13. EXPLODED VIEW & REPLACEMENT PART LIST
13. EXPLODED VIEW & REPLACEMENT PART LIST
13.1 Exploded View
M33 M31
M26
M25
M32
M24
M23
M20 M22
M19
M30
M18
M15 M16 M29
M13
M27
M28
M8
M11
M7
M6 M17
M21
M14
M5
M3
M1 M2
M12
M9
M10
M4
- 124 -
13. EXPLODED VIEW & REPLACEMENT PART LIST
< Parts List of Exploded View >
Level Location No. Part No. Description QTY Specification Service Remark
M1 MDAE00 MDAE0004002 DECO,FOLDER(UPPER) 1 BLUE Cobalt Blue Yes
MDAE0004001 DECO,FOLDER(UPPER) 1 Cool Gray Metal Silver Yes
M2 MWAF00 MWAF0002601 WINDOW,LCD(SUB) 1 SUB Yes
M3 ACGJ00 ACGJ0010302 COVER ASSY,FOLDER(UPPER) 1 COBALT BLUE Cobalt Blue Yes
ACGJ0010301 COVER ASSY,FOLDER(UPPER) 1 METAL SILVER Metal Silver Yes
M4 ABGB00 ABGB0000401 BUTTON ASSY,FUNCTION 1 METAL SILVER BUTTON Yes
M5 MHGD01 MHGD0001101 HOLDER,LCD 1 SUB, 26.7X38.5 Yes
M6 SVLM00 SVLM0003001 LCD MODULE 1 128*128 , 96*64 , ,DUAL LCD, 4GRAY FSTN Yes
M7 SBCL00 SBCL0000901 BATTERY,CELL,LITHIUM 1 2.00 V,4.0 mAh,COIN ,BACKUP BATTERY Yes
M8 SJMY00 SJMY0003601 VIBRATOR,MOTOR 1 3.0 V,0.085 A,10 * 25 ,G5200 VIBRATOR Yes
M9 SUSY00 SUSY0006201 SPEAKER 1 ASSY ,8 ohm,86 dB,15 mm,G5200 SPEAKER Yes
M10 SURY00 SURY0005401 RECEIVER 1 ASSY ,99 dB,32 ohm,13 * 2.7 ,G5200 REEIVER Yes
M11 SACY00 SACY0005501 PCB ASSY,FLEXIBLE 1 G5200 LCD, LCD Connector(Header, Socket) Yes
M12 MHGD00 MHGD0001001 HOLDER,LCD 1 MAIN , 37.8X44.9 Yes
M13 ACGH00 ACGH0005602 COVER ASSY,FOLDER(LOWER) 1 COBALT BLUE Cobalt Blue Yes
ACGH0005601 COVER ASSY,FOLDER(LOWER) 1 METAL SILVER Metal Silver Yes
M14 MWAC00 MWAC0015801 WINDOW,LCD 1 MAIN Yes
M15 GMZZ00 GMZZ0003201 SCREW MACHINE 2 3.5 mm,3.5 mm,MSWR3(FN) ,N ,STR ,- , M1.7X3.5 DIA3.5 Yes
M16 MCCH00 MCCH0003907 CAP,SCREW 2 COBALT BLU Cobalt Blue Yes
MCCH0003906 CAP,SCREW 2 METAL SILVER Metal Silver Yes
M17 MHFD00 MHFD0000401 HINGE,FOLDER 1 LG-510,511,512 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
