Image preview - the first page of the document
>> Download 071321300 (Oct 2014)(8020-KHV) documenatation <<
Text preview - extract from the document
Model 8020-KHV
Keithley Instruments
28775 Aurora Road
Kelvin Keithley Triaxial Connector Card
Cleveland, Ohio 44139
1-800-935-5595
http://www.keithley.com
Description
The Model 8020-KHV Keithley HV Connector Card provides high-voltage triaxial connections for sense and
force connections on the Model 8020 High Power Interface Panel. Use this connector card to connect the
Model 8020 to a device under test using the Keithley high-voltage triaxial connector. The connector card can be
installed in any Model 8020 channel.
Figure 1: Model 8020-KHV, front view
Figure 2: Model 8020-KHV, side view
071321300 / October 2014 *P071321300* 1
Model 8020-KHV
Cable connections
Use the following cables to connect to this card:
