Image preview - the first page of the document
>> Download Kyocera Sorter SO60 Parts Manual documenatation <<
Text preview - extract from the document
SO-60
Sorter
PARTS LIST
First Edition, Published in January 2001
01-065
01-027
Figure 1. Collator 01-003 01-016
01-006 01-001
B04
01-028
01-005
B04
01-067
01-004
D
01-028 01-025
01-068
01-017 01-006 01-008
01-007
01-005
01-018
01-014 01-064
01-002 01-006 01-027 K
01-016
01-005 01-010
B04
01-009
01-068
B04
B04 B07 01-024
01-015 01-004
01-029 01-063
B04 01-019 01-026
G
01-060
01-011
01-013
01-068
B04
01-015
01-018
01-012
01-035
B04 01-020
01-030 B04
01-015
01-060 SO-60 DEC-26-00 A-One
B 01-032
B03
C
B A
01-045 01-043
01-021 01-056 B06
01-034 E C
D
01-050 01-053 A E
01-061 B07 F
01-058 01-033 01-068
01-031 F
01-062 01-052 G
01-059
01-055 01-057
01-023 01-068 B02
01-022 B01
B07
B03 01-066
01-054 K
01-046
01-031 H
B05 I
J B06
01-022 H 01-049
01-023
01-048
B05 01-051
J
01-036 I
B06
01-047
01-042
B05
B06 01-042
01-037
B05
01-040
01-038
01-069
01-044 01-071
01-042
01-072 02-001
Figure 2. Overall 01-041 01-070
01-039 SO-60 DEC-26-00 A-One
SO-60 Sorter
ISP=Initial Spare Part SP=Spare Part
Voltage
Ref.No. Part Code Description ISP SP 120V 230V
01-001 5SNSP0013794 FRAME RIGHT - - 1 1
01-002 5SNSP0013795 FRAME LEFT - - 1 1
01-003 5SNSP0013839 GUIDE TOP X X 1 1
01-004 5SNSP0013847 FLAG FULL - X 5 5
01-005 5SNSP0013862 SPRING EXIT - - 10 10
01-006 5SNSP0013782 ROLLER PINCH EXIT X X 10 10
01-007 5SNSP0013861 BRUSH DISCHARGER - X 5 5
01-008 5SNSP0013788 TRAY INNER - X 5 5
01-009 5SNSP0013790 FLAG EMPTY - X 5 5
01-010 5SNSP0013866 SPRING FLAG - - 5 5
01-011 5SNSP0013771 COVER LOWER FRONT - - 1 1
01-012 5SNSP0013845 SENSOR 2 X X 1 1
01-013 5SNSP0013857 CONN CORD SENSOR - - 1 1
01-014 5SNSP0013780 ROLLER CONVEYING X X 5 5
01-015 5SNSP0013783 BUSH 5A X X 11 11
01-016 5SNSP0013784 BUSH 5B X X 6 6
01-017 5SNSP0013779 DEFLECTOR TRAY X X 4 4
01-018 5SNSP0013785 RUBBER SILENCER X X 6 6
01-019 5SNSP0013773 FLAPPER GATE X X 1 1
01-020 5SNSP0013775 GUIDE LOWER FRONT - - 1 1
01-021 5SNSP0013793 COVER REAR X X 1 1
01-022 5SNSP0013863 SPRING PINCH - - 8 8
01-023 5SNSP0013712 ROLLER PINCH X X 8 8
01-024 5SNSP0013781 BKT MOTOR - - 1 1
01-025 5SNSP0013806 MOTOR SO X X 1 1
01-026 5SNSP0013778 PULLEY GEAR X X 1 1
01-027 5SNSP0013777 PULLEY CONVEYING X X 6 6
01-028 5SNSP0013786 FLANGE PULLEY X X 6 6
01-029 5SNSP0013776 ARM SOLENOID - - 4 4
01-030 5SNSP0013774 ARM GATE - - 1 1
01-031 5SNSP0013796 BKT POWER SUPPLY - - 2 2
01-032 5SNSP0013799 DUCT CABLE R - - 1 1
01-033 5SNSP0013865 PLATE PRESS SW - - 1 1
01-034 5SNSP0013787 COVER TOP - X 1 1
Revision 1.00, 29-Jan-01
SO-60 Sorter
ISP=Initial Spare Part SP=Spare Part
Voltage
Ref.No. Part Code Description ISP SP 120V 230V
01-035 5SNSP0013772 COVER POWER REAR X X 1 1
01-036 5SNSP0013797 BKT ATTACHMENT R - - 1 1
01-037 5SNSP0013798 BKT ATTACHMENT L - - 1 1
01-038 5SNSP0013801 ATTACHMENT RIGHT X X 1 1
01-039 5SNSP0013802 ATTACHMENT LEFT X X 1 1
01-040 5SNSP0013800 COVER ATTACHMENT R X X 1 1
01-041 5SNSP0013840 COVER ATTACHMENT L X X 1 1
01-042 5SNSP0013803 SCREW ATTACHMENT - - 4 4
01-043 5SNSP0013791 COVER RIGHT X X 1 1
01-044 5SNSP0013792 COVER LEFT X X 1 1
01-045 5SNSP0013804 PWB CONTROL ASSY X X 1 1
01-046 5SNSP0013846 IN/OUTLET - - 1 1
01-047 5SNSP0013850 CONN CORD INLET - - 1 1
01-048 5SNSP0013856 CONN CORD OUTLET - - 1 1
01-049 5SNSP0013855 CONN CORD GND - - 1 1
01-050 5SNSP0013867 SW INTERLOCK X X 1 1
01-051 5SNSP0013931 PWB RELAY - X 1 1
01-052 5SNSP0013860 CONN CORD SENSOR - - 1 1
01-053 5SNSP0013854 CONN CORD INTERLOCK - - 1 1
01-054 5SNSP0013853 CONN CORD SOLENOID - - 1 1
01-055 5SNSP0013851 CONN CORD P/S IN - - 1 1
01-056 5SNSP0013852 CONN CORD P/S OUT - - 1 1
01-057 5SNSP0013849 CONN CORD TRANSMIT - - 1 1
01-058 5SNSP0013858 CONN CORD CABLE X X 1 1
01-059 5SNSP0013844 SENSOR 1 X X 1 1
01-060 5SNSP0013807 SOLENOID SO X X 5 5
01-061 5SNSP0013859 POWER SUPPLY X X 1 1
01-062 5SNSP0013838 CORD CLAMP X X 1 1
01-063 5SNSP0013841 BELT S2M 200 X X 1 1
01-064 5SNSP0013842 BELT S2M 220 X X 1 1
01-065 5SNSP0013843 BELT S2M 158 X X 4 4
01-066 5SNSP0013938 PLATE VOLTAGE - X 1 1
01-067 5SNSP0013937 ROLLER CONVEYING TOP - X 1 1
01-068 5SNSP0013918 SCREW RS M3 - - 10 10
Revision 1.00, 29-Jan-01
SO-60 Sorter
ISP=Initial Spare Part SP=Spare Part
Voltage
Ref.No. Part Code Description ISP SP 120V 230V
01-069 5SNSP0013939 PLATE LOCK R - - 1 1
01-070 5SNSP0013940 PLATE LOCK L - - 1 1
01-071 5SNSP0013941 SPRING LOCK R - - 1 1
01-072 5SNSP0013942 SPRING LOCK L - - 1 1
02-001 5SNSP0013789 TRAY SO - X 5 5
P-001 5SNSAA64E+02 PACKING ASSY - X 1 1
P-002 5SNSP0013809 OUTER CARTON X - 1 1
P-003 5SNSP0013870 PAD BOTTOM X - 1 1
P-004 5SNSP0013869 PAD TOP X - 1 1
P-005 5SNSP0013871 PAD MIDDLE X - 1 1
P-006 5SNSP0013868 BASE BOTTOM X - 1 1
P-007 5SNSP0013872 POLY BAG SO X - 1 1
A-001 5SNSP0013928 CABLE AC RELAY 220V - X - 1
A-001 5SNSAA64U+01 120V CABLE ASSY - X 1 -
