                                                                                       Model 2460-KIT
Keithley Instruments
28775 Aurora Road
                                                                Screw Terminal Connector Kit
Cleveland, Ohio 44139
1-800-935-5595
http://www.keithley.com




Description
    The Model 2460-KIT Screw Terminal Connector Kit contains a cable housing, an inverted plug, and a cable tie
    for strain relief. The cable housing is made up of two half-shells with cable outlets on three sides so that you
    can select which direction to wire your connections to the Model 2600-KIT rear-panel screw terminal. The
    inverted plug secures cables to pins for quick connection to the rear panel.


                                               Figure 1: Model 2460-KIT




071335400 / September 2014                           *P071335400*                                                  1
Model 2460-KIT Screw Terminal Connector Kit




            The maximum floating (common mode) voltage for a source-measure unit (SMU) is
