Image preview - the first page of the document
>> Download LG G5300 5 documenatation <<
Text preview - extract from the document
13. EXPLODED VIEW & REPLACEMENT PART LIST
M19
M20 M25
M16 M23
M15
M14
M8 M12 M24
M1 M17
M4
M11
M6 M10
M3
M21
M7 M13
M22
M18
M4
M9
M2
- 130 -
13. EXPLODED VIEW & REPLACEMENT PART LIST
< Parts List of Exploded View >
No. Location No. Description Part No. QTY Specification Service
M1 ACGK00 COVER ASSY,FRONT ACGK0018701 1 YES
M2 ABGA00 BUTTON ASSY,DIAL ABGA0000801 1 YES
M3 ADCA00 DOME ASSY,METAL ADCA0009001 1 5mm DR DOME YES
M4 SVLM00 LCD MODULE SVLM0004401 1 128*128 (1.51) ,32.25*39.84 ,65K CSTN , D/IC:S6B33B0A YES
M5 SAFY00 PCB ASSY,MAIN SAFY0062201 1 G5300 EUA, GPRS Phone, Blue LED YES
M6 CN203 VIBRATOR,MOTOR SJMY0002802 1 3 V,0.08 A,12*15 ,G5300 VIBRATOR (0.5t PAD) YES
M7 SBCL00 BATTERY,CELL,LITHIUM SBCL0001302 1 2 V,1 mAh,COIN ,W3000 Back Up Battery YES
M8 SNGF00 ANTENNA,GSM,FIXED SNGF0001401 1 3.0 ,-2.0 dBd,◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
