Image preview - the first page of the document
>> Download Kyocera Paper Feeder PF-5 Parts Manual documenatation <<
Text preview - extract from the document
PRINTER OPTIONS
PF-5
PARTS CATALOGUE
24-01-2000
PRINTER OPTIONS - Parts Catalogue KYOCERA PF-5 Page 1
PF-5 Parts Catalogue
Table of Contents
Feeding Unit (Fig.1) 3
Base Assembly (Fig.2) 5
Cover Top Assembly (Fig.3) 7
Paper cassette (PC-8) (Fig.4) 10
Introduction
The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:
'Ref No.' Reference number which corresponds to the parts in the figure
'Part code' Part code which identifies the part
'Part description' A brief description of the part
'Quantity' Quantity of the part used in the printer or option
Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.
PRINTER OPTIONS - Parts Catalogue KYOCERA PF-5 Page 2
301-002
301-001
01-002
01-001
01-003
01-004
Fig.1 - Feeding Unit
PRINTER OPTIONS - Parts Catalogue KYOCERA PF-5 Page 3
Ref No. Part Code Description Quantity
01-001 5SNSP0008686 BASE ASSY 1
01-002 5SNSP0008700 COVER TOP ASSY 1
01-003 5SNSP0008775 COVER TOP ASSY 1
01-004 5SNSP0008776 SHEET COVER 1
301-001 5SNSP0008685 FEED UNIT 1
301-002 5SNSP0008744 CASETTE ASSY 1
PRINTER OPTIONS - Parts Catalogue KYOCERA PF-5 Page 4
PRINTER OPTIONS - Parts Catalogue
02-010
02-012
02-008
02-003
02-001
02-005
Fig.2 - Base Assembly
KYOCERA PF-5
02-009
02-011
02-002
03-002
02-007 03-001
02-004 03-003
Page 5
Ref No. Part Code Description Quantity
02-001 5SNSP0008687 BASE 1
02-002 5SNSP0008688 FOOT 4
02-003 5SNSP0008689 PLATE EARTH CASETTE 1
02-004 5SNSP0008690 COVER PANEL ASSY 1
02-005 5SNSP0008694 SWITCH ASSY 1
02-007 5SNSP0009608 LEVER LOCK ON 1
02-008 5SNSP0008697 COVER REAR 1
02-009 5SNSP0008698 SPRING COVER REAR 1
02-010 5SNSP0008699 GUIDE SLIDE 1
02-011 5MVX211NN024 NYLON CLAMP 1
02-012 5MVVSPF5***1 LABEL SERIAL 1
03-001 5SNSP0008691 COVER PANEL 1
03-002 5SNSP0008692 PWB PANEL ASSY 1
03-003 5SNSP0008693 SHEET PANEL 1
PRINTER OPTIONS - Parts Catalogue KYOCERA PF-5 Page 6
PRINTER OPTIONS - Parts Catalogue
04-012
09-002
04-022
09-001
04-017
05-002
04-014
10-003
07-001
10-002
11-001
04-005
07-002
04-013
04-019 10-001
04-020
06-005
04-006
08-003
Fig.3 - Cover Top Assembly
08-001
KYOCERA PF-5
08-002 12-004
05-006
12-001
06-001
08-004
04-015
05-003
06-006
06-003 12-002
06-007
12-005
06-002
12-003
06-004
04-010
05-004 04-009
04-011
04-023
04-007
04-001
04-008
04-021
04-018 04-003
Page 7
04-002
Ref No. Part Code Description Quantity
04-001 5SNSP0009607 COYER TOP N 1
04-002 5SNSP0008702 LEVER SENS PA-1 1
04-003 5SNSP0008703 SPRING LEVER SENS 1
04-005 5SNSP0009612 BRACKET COYER TOP N 1
04-006 5SNSP0008717 SHAFT ROLL A ASSY 1
04-007 5SNSP0008722 BRACKET SENSOR FEED 1
04-008 5SNSP0008715 SENSOR 1
04-009 5SNSP0009604 ACTUATER SENSOR N 1
04-010 5SNSP0008724 LEVER SOLENOID 1
04-011 5SNSP0008725 SPRING SOLENOID 1
04-012 5SNSP0008726 SOLENOID ASSY 1
04-013 5SNSP0008729 CONNECTER ASSY 1
04-014 5SNSP0008732 SHAFT ROLLER ASSY 1
04-015 5SNSP0008734 STOPPER 1
04-017 5SNSP0008739 COYER FRONT L 1
04-018 5SNSP0008740 COYER FRONT R 1
04-019 5SNSP0008741 ROLL PICK UP ASSY 1
04-020 5SNSP0008742 PLATE EARTH 1
04-021 5SNSP0008743 PWB MAIN 1
04-022 5AACCNLZ2GEA CONN.CORD S00702 1
04-023 5MVX717NN005 SNAP BAND 1
05-002 5SNSP0008713 SENSOR ENCODER ASSY 1
05-003 5SNSP0008715 SENSOR 1
05-004 5AACCNLZlGEA CONN.CORD S00701 1
05-006 5MVK121NB002 EDGING SADDLE 1
06-001 5SNSP0008706 BRACKET MOTOR 1
06-002 5SNSP0008709 GEAR H16-P56 1
06-003 5SNSP0008708 GEAR Z20-H56 1
06-004 5SNSP0008707 GEAR Z32 1
06-005 5SNSP0008710 MOTOR ASSY 1
06-006 5SNSP0008711 PULLEY ENCODER P16 1
06-007 5SNSP0008712 BELT DRIVE Z86 1
07-001 5SNSP0008714 BRACKET ENCODER 1
07-002 5SNSP0008715 SENSOR 1
08-001 5SNSP0008718 SHAFT ROLL A 1
08-002 5SNSP0008721 CLUTCH FEED DRIVE 1
08-003 5SNSP0008719 BUSHING A 1
08-004 5SNSP0008720 BUSHING B 1
09-001 5SNSP0008727 SOLENOID 1
09-002 5SNSP0008728 BRACKET SOLENOID 1
10-001 5SNSP0008730 HOLDER CONNECTER 1
10-002 5SNSP0008731 SPACER 2
10-003 5AACCNLZ3GEA CONN. COAD S00703 1
11-001 5SNSP0008733 SHAFT ROLLER 1
12-001 5SNSP0008736 ROLLER FEED 1
PRINTER OPTIONS - Parts Catalogue KYOCERA PF-5 Page 8
Ref No. Part Code Description Quantity
12-002 5SNSP0008737 GEAR JOINT Z16 1
12-003 5SNSP0008738 GEAR FEED Z16 1
12-004 5SNSP0008719 BUSHING A 1
12-005 5SNSP0008720 BUSHING B 1
PRINTER OPTIONS - Parts Catalogue KYOCERA PF-5 Page 9
PRINTER OPTIONS - Parts Catalogue
43-003
43-002
42-011
43-001
41-002 47-001
44-002 42-012
47-002
42-010 44-001
42-010
Fig.4 - Paper cassette (PC-8)
42-007
47-005 42-004
47-004
42-005
KYOCERA PF-5
47-003
42-003
42-006
42-002
42-004
46-003
41-001 42-002
46-002
42-003 46-001
42-013
45-003
42-001
45-001
42-014
45-003
45-002
42-009
42-008
Page 10
Ref No. Part Code Description Quantity
41-001 5SNSP0008745 BASE CASETTE ASSY 1
41-002 5SNSP0008770 COVER FRONT ASSY 1
42-001 5SNSP0008746 BASE CASETTE 1
42-002 5SNSP0008747 LEVER LOCK CASETTE 2
42-003 5SNSP0008748 FLAT WASHER 2
42-004 5SNSP0008749 SPRING LEVER LOCK 2
42-005 5SNSP0008750 SHEET GUIDE A 1
42-006 5SNSP0009614 SHEET GUIDE BN 1
42-007 5SNSP0009615 SHEET GUIDE ON 1
42-008 5SNSP0008753 PLATE SPRING EARTH 1
42-009 5SNSP0008754 KNOB SIZE SELECT 1
42-010 5SNSP0009613 SPRING CASETTE N 2
42-011 5SNSP0008756 PLATE BOTTOM ASSY 1
42-012 5SNSP0008759 PLATE SIDE L ASSY 1
42-013 5SNSP0008762 PLATE SIDE R ASSY 1
42-014 5SNSP0008766 BACK END ASSY 1
43-001 5SNSP0009611 PLATE BOTTOM N 1
43-002 5SNSP0008758 PAD FRICTION 2
43-003 5MVVL662WN02 LABEL INSTRUCTION 1
44-001 5SNSP0008760 PLATE SIDE L 1
44-002 5SNSP0009609 NAIL LN 1
45-001 5SNSP0008763 PLATE SIDE R 1
45-002 5SNSP0009610 NAIL RN 1
45-003 5SNSP0008765 SPRING ADJUST SIDE 2
46-001 5SNSP0008767 BACK END 1
46-002 5SNSP0008768 SPRING ADJUST REAR 2
46-003 5SNSP0008769 COVER BACK END 1
47-001 5SNSP0008771 COVER FRONT 1
47-002 5SNSP0008772 SPRING TENSION 4
47-003 5SNSP0008773 ROLLER PINCH 2
47-004 5SNSP0008774 SHAFT ROLLER PINCH 2
47-005 5SNSP0009017 COLLOR 4
PRINTER OPTIONS - Parts Catalogue KYOCERA PF-5 Page 11
