PRINTER OPTIONS
DU-20
PARTS CATALOGUE
PRINTER OPTIONS - Parts Catalogue KYOCERA DU-20 Page 1
DU-20 Parts Catalogue
Table of Contents
Overall (Fig.1) 3
Base Assembly (Fig.2) 5
Stacker Assembly (Fig.3) 9
Top Cover Assembly (Fig.4) 13
Introduction
The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:
'Ref No.' Reference number which corresponds to the parts in the figure
'Part code' Part code which identifies the part
'Part description' A brief description of the part
'Quantity' Quantity of the part used in the printer or option
Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.
PRINTER OPTIONS - Parts Catalogue KYOCERA DU-20 Page 2
50-003
50-002
50-004
50-001
Fig.1 - Overall
PRINTER OPTIONS - Parts Catalogue KYOCERA DU-20 Page 3
Ref No. Part Code Description Quantity
50-000 DU-20 DUPLEX ASSEMBLY 1
50-001 5SNSP0009961 BASE ASSEMBLY 1
50-002 5SNSP0009962 STACKER ASSEMBLY 1
50-003 5SNSP0009963 TOP COVER ASSEMBLY 1
50-004 5SNSP0008888 COVER TOP R 1
50-005 5MVVSDU20**1 SER. NO. PLATE 1
PRINTER OPTIONS - Parts Catalogue KYOCERA DU-20 Page 4
07-004 07-015
03-012 07-006
24-004
06-006 24-005
PRINTER OPTIONS - Parts Catalogue
07-014 07-015
06-004 03-016
07-013
07-034 07-022 25-003
07-024 07-020
06-005
24-001 25-002
07-007 07-023
07-026
25-001
07-005 07-008
07-009 24-006
06-010 06-007 07-003
07-021
24-003
06-008 22-003 22-004 07-017 07-012
24-007
06-003 07-025
07-008 30-001 07-015 23-006
22-002 22-001
21-001 30-002 07-031 23-005
30-003
03-015
03-007
23-002 07-034
23-001
06-012
07-018
23-004
07-015
21-003
23-003
03-007
Fig.2 - Base Assembly
KYOCERA DU-20
29-001
07-027
03-002 29-002
03-013
29-003 03-014
03-004 03-005
03-017
21-003
03-003
05-002 03-006
03-009
03-018
20-001
03-010
20-002
03-008 03-005
04-001
04-002 04-003
03-004
Page 5
05-001
03-001
03-011
Ref No. Part Code Description Quantity
03-001 5SNSP0008869 BASE SUB ASSY 1
03-002 5SNSP0008889 COVER REAR 1
03-003 5SNSP0008987 SPRING R COVER 1
03-004 5SNSP0008904 LEVER LOCK 1
03-005 5SNSP0008988 SPRING LOCK DS 2
03-006 5SNSP0009965 LED ASSY 2
03-007 5SNSP0008885 CONN. CORD S00751 1
03-008 5SNSP0008880 CONN. CORD S00716 1
03-009 5SNSP0008949 BRACKET DB CONNECT 1
03-010 5SNSP0008883 CONN. CORD S00719 1
03-011 5SNSP0008997 STAD CONNECTOR 1
03-012 5SNSP0008856 PASSAGE ASSY 2
03-013 5SNSP0008951 PLATE EARTH 1
03-014 5SNSP0008857 DRIVE ASSY 1
03-015 5SNSP0009003 TAPPING SCREW 1
03-016 5SNSP0009004 STAD FRAME 4
03-017 5SNSP0008876 PWB REAR SW 1
03-018 5SNSP0009971 PWB MAIN 1
03-019 5SNSP0009249 SCREW CONNECTOR 2
03-020 5SNSP0009420 IC. UPD75 P008CU 1
03-021 5MVX321NN020 CLAMP 1
04-001 5SNSP0008886 BASE 1
04-002 5SNSP0008688 FOOT 1
04-003 5SNSP0008993 SHEET RAIL 1
05-001 5SNSP0009966 LED COVER ASSY 1
05-002 5SNSP0009967 PWB LED 1
06-001 5SNSP0008891 BASE PASSAGE 1
06-002 5SNSP0008860 FRAME L ASSY 1
06-003 5SNSP0008859 PASSAGE GUIDE ASSY 1
06-004 5SNSP0008957 FRAME R 1
06-005 5SNSP0008946 GUIDE PASSAGE A 1
06-006 5SNSP0008929 GATE DB 1
06-007 5SNSP0009009 BUSHING 4 1
06-008 5SNSP0008931 LEVER GATE B 1
06-010 5SNSP0009858 LINK GATE 1
06-012 5SNSP0008990 SPRING GATE A 1
07-001 5SNSP0008861 DRIVE SUB ASSY A 1
07-002 5SNSP0008862 DRIVE SUB ASSY B 1
07-003 5SNSP0009248 SPRING JOINT R 1
07-004 5SNSP0008992 SPRING JOINT C 1
07-005 5SNSP0008963 SHAFT CLT 1
07-006 5SNSP0008896 GEAR CLT Z18 1
07-007 5SNSP0008895 GEAR CLT Z24 1
07-008 5SNSP0009012 BUSHING 6 2
07-009 5SNSP0008894 GEAR Z24 1
PRINTER OPTIONS - Parts Catalogue KYOCERA DU-20 Page 6
Ref No. Part Code Description Quantity
07-010 5SNSP0008867 TENSION ASSY 1
07-012 5SNSP0008969 BELT T158 1
07-013 5SNSP0008962 SHAFT B 1
07-014 5SNSP0008917 PULLEY T20 1
07-015 5SNSP0008932 FLANGE 1
07-016 5SNSP0009012 BUSHING 6 2
07-017 5SNSP0008893 GEAR H44 1
07-018 5SNSP0008738 GEAR FEED Z16 1
07-020 5SNSP0008892 GEAR H16-T56 1
07-021 5SNSP0009001 BEARING 6 1
07-022 5SNSP0009002 BUSHING SLEEVE 1
07-023 5SNSP0008711 PULLEY ENCODER P16 1
07-024 5SNSP0008968 BELT T95 1
07-025 5SNSP0008715 SENSOR 1
07-026 5SNSP0008714 BRACKET ENCODER 1
07-027 5SNSP0008952 PIECE EARTH 1
07-030 5SNSP0008882 CONN CORD S00718 1
07-031 5MVK122NB001 EDGING SADDLE 1
07-032 5MVX118NN001 MINI CLAMP 4
07-034 5SNSP0008994 RUBBER 5
07-035 5SNSP0009245 RACK DS 1
20-001 5SNSP0008890 COVER PANEL 1
20-002 5SNSP0008991 SHEET PANEL 1
21-001 5SNSP0008956 EDGING SADDLE 1
21-002 5MVK121NB002 LEVER GATE A 1
21-003 5MBCE4060XSW E STOP RING 1
22-001 5SNSP0008925 GUIDE PASSAGE B 1
22-002 5SNSP0008950 BRACKET DB SENSOR 1
22-003 5SNSP0009008 SENSOR 1*
22-004 5SNSP0008881 CONN. CORD S00717 1
23-001 5SNSP0008954 FRAME DRIVE A 1
23-002 5SNSP0009006 MOTOR MAIN 1
23-003 5SNSP0009241 JOINT D ASSY 1
23-004 5SNSP0009246 GEAR Z16 1
23-005 5SNSP0008900 GEAR Z16-T20 1
23-006 5SNSP0008932 FLANGE 1
23-007 5SNSP0009237 SPRING JOINT D 1
24-001 5SNSP0008955 FRAME DRIVE B 1
24-002 5SNSP0008864 JOINT A ASSY 1
24-003 5SNSP0008738 GEAR FEED Z16 1
24-004 5SNSP0008898 GEAR Z18 2
24-005 5SNSP0008897 GEAR Z18-24 1
24-006 5SNSP0008898 GEAR Z18 1
24-007 5SNSP0008894 GEAR Z24 1
24-008 5SNSP0009240 JOINT C ASSY 1
PRINTER OPTIONS - Parts Catalogue KYOCERA DU-20 Page 7
Ref No. Part Code Description Quantity
24-009 5SNSP0008894 GEAR Z24 1
25-001 5SNSP0008961 BRACKET TENSION 1
25-002 5SNSP0008917 PULLEY T20 1
25-003 5SNSP0008932 FLANGE 1
29-001 5SNSP0009234 BRACKET JOINT D 1
29-002 5SNSP0008899 GEAR Z16 2
29-003 5SNSP0008903 COLLAR A 2
30-001 5SNSP0008947 BRACKET JOINT A 1
30-002 5SNSP0008899 GEAR Z16 1
30-003 5SNSP0008903 COLLAR A 1
PRINTER OPTIONS - Parts Catalogue KYOCERA DU-20 Page 8
14-003
11-004 15-003 01-033 14-004
15-004
14-002
11-008
15-002
14-003
11-007
15-003
11-009 11-005
PRINTER OPTIONS - Parts Catalogue
11-006
14-001
15-001
01-031
01-030
01-032 01-020
11-001
28-001
01-024
27-001
01-037
01-022
28-002 27-002
01-034
11-002
01-021
01-046
01-038
01-008 11-003 01-047 17-002
Fig.3 - Stacker Assembly
01-002 17-003
KYOCERA DU-20
17-001
26-002 01-039
16-007
01-005
26-001 16-001
01-040
08-001 01-035
16-006
01-017
01-001
16-002
16-004
01-023 01-045
16-008
01-041
01-025 16-003
01-012
01-026
16-005
08-002 01-013
01-010
01-018
01-027 01-019
01-029 01-036
01-006 01-014
01-011 13-001 13-002
01-016
01-042 01-028
01-015
01-003 12-002 01-044
01-009
18-002
10-002 10-004
01-043 01-004
Page 9
10-001
01-007
10-003
18-001
18-003
18-004
Ref No. Part Code Description Quantity
01-001 5SNSP0008871 BASE STACKER ASSY 1
01-002 5SNSP0008909 ROLLER PINCH 1
01-003 5SNSP0008940 BRACKET ROLLER 1
01-004 5SNSP0008909 ROLLER PINCH 1
01-005 5SNSP0008884 CONN. CORD S00750 1
01-006 5SNSP0008868 SENSOR ASSY 4
01-007 5SNSP0008850 EPS ASSY 2
01-008 5SNSP0008847 ADJUST ASSY 2
01-009 5SNSP0008872 GUIDE ENT ASSY 1
01-010 5SNSP0008973 GATE ENT 1
01-011 5SNSP0009009 BUSHING 4 1
01-012 5SNSP0008852 DS SENSOR ASSY 1
01-013 5SNSP0008982 SPRING GATE B 1
01-014 5MVX717NN005 SNAP BAND 1
01-015 5SNSP0008976 ROLLER C 2
01-016 5SNSP0009016 BUSH DS 2
01-017 5SNSP0008912 GEAR Z16 1
01-018 5SNSP0008918 GUIDE FRONT 1
01-019 5SNSP0008944 GUIDE ENT B 1
01-020 5SNSP0008974 ROLLER A 1
01-021 5SNSP0009016 BUSH DS 1
01-022 5SNSP0009238 GEAR CLT Z16 1
01-023 5SNSP0008917 PULLEY T20 1
01-024 5SNSP0008975 ROLLER B 1
01-025 5SNSP0009016 BUSH DS 4
01-026 5SNSP0008932 FLANGE 1
01-027 5SNSP0008917 PULLEY T20 2
01-028 5SNSP0008721 CLUTCH FEED DRIVE 1
01-029 5SNSP0008906 GEAR Z28-T20 1
01-030 5SNSP0008919 GUIDE COVER B 1
01-031 5SNSP0008873 GUIDE COVER ASSY 1
01-032 5SNSP0008943 GUIDE COVER B 1
01-033 5SNSP0008874 GUIDE PLATE ASSY 1
01-034 5SNSP0008953 SPRING EARTH 1
01-035 5SNSP0008848 PU ROLLER ASSY 1
01-036 5SNSP0009016 BUSH DS 1
01-037 5SNSP0008902 GEAR Z20 1
01-038 5SNSP0008851 JOINT C ASSY 1
01-039 5SNSP0008912 GEAR Z16 1
01-040 5SNSP0008983 SPRING JOINT C 1
01-041 5SNSP0008978 BELT T106 1
01-042 5SNSP0008979 BELT T113 1
01-043 5SNSP0008927 COVER CLT 1
01-044 5SNSP0009964 FRONT COVER ASSY 1
01-045 5SNSP0008933 COVER HARNESS 1
PRINTER OPTIONS - Parts Catalogue KYOCERA DU-20 Page 10
Ref No. Part Code Description Quantity
01-046 5SNSP0008959 BRACKET ADJUSTER 1
01-047 5SNSP0009000 SCREW ADJUSTER 1
01-048 5SNSP0009239 SHEET PROTECTOR 1
01-049 5SNSP0009235 PLATE ROLLER EARTH 1
01-050 5SNSP0009247 BUSHING 6 3
01-051 5SNSP0009244 KNOB DS 1
01-052 5SNSP0008932 FLANGE 1
08-001 5SNSP0008928 BASE STACKER 1
08-002 5SNSP0008996 FILM SENSOR 1
08-003 5SNSP0009228 FILM STACKER 1
10-001 5SNSP0008936 BRACKET EPS 1
10-002 5SNSP0008715 SENSOR 1
10-003 5SNSP0008907 LEVER EPS 1
10-004 5SNSP0008964 SHAFT EPS 1
11-001 5SNSP0008921 BASE ADJUST 1
11-002 5SNSP0008865 ADJUSTER-L ASSY 1
11-003 5SNSP0008866 ADJUSTER-R ASSY 1
11-004 5SNSP0008915 RACK ADJUSTER 2
11-005 5SNSP0008911 PINION ADJUSTER 1
11-006 5SNSP0008905 GEAR Z18-67 1
11-007 5SNSP0008908 GEAR Z48 1
11-008 5SNSP0008999 FASTENER 4 1
11-009 5SNSP0009007 MOTOR ADJUSTER 1
11-010 5SNSP0008849 HPS ASSEMBLY 1
11-011 5SNSP0009231 TAPE EARTH 1
12-001 5SNSP0008942 SHEET ENV A 1
12-002 5SNSP0009005 SHEET ENT 1
12-003 5SNSP0009227 FILM PG10 1
13-001 5SNSP0008937 BRACKET DS SENSOR 1
13-002 5SNSP0008879 PWB DS SENSOR 1
14-001 5SNSP0008920 GUIDE COVER T 1
14-002 5SNSP0008967 SHAFT PINCH 1
14-003 5SNSP0008923 ROLLER PINCH 2
14-004 5SNSP0008939 SPRING PINCH F 1
14-005 5MVVL751WN11 LABEL CAUTION 1
15-001 5SNSP0008945 GUIDE PLATE A 1
15-002 5SNSP0008967 SHAFT PINCH 1
15-003 5SNSP0008923 ROLLER PINCH 2
15-004 5SNSP0008938 SPRING PINCH R 1
15-005 5SNSP0009230 FILM PG5 2
16-001 5SNSP0008916 FRAME PU 1
16-002 5SNSP0008965 PIN PU 1
16-003 5SNSP0008972 ROLLER PU 1
16-004 5SNSP0008980 BELT T59 1
16-005 5SNSP0008966 SHAFT PU 1
PRINTER OPTIONS - Parts Catalogue KYOCERA DU-20 Page 11
Ref No. Part Code Description Quantity
16-006 5SNSP0009417 SPRING CLUTCH 1
16-007 5SNSP0009416 BUSHING CLUTCH 1
16-008 5SNSP0008972 ROLLER PU 1
17-001 5SNSP0008941 BRACKET JOINT C 1
17-002 5SNSP0008912 GEAR Z16 1
17-003 5SNSP0008910 COLLAR B 1
18-001 5SNSP0009970 COVER FRONT 1
18-002 5SNSP0008772 SPRING TENSION 2
18-003 5SNSP0008924 ROLLER EXIT 2
18-004 5SNSP0008774 SHAFT ROLLER PINCH 2
26-001 5SNSP0008913 ADJUSTER-L 1
26-002 5SNSP0008971 FILM ADJUSTER 1
27-001 5SNSP0008914 ADJUSTER-R 1
27-002 5SNSP0008971 FILM ADJUSTER 1
28-001 5SNSP0008935 BRACKET HPS 1
28-002 5SNSP0008715 SENSOR 1
PRINTER OPTIONS - Parts Catalogue KYOCERA DU-20 Page 12
02-002
02-001
Fig.4 - Top Cover Assembly
PRINTER OPTIONS - Parts Catalogue KYOCERA DU-20 Page 13
Ref No. Part Code Description Quantity
02-001 5SNSP0008887 COVER TOP F 1
02-002 5SNSP0008960 PLATE TOP 1
02-006 5SNSP0009232 CONN CORD S00766 1
PRINTER OPTIONS - Parts Catalogue KYOCERA DU-20 Page 14
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
