Image preview - the first page of the document
071327300 (Oct 2014)(8020-ILC-UNT)


>> Download 071327300 (Oct 2014)(8020-ILC-UNT) documenatation <<

Text preview - extract from the document
                                                                          Model 8020-ILC-UNT
Keithley Instruments
28775 Aurora Road
                                                                Unterminated Interlock Cable
Cleveland, Ohio 44139
1-800-935-5595
http://www.keithley.com




Description
    The Keithley Instruments Model 8020-ILC-UNT Unterminated Interlock Cable is used for connecting to the
    INTERLOCK OUT connector on the Model 8020 for use as a system interlock. The unterminated end of the
    cable connects to a normally-open switch at device under test (DUT) access point. For information where to
    connect this cable, refer to the Model 8020 High Power Interface Panel User's Manual.
                          Figure 1: Model 8020-ILC-UNT interlock to unterminated cable




Dimensions and pinouts
                             Figure 2: Model 8020-ILC-UNT dimensions and pinouts




071327300 / October 2014            *071327300*                                                                  1
Model 8020-ILC-UNT


Safety interlock usage
    Any SMU capable generating more than 42 V requires the use of the safety interlock. A properly configured
    safety interlock disables power from the source-measure units (SMUs) when the cover or door of a test
    enclosure for the device under test (DUT) is opened. Power is enabled when the cover or door is closed.
    A user-supplied switch is required for the safety interlock. The normally-open switch must be used on a test
    fixture, on the enclosure of a semiconductor prober or device handler, on the doors of a test-equipment rack, or
    to any access point at the device under test at which the user could be exposed to hazardous voltages.
    The switch must be installed as follows:
