Image preview - the first page of the document
LG G5300 10


>> Download LG G5300 10 documenatation <<

Text preview - extract from the document
2. PERFORMANCE



2. PERFORMANCE

 2.1 H/W Features
                  Item                              Feature                   Comment
                           Li-ion, 850 mAh
      Standard Battery     Si e: 42.73   64.25   7.5mm
                           Weight: 30g
      Stand by Current     < 4 mA
      Talk time            Up to 3hours (GSM TX Level 7)
      Stand by time        Up to 200hours (Paging Period: 9, RSSI: -85 dBm)
      Charging time        3hours
      RX Sensitivity       GSM, EGSM: -105dBm, DCS: -105dBm
                           GSM, EGSM: 32 dBm (Level 5)
      TX output power
                           DCS: 29dBm (Level 0)
      GPRS compatibility   Class 10
      SIM card type        3V Small
      Display              128   128 pixel 65K Color LCD
                           Hard icons
                           Key Pad:
      Status Indicator     0 ~ 9, #, *, Up/Down Navigation Key
          & keypad
                           Confirm Key, Clear Key
                           Send Key, END/PWR Key
      ANT                  Internal
      EAR Phone Jack       Yes
      PC Synchronization   Yes
      Speech coding        EFR/FR/HR
      Data and Fax         Yes
      Vibrator             Yes
      Loud Speaker         Yes
      Voice Recoding       Yes
      C-Mike               Yes
      Receiver             Yes
      Travel Adapter       Yes
      Options              Hands-free kit, CLA, Data Kit




                                          -8-
                                                                    2. PERFORMANCE



2.2 Technical Specification
     Item            Description                       Specification
                                     GSM
                                      TX: 890 + n      0.2 MHz
                                         RX: 935 + n   0.2 MHz (n = 1 ~ 124)
                                     EGSM
      1     Frequency Band            TX: 890 + (n
