Image preview - the first page of the document
>> Download Deskstar 5 Quick Installation Guide v3.0 documenatation <<
Text preview - extract from the document
IBM storage products
Quick installation guide
Deskstar 5
AT/IDE
Models: DHEA-34330, DHEA-36480
Handling precautions Quick installation procedure
1. Do not cover the breather hole! Covering the Note: It is advisable to backup all data before
breather hole may result in loss of data. proceeding with the installation.
If your system BIOS cannot handle large capacity drives
(over 540 MB), you may need to use a disk overlay
program such as Ontrack's Disk Manager. The
following procedure uses the Ontrack Disk Manager
2. Do not press on the drive! Do not apply any force to software. Information on obtaining a copy of Ontrack's
the drive during handling or installation. Disk Manager can be found on the Web at
www.ibm.com/harddrive.
Setting the jumpers
1. Refer to your computer manual to determine if you
require the 15 or 16 head logical architecture.
2. In a one drive system, configure your new drive as
3. Always handle the drive with care to prevent damage Master (Device 0) with no jumpers installed.
from shock, vibration, or electrostatic discharge (ESD). 3. In a two drive system, one drive must be designated
4. Do not open the static-protective bag containing the as the Master, the other as the Slave (Device 1)
drive until required. Static electricity can damage the 4. When installing the new drive as a Slave, check the
drive. Master drive to determine if a jumper change is re-
5. Turn off and unplug your computer. Remove the quired to indicate the presence of a Slave drive.
cover. 5. Consult your manual to see if your computer
6. When installing the drive, touch a grounded, supports Cable Select before choosing this option.
unpainted metal surface with the static-protective
package containing the drive for at least two seconds.
(This drains static electricity from the package and from 39 19 1 I G E C A
your body.)
7. Handle the drive carefully by the edges. Do not touch 40 20 2 H F D B
any exposed printed circuit board.
8. Save the drive packaging material including the ESD
bag in the event that the drive must be returned. Place 16 head logical architecture 15 head logical architecture
the drive in an anti-static bag before placing it in the Jumper pins Jumper pins
Master A-B and G-H Master A-C and G-H
shipping container. The warranty will be void if the drive Slave A-B and C-D Slave A-C
is not returned in IBM approved packaging. Cable Select E-F Cable Select A-C and E-F
Slave Present E-F & G-H Slave Present A-C, E-F &
G-H
Page 1
IBM Technology Group Support Center version 3.1
IBM storage products
Attaching the drive to your original configuration and contact technical
1. Turn off the computer, unplug the power cord, and support.
open the cover.
2. Match pin 1 of the 40 pin cable to pin 1 of the drive
interface connector. Pin 1 is usually denoted by a
stripe along the edge of the cable.
3. Insert a power plug in either the 3 or 4 pin power
