7002 Switch/Control Mainframe
400-channel
The Model 7002 Switch System is a 10-slot mainframe that supports up to
400 2-pole multiplexer channels or 400 matrix crosspoints . The front panel
includes a unique interactive display of channel status for quick program-
ming . Scanning speeds of up to 300 channels per second are possible with
the high density switch cards . The wide selection of more than 30 different
switch cards makes the 7002 one of the most flexible switching main-
frames available .
reduce the size and Cost
of Your switching application.
Ten-slot high density switch mainframe
Ten-slot high density switch mainframe
Up to 400 channels of 2-pole switching. A single Model 7002 mainframe
can accommodate up to ten 40-channel cards . That's 400 channels in a
