Image preview - the first page of the document
Konica Minolta QMS pagepro 4100 Parts Manual


>> Download Konica Minolta QMS pagepro 4100 Parts Manual documenatation <<

Text preview - extract from the document
++ Service ++ Service ++ Service ++ Service ++ Service ++ Service ++ Service ++ Service ++ Service++ Service ++ Service ++ Service ++ Service ++




                  PagePro 4100E/GN/W
                  Parts Manual
                              July 2000
                              1750045-001A
                                                                                                                                                                     i
                                                                                                                                           PARTS MANUAL
                   PREFACE
1.   The part numbers listed in this Parts Manual are those which were assigned to the parts making up the printer at the time the printer was originally
     introduced onto the market.

2.   Parts whose numbers are preceded by an asterisk in the Index Column on the List Page are parts to be used in only certain market areas. Therefore,
     please check the number in the Area column on the List Page and then compare it with the numbers given in the Area Chart on page II to find out which part
     number is applicable to your own Area.
     NOTE: Parts for only certain Market Areas: The part numbers for these parts vary according to market area. In other cases, these parts are used in only
            restricted areas.

3.   The Index Number on the List Page is composed of two numbers and two letters. Generally, only A is used as the first of the two letters. However,
     sometimes B, C, D, etc. are used when one part in the illustration, such as an electrical part or a part which varies according to market areas, has two or
     more part numbers. The second of the two letters represents the modification history of that part.

4.   The Areas Number is listed in the Areas Column for only those parts used in certain market areas. This Area Number represents the areas listed opposite
     to It in the Chart given on Page II. Parts having no Area Number listed in the Area Column can be used in all market areas.

5.   In the exploded views in this Parts Manual the parts (Screws & Washes, etc...) which are indicated with a four-digit number are listed in numerical order
     in the section "SCREWS AND WASHERS." Please check these four-digit numbers with the ten-digit part numbers, which should be used for ordering
     the part.

6.   All part numbers consist of "ten-digits" which should all be quoted when ordering a part. The price of parts can be obtained by referring to the "Parts Price
     List" which is separately issued.

7.   All information contained in this parts manual is subject to change.
                                                                                                                                                                            PARTS MANUAL
                AREA CHART


 AREA No.                            AREA                               (JAPAN)             AREA No.                                                AREA                                        (JAPAN)

  2520      120V
  2612      220/240V




                   We recommend that you cross out from your Parts Manuals those parts numbers which do not apply your area so that
                   no error is made when ordering parts.




                CONTENTS

 1.   HOUSING
