 partial                           Reset
                                 Over the Air (OTA) programming                       2 SKUs Dialing Pad: 12 keys and 20 keys
                                 FDN                                             12-Keys SKU:
                                 ADN                                                  Start button (Left button (Dialing pad area))
                                 Security Pin 1 & 2 control                           Messaging/Inbox button (Left button (Dialing pad
            Camera                                                                    area))
                         Main camera:                                                 Portal button (Right button (Dialing pad area))
                                 2 mega-pixel CMOS imagine sensor FF                  Vibrator button (share with # Key)
                         2nd camera:                                                        Long Press # Key: Turn off/on Vibration mode
                                 CIF CMOS imagine sensor                              One numerical dialing pad- 12 keys
                         Preview Mirror                                          20-Keys SKU:
            Keyboard/Button/Switch                                                    One numerical dialing pad- 20 keys
                         Power button (position: upper side)                     Notification
                                 Short Press: system on/off                           One bi-color LED for UMTS/GSM standby,
                                 Long Press: Turn off power totally                   UMTS/GSM message, UMTS/GSM network status,
                         One 5-way navigation pad                                     notification, and charging status
                         Send/Hands-free button                                       One Blue LED for Bluetooth connectivity status
                                 Long Press during the call: Hands-free On/Off        Vibration for notification and incoming call
                         End Key/lock button                                          Notification by LED, Sound, message on the display
                         Volume Up/ Voice Recording Button (position: left       Audio
                         side)                                                        Built-in Microphone
                                 Quick Press: Volume Up                               Receiver
                                 Long Press: Voice Recording                          Loud speaker for Hands-Free supported
                         Volume Down/Voice Command & Dial Button                      Full duplex
                         (position: left side)                                        Audio sampling rate
                                 Quick Press: Volume Down                             16-bits with 8KHz, 11KHz, 22KHz, 44.1KHz
                                 Long Press: Voice Command                            AMR/AAC/WAV/WMA/MP3 codec
                         Camera capture button (position: right side)                 Audio Path Routing


            HTC CONFIDENTIAL
                                                                                                                          SM-TP002-0706
6/30/2008 2:47:10 PM
                                                                                                  Doc. No.     DOC-00034195      REV.

                                                              HTC Corporation                 Issued Date         2007/9/27
                                                                                                                                 A07
                                                .                                            Revised Date         2008/4/21
                       Doc. Title                     Nike Service Manual                           Page              7 of 89


                              Bluetooth                                            External RF connector with cover
                              Receiver                                        Power
                              Speaker                                              Battery
                              Headset                                                    Removable and Rechargeable Lithium ion or
            Connectivity & Interface                                                     Lithium-polymer battery, 1100mAh
                         Bluetooth                                                       Charging time: 3 hours
                              Compliant with v2.0 with EDR                         Battery life
                              Class 2 transmit power                                     Playing WMV: 8 hours
                              Supported profiles:                                        Playing WMA: 12 hours
                                     GAP (generic access profile)                        Talk time: 2.8 ~ 6 hours for GSM based on RF
                                     SPP (serial port profile)                           power level 5~12
                                     OPP (object push profile)                           Talk time: 1.5 ~ 4 hours for UMTS based on RF
                                     GOEP (generic object exchange profile)              power level 0 dbm~Max
                                     ActiveSync-Over-Bluetooth (legacy                   Video Telephony time: 60~120 mins based on
                                     application via SPP)                                RF power level 0 dbm~Max
                                     HSP (headset profile)                               Standby time: 150+ hours for GSM based on
                                     HFP (handsfree profile)                             multiframe 2~5
                                     A2DP (Advanced Audio Distribution                   Standby time: 160 ~ 250 hours for UMTS
                                     profile)                                      AC adaptor
                                     AVRCP (Audio/Video Remote control                   AC input: 100 ~ 240V AC, 50/60 Hz
                                     Profile)                                      DC output: 5V and 1A
                                     HID (Human interface device profile)     Liquid Indicator
                                     SAP(SIM Access Profile)                  Stylus
                                     Service Discovery Application Profile         Retractable stylus with lock type mechanism
                                     BPP (basic printing profile)             Hanger hole
                                     FTP (file transfer profile)                   Stylish hanger to wear phone with neck strap as
                                     PAN (personal area networking profile)        pendant or to attach various phone hangers
                         HTC 11-pin mini-USB Connector                        Accessories
                              USB 2.0 Client with Full Speed                       Quick Start Guide [Inbox]
                              Audio Jack                                           CD (User manual & Sync. software) [Inbox]
                              Support USB charging and synchronization             Screen Protector [Inbox]
                              H2W                                                  Stylus [Inbox]
                         Micro SD                                                  Travel Charger (AC adapter) [Inbox]
                         1.8/3V USIM/SIM card slot                                 Pouch (Carrying Case) [Inbox]


            HTC CONFIDENTIAL
                                                                                                                     SM-TP002-0706
6/30/2008 2:47:10 PM
                                                                                                Doc. No.       DOC-00034195      REV.

                                                              HTC Corporation               Issued Date           2007/9/27
                                                                                                                                 A07
                                                .                                           Revised Date          2008/4/21
                       Doc. Title                    Nike Service Manual                          Page                 8 of 89


                         USB Sync Cable (mini-USB/USB) [Inbox]                    Microsoft Windows Mobile Update
                         Battery with battery cover [Inbox]                       Microsoft Windows Mobile Marketplace
                         Wired Stereo Headset (HS 168 or HS 200) [Inbox]          Internet Sharing
                         Device shall comply both models.                         Picture & Video
                         3-in-1 stylus                                            Games
                         3.5 mm Audio Adaptor with Microphone plus 3.5mm          File Explorer
                         stereo headset, HS U110                                  Device Management
                         Wired Remote Controller with Earphone, RC E100           Security Enhancement
                         Mono Bluetooth Headset, BH M100                               Storage Card Encryption, Device Lock
                         Mono Bluetooth Headset, BH M200                          Microsoft Office Mobile (optional with extra cost)
                         Stereo Bluetooth Headset, BH S100                             Word, Excel & PowerPoint Mobile
                         Bluetooth Keyboard                                       Microsoft Windows Live!
                         Y-Cable 11 pin to 5pin + 6pin                                 Windows Live Messenger
                         Y-Cable 11 pin to 5pin + 3.5 mm Audio Jack                    Windows Live Mail (Push Mail)
                         4-in-1 multifunction audio cable                              Windows Live Contacts
                         Car Charger                                                   Windows Live Search
                         Car Holder                                                    Windows Live Spaces
            Compatibility Test :                                                  Microsoft Remote Desktop Mobile (optional with
            Below 3rd party accessories are required to do the                    extra cost)
            compatibility test for all models.                                Value Added Applications
                         Handsfree Carkit : Parrot CK3400LS, Parrot MK6100,       Camera / Camcorder
                         Parrot Minikit, Audi, BMW & Mercedes incar                    Camera Mode
                         solutions                                                              Encoding format: JPEG
                         Bluetooth Conference: Parrot Conference                                Resolution: UXGA 1600x1200, SXGA
                         Bluetooth Speaker: Parrot Boombox                                      1280x960, VGA 640x480, QVGA
                         SanDisk memory cards (including SDHC format)



◦ Jabse Service Manual Search 2021 ◦ Jabse Pravopis ◦ Other service manual resources online : FixyaeServiceinfo
