Image preview - the first page of the document
LG B1200 11


>> Download LG B1200 11 documenatation <<

Text preview - extract from the document
                                                  9. TOOLING LIST



9. TOOLING LIST
    Level 1

    ITEM                     FUNCTION             SPEC
    MAGANIFY(20 TIME )                            Motic 20x~80x
    DOUBLE TAPY ( 3M)                             8*22 mm
    TAPE CUTER MACHINE                            ELM
    PINCES                   Pick up small part   3C
    SCREW DRIVE              Screwing             HIOS CL3000
    ELIMINATOR AIR GUN       Clean lens           3M Model 908
    LONG FIBER CLOTH         Clean hand set       15*15 CM
    DUMMY BATTERY            For testing
    TEST SIM CARD
    ANTISTATIC GLOVE
    ESD COMPONENT BOX
    ( SMALL )
    ESD COMPONENT BOX
    ( BIG )
    ESD WRIST STRIP
    ESD TRAY
    ANTISTATIC TABLE CLOTH
    SCREW FEEDER
    HAND SCREW DRIVE




                             - 57 -
9. TOOLING LIST



       Level 2

      ITEM                      FUNCTION             SPEC
      Buzzer/Mic Replace
      LED Replace
      Murcury Battery Replace
      SOLDER STATION                                 Weller WES50
      SOLDER WIRE                                    Kester 0.6mm
      FLUX PASTE                                     Fmkanc32-200
      MAGANIFY(20 TIME )                             Motic 20x~80x
      DOUBLE TAPY ( 3M)                              8*22 mm
      TAPE CUTER MACHINE                             ELM
      PINCES                    Pick up small part   3C
      SCREW DRIVE               Screwing             HIOS CL3000
      ELIMINATOR AIR GUN        Clean lens           3M Model 908
      LONG FIBER CLOTH          Clean hand set       15*15 CM
      DUMMY BATTERY             For testing
      PRINTER
      SCANNER
      PC
      TEST SIM CARD
      ANTISTATIC CLOTH
      ANTISTATIC GLOVE
      ANTISTATIC SHOES
      ESD COMPONENT BOX
      ( SMALL )
      ESD COMPONENT BOX
      ( BIG )
      CLEANNER
      CLEANNER BOTTLE
      ESD WRIST STRIP
      ESD TRAY
      ANTISTATIC TABLE CLOTH
      SCREW FEEDER
      SOLDER IRON JIG
      HAND SCREW DRIVE




                                - 58 -
                                               9. TOOLING LIST



Level 3

ITEM                      FUNCTION             SPEC
Buzzer/Mic Replace
LED Replace
Murcury Battery Replace
SOLDER STATION                                 Weller WES50
SOLDER WIRE                                    Kester 0.6mm
FLUX PASTE                                     Fmkanc32-200
MAGANIFY(20 TIME )                             Motic 20x~80x
DOUBLE TAPY ( 3M)                              8*22 mm
TAPE CUTER MACHINE                             ELM
PINCES                    Pick up small part   3C
SCREW DRIVE               Screwing             HIOS CL3000
ELIMINATOR AIR GUN        Clean lens           3M Model 908
LONG FIBER CLOTH          Clean hand set       15*15 CM
DUMMY BATTERY             For testing
PRINTER
SCANNER
PC
TEST SIM CARD
ANTISTATIC CLOTH
ANTISTATIC GLOVE
ANTISTATIC SHOES
ESD COMPONENT BOX
( SMALL )
ESD COMPONENT BOX
( BIG )
CLEANNER
CLEANNER BOTTLE
ESD WRIST STRIP
ESD TRAY
ANTISTATIC TABLE CLOTH
SCREW FEEDER
SOLDER IRON JIG
HAND SCREW DRIVE




                          - 59 -
10. EQUIPMENT LIST



10. EQUIPMENT LIST
      Level 2

      ITEM                            FUNCTION   SPEC
      1. PC
      2. Dummy Battery
      3. Multimeter
      4. OSC SCOPE
      5. SPECTRUM



      Level 3

      ITEM                            FUNCTION   SPEC
      1. HP 8960/HP 8922/R&S CMU200
      2. HP 66311B (DC Power)
      3. PC
      4. GPIB Card (HP82350A)
      5. Dummy Battery
      6. Multimeter
      7. OSC SCOPE
      8. SPECTRUM
      9. HP E6392B




                                      - 60 -
