2 Pin Phoenix to BNC Cable for Sense HI, 2 m
Keithley Instruments
28775 Aurora Road
Cleveland, Ohio 44139
1-800-935-5595
http://www.keithley.com
Description
The Keithley Instruments Model 8020-SHI-BNC-2 is a 2 meter, 2-pin Phoenix to BNC Cable. This cable
assembly is used to connect the Sense HI of the Combined 2651 channel of the Model 8020 to a BNC
connector.
Figure 1: 8020-SHI-BNC-2 cable assembly
Dimensions
Figure 2: 8020-SHI-BNC-2 cable assembly dimensions
Electrical characteristics
