Image preview - the first page of the document



>> Download jbl_cinema_sb400 documenatation <<

Text preview - extract from the document

                                                 Service Manual

     CINEMA SB400
     Powered sound bar with powered, wireless 8" Subwoofer.




                                CONTENTS
SAFETY INFO                 2           SUBWOOFER EXPLODED VIEW         14
ESD WARNING                 3           PARTS AND ACCESORIES            15
LEAKAGE TESTING             4           PCB DRAWINGS                    16
CONTROLS AND CONNECTIONS    5           SEMICONDUCTOR PINOUTS           22
SETUP AND OPERATION         9           BLOCK DIAGRAM                   30
SPECIFICATIONS             12           SCHEMATICS                      31
CENTER EXPLODED VIEW       13




                             Harman International
Released 2013                 8500 Balboa Blvd.
Discontinued XXXX            Northridge, CA. 91329                Rev0 5/2013
     CINEMA BDS 570
     BDS 270 / SB400                                                                                                                                           harman/kardon
Important Safety Instructions
  1.    Read these instructions.
  2.    Keep these instructions.                                                                                                                            CAUTION
  3.    Heed all warnings.
  4.    Follow all instructions.                                                                                                             RISK OF ELECTRIC SHOCK. DO NOT OPEN.
  5.    Do not use this apparatus near water.
  6.    Clean only with a dry cloth.
  7.    Do not block any ventilation openings.Install in accordance with the manufacturer's instructions.
  8.    Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including
        amplifiers) that produce heat.
  9.    Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one          THE LIGHTNING FLASH WITH AN ARROWHEAD SYMBOL,
        wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the               WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED TO
        third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for     ALERT THE USER TO THE PRESENCE OF UNINSULATED
                                                                                                                                    "DANGEROUS VOLTAGE" WITHIN THE PRODUCT'S
        replacement of the obsolete outlet.                                                                                         ENCLOSURE THAT MAY BE OF SUFFICIENT MAGNITUDE TO
  10.   Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles and the              CONSTITUTE A RISK OF ELECTRIC SHOCK TO PERSONS.
        point where they exit from the apparatus.
  11.   Only use attachments/accessories specified by the manufacturer.
  12.   Use only with the cart, stand, tripod, bracket or table specified by the manufacturer or sold with the
        apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid
        injury from tip-over.
  13.   Unplug this apparatus during lightning storms or when unused for long periods of time.
                                                                                                                                    THE EXCLAMATION POINT WITHIN AN EQUILATERAL
  14.   Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged               TRIANGLE IS INTENDED TO ALERT THE USER TO
        in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the           THE PRESENCE OF IMPORTANT OPERATING AND
        apparatus, or the apparatus has been exposed to rain or moisture, does not operate normally or has been dropped.            MAINTENANCE (SERVICING) INSTRUCTIONS IN THE
  15.   Do not expose this apparatus to dripping or splashing and ensure that no objects filled with liquids, such as vases,        LITERATURE ACCOMPANYING THE PRODUCT.
        are placed on the apparatus.
  16.   To completely disconnect this apparatus from the AC Mains, disconnect the power supply cord plug from the AC
        receptacle.                                                                                                                 WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
  17.   The mains plug of the power supply cord shall remain readily operable.                                                      SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR
                                                                                                                                    MOISTURE.
  18.   Do not expose batteries to excessive heat such as sunshine, fire or the like.


For Products That Transmit and                                     For Canadian Model                                              Caution:
Receive RF Energy:                                                   This Class B digital apparatus complies with Canadian         This product uses a laser system. To prevent direct exposure
                                                                     ICES-003.                                                     to the laser beam, do not open the cabinet enclosure or defeat
FCC Regulations (USA Only)                                                                                                         any of the safety mechanisms provided for your protection.
                                                                                                                                   DO NOT STARE INTO THE LASER BEAM. To ensure proper use
FCC Information For Users                                          Mod
