Image preview - the first page of the document
>> Download Hitachi Ultrastar C10K147 documenatation <<
Text preview - extract from the document
UltrastarTM C10K147
2.5-INCH ENTERPRISE HARD DISK DRIVES
Small form factor enterprise hard disk drive--Optimized for power/performance
Highlights Features and Benefits
> 50% smaller footprint and 40% reduction in
Feature / Function Benefits
z-height than traditional enterprise drives
Reliability End-to-end data protection (ANSI) Enhanced error detection for optimal data integrity
> Compact size provides for optimal power
TMR head technology Highly reliable design for high-density storage
and space efficiencies
> 10,000 RPM rotational speed for Thermal Fly-height Control (TFC) Better soft error rate for improved reliability &
& adaptive formatting performance
> enterprise-class performance
> 3Gb/s SAS supports high data throughput Head load/unload ramp Minimizes handling damage during integration
and scalability Fluid Dynamic Bearing (FDB) motor Improved acoustics & positional accuracy
> Capacities up to 147GB1 Performance 10,000 RPM Reduced latency for faster access to data
Applications/Environments 16MB cache buffer Optimizes read/write response times
> Blade servers Rotational Vibration Safeguard (RVS) Improved system robustness in multi-drive systems
> 1U and 2U rack-mounted servers Workload detector technology Maximizes performance in RAID environments
> Space and/or power constrained Serial Attached SCSI (SAS) Dual port supports full-duplex and multiple data paths
environments
Investment Small Form Factor (SFF) size Lower power requirements
> Online Transaction Processing (OLTP) Improved server/storage density
> Mission-critical 24x7 applications
147GB & 73GB capacities Configuration flexibility & ease of integration
Superior performance in a small package
The UltrastarTM C10K147 is Hitachi's first small form factor (SFF) 2.5-inch enterprise hard drive.
Leveraging the company's proven enterprise-class technology, the Ultrastar C10K147 delivers
performance and reliability with lower power consumption and space requirements to meet the
needs of real-time server environments. With features like Thermal Fly-height Control (TFC)
and end-to-end data protection, the Ultrastar C10K147 provides enhanced error detection for
superior data integrity. In addition, Rotational Vibration Safeguard (RVS) maintains system
robustness in multi-drive system environments.
Configuration flexibility
The Ultrastar C10K147 provides an industry-standard Serial Attached SCSI (SAS) interface
offering customers improved performance and configuration flexibility while requiring less
147 and 73GB | 10,000 RPM power. Hitachi's dual-port configuration supports multiple data paths for optimum reliability
2.5-inch SFF | 3Gb/s SAS and performance for online transaction processing and other compute-intensive applications.
DATA SHEET www.hitachiGST.com
UltrastarTM C10K147
Specifications Hitachi quality and service
Model(s) HUC101414CSS300 Hitachi's Ultrastar C10K147 extends the
HUC101473CSS300 company's long-standing tradition of performance
Interface 3Gb/s SAS and reliability leadership. A balanced combina-
Capacity (GB) 1 147 / 73 tion of new and proven technologies enables
Sector size (variable, Bytes/sector) 512-528 (4 byte incr.) high reliability and availability to customer data.
Ultrastar quality, performance, and world class
Recording zones 20
technical support and service provides customers
Data heads (physical) 4/2
with a lower total cost of ownership over previous
Data disks 2/1
generations.
Max. areal density (Gbits/sq. in.) 137
Hitachi drives are backed by an array of techni-
Performance
cal support and services, which may include
Data buffer (MB) 2 16
customer and integration assistance. Hitachi is
Rotational speed (RPM) 10,000 dedicated to providing a breadth of hard disk
Latency average (ms) 3.0 drive solutions to satisfy all of today's demanding
Media transfer rate (Mbits/sec, max) 1057 computing needs.
Interface transfer rate (MB/sec, max) 300
Sustained transfer rate (MB/sec, typ.) 89 - 55 (zone 0-19)
How to read the Ultrastar model number
3
HUC101414CSS300 = 147GB, 3Gb/s SAS
Seek time (read, ms, typical) 3.7
H = Hitachi
Reliability
U = Ultrastar
Error rate (non-recoverable, bits read) 1 in 1016 C = Compact (vs S for Standard)
Start/stops 50,000 10 = 10,000 RPM
Availability (hrs/day x days/wk) 24x7 14 = Full capacity -- 147GB
Acoustics 14 = Capacity this model 14 =147GB
Idle (Bels) 2.9 (73 = 73GB
Power
C = Generation code
S = 14.8mm z-height
Requirement +5 VDC (+/-5%), +12 VDC (+/-5%)
S3 = Interface, 3Gb/s SAS
Operating, (W, typical) 9.0 / 8.4
0 = Reserved
Idle (W) 5.9 / 5.3
0 = Reserved
Power consump. efficiency index (W/GB) 0.040 / 0.072
Information and Technical Support
Physical size
www.hitachigst.com (Main Web site)
z-height (mm) 14.8
www.hitachigst.com/partners (Partner Web site)
Dimensions (width x depth, mm) 70.1 x 100.6
Weight (g, max) 227 North America
Environmental (operating) [email protected]
