Image preview - the first page of the document
>> Download LG G7020 5 documenatation <<
Text preview - extract from the document
12. EXPLODED VIEW & REPLACEMENT PART LIST
12. EXPLODED VIEW & REPLACEMENT PART LIST
12.1 Exploded View
M28
M31 M32
M27 M30
M23
M22 M26
M20
M19
M29
M16
M12 M13
M11
M10 M21 M24
M18 M25
M4 M17
M34
M2 M15
M8 M14
M1 M3
M9
M5
M7
M6
M33 M35
- 97 -
12. EXPLODED VIEW & REPLACEMENT PART LIST
< Parts List Of Exploded View >
No. Location No. Part No. Description QTY Specification Color Sevice Remark
M1 MWAF00 MWAF0005701 WINDOW,LCD(SUB) 1 G7020 G7028 Common use (ALL BRAND) Y
M2 ACGJ00 ACGJ0016302 COVER ASSY,FOLDER(UPPER) 1 Cobalt Blue Y
ACGJ0016301 COVER ASSY,FOLDER(UPPER) 1 Metal Silver Y
ACGJ0016303 COVER ASSY,FOLDER(UPPER) 1 Red Y
M3 MHFD00 MHFD0002101 HINGE,FOLDER 1 G7000 5 PHI Y
M4 SVLM00 SVLM0003701 LCD MODULE 1 128*160, 96*64 ,32.05*40.20 ,39.5*58.7*6.4(t), 65K COLOR LCD Y
M5 SUSY00 SUSY0006001 SPEAKER 1 ASSY ,8 ohm,86 dB,15 mm,G7000 SPEAKER Y
M6 SACY00 SURY0004501 RECEIVER 1 Y
M7 SJMY00 SJMY0002801 VIBRATOR,MOTOR 1 3.0 V,80 mA,12*15 ,height 2.7+0.1T Y
M8 SBCL00 SBCL0001001 BATTERY,CELL,LITHIUM 1 3 V,1.2 mAh,COIN ,ASAHI BATTERY (ML414NB/F9D) Y
M9 SACY00 SACY0004601 PCB ASSY,FLEXIBLE 1 G7000 Receiver Y
M10 SACY01 SACY0004501 PCB ASSY,FLEXIBLE 1 G7000 LCD Y
M11 ACGH00 ACGH0006702 COVER ASSY,FOLDER(LOWER) 1 Cobalt Blue Y
ACGH0006703 COVER ASSY,FOLDER(LOWER) 1 Metal Silver Y
ACGH0006704 COVER ASSY,FOLDER(LOWER) 1 Red Y
M12 GMZZ00 GMZZ0003201 SCREW MACHINE 2 3.5 mm,3.5 mm,MSWR3(FN) ,N ,STR ,- , M1.7X3.5 DIA3.5 Y
M13 MCCH00 MCCH0003902 CAP,SCREW 2 Cobal Blue Y
MCCH0003903 CAP,SCREW 2 Metal Silver Y
MCCH0003904 CAP,SCREW 2 Red Y
Cobalt Blue
MBHY0003503 BUMPER 1 LG-510,511,512,common use for METALIC SILVER,diameter=2.4 Metal Silver Y
M14 MBHY00
MBHY0003505 BUMPER 1 LG-510,511,512,common use, diameter=2.4 Red Y
M15 MWAC00 MWAC0021401 WINDOW,LCD 1 65K COLOR (LG Brand) Y
M16 ABGC00 ABGC0000701 BUTTON ASSY,SIDE 1 G7000 Y
M17 ACGK00 ACGK0014702 COVER ASSY,FRONT 1 Cobalt Blue Y
ACGK0014703 COVER ASSY,FRONT 1 Metal Silver Y
ACGK0014704 COVER ASSY,FRONT 1 Red Y
M18 MDAC00 MDAC0005001 DECO,SIDE 2 G7000 Y
M19 MCCC00 MCCC0003502 CAP,EARPHONE JACK 1 G7000 Pearl White Color Cobalt Blue Y
MCCC0003501 CAP,EARPHONE JACK 1 Metal Silver Y
MCCC0003503 CAP,EARPHONE JACK 1 Red Y
M20 ABGA00 ABGA0000901 BUTTON ASSY,DIAL 1 OK key + i (English version) Y
M21 ADCA00 ADCA0006001 DOME ASSY,METAL 1 G7000 Y
M22 SAKY00 SAKY0001101 PCB ASSY,SIDEKEY 1 G7000 Y
M23 SAFY00 SAFY0050102 PCB ASSY,MAIN 1 65K color PCB ASSY MAIN Y
M24 SUMY00 SUMY0003503 MICROPHONE 1 FPCB,-40 dB,6*1.8,TOLERANCE +-2 Y
M25 MLEA00 MLEA0003802 LOCKER,BATTERY 1 Cobalt Blue Y
MLEA0003803 LOCKER,BATTERY 1 Metal Silver Y
MLEA0003804 LOCKER,BATTERY 1 Red Y
M26 MWAZ00 MWAZ0001701 WINDOW 1 G7000 IrDA Y
M27 ACGM00 ACGM0011902 COVER ASSY,REAR 1 Cobalt Blue Y
ACGM0011903 COVER ASSY,REAR 1 MetalSilver Y
ACGM0011904 COVER ASSY,REAR 1 Red Y
M28 SNGF00 SNGF0000702 ANTENNA,GSM,FIXED 1 1.5 ,-2.5 dBd,P426C ,G7000 ANTENNA Cobalt Blue Y
SNGF0000701 ANTENNA,GSM,FIXED 1 1.5 ,-2.5 dBd,P427 ,G7000 ANTENNA (PANTONE 427C) Metal Silver Y
SNGF0000702 ANTENNA,GSM,FIXED 1 1.5 ,-2.5 dBd,P426C ,G7000 ANTENNA Red Y
M29 ACFY00 ACFY0000701 CONTACT ASSY,ANTENNA 1 G7000 Y
M30 MCCF00 MCCF0002002 CAP,MOBILE SWITCH 1 LG-510,511,512 Cobalt Blue Y
MCCF0002003 CAP,MOBILE SWITCH 1 LG-510,511,512 Metal Silver Y
MCCF0002005 CAP,MOBILE SWITCH 1 LG-510,511,512 Red Y
M31 GMZZ00 GMZZ0003201 SCREW MACHINE 2 3.5 mm,3.5 mm,MSWR3(FN) ,N ,STR ,- , M1.7X3.5 DIA3.5 Y
M32 SBPP00 SBPP0005103 BATTERY PACK,LI-POLYMER 1 3.7 V,820 mAh,1 CELL,PRISMATIC ,G7000-BATTERY PACK (CB) Cobalt Blue Y
SBPP0005102 BATTERY PACK,LI-POLYMER 1 3.7 V,820 mAh,1 CELL,PRISMATIC ,G7000-BATTERY PACK (SV) Metal Silver Y
SBPP0005104 BATTERY PACK,LI-POLYMER 1 3.7 V,820 mAh,1 CELL,PRISMATIC ,G7000-BATTERY PACK (RD) Red Y
M33 MTAE00 MTAE0004901 TAPE,WINDOW(SUB) 1 G7020 G7028 Common use Y
M34 MCCZ00 MCCZ0002702 CAP 1 Cobalt Blue Y
MCCZ0002703 CAP 1 Metal Silver Y
MCCZ0002704 CAP 1 Red Y
M35 ACGG00 ACGG0021702 COVER ASSY,FOLDER 1 Cobalt Blue Y
ACGG0021701 COVER ASSY,FOLDER 1 Metal Silver Y
ACGG0021703 COVER ASSY,FOLDER 1 Red Y
- 98 -
12. EXPLODED VIEW & REPLACEMENT PART LIST
12.2 Accessories
Portable Handsfree Travel Adapter
Cigar Lighter Adapter Data-cable
< Accessories >
No. Location No. Part No. Description QTY Specification Color Service Remark
2 SGEY00 SGEY0002901 EAR PHONE/EAR MIKE SET 1 EG890B, G5200 3P EAR MIC (EM-412GS) Yes
2 SSAD00 SSAD0007806 TRAVEL ADAPTOR,AC-DC 1 100-240V, 50/60 Hz,5.2 V,850 mA,CE (Europe: TA-20G) Yes
SSAD0007807 TRAVEL ADAPTOR,AC-DC 1 100-240V, 50/60 Hz,5.2 V,850 mA,CE (Russian(CIS): TA-20GR) Yes
2 SGCC00 SGCC0001802 CIGARETTE LIGHT ADOPTER 1 CLA (CLA-20G) Yes
2 SGDY00 SGDY0004401 DATACABLE 1 (DK-20G) Yes
- 99 -
12. EXPLODED VIEW & REPLACEMENT PART LIST
12.3REPLACEMENT PARTS
Level Location No. Part No. Description QTY Specification Service Color Remark
3 ABGA00 -- BUTTON ASSY,DIAL 1 Please refer to the 'Exploded View' Y M20
3 ACGG00 -- COVER ASSY,FOLDER 1 Please refer to the 'Exploded View' Y Cobalt Blue M35
3 ACGG00 -- COVER ASSY,FOLDER 1 Please refer to the 'Exploded View' Y Metal Silver
3 ACGG00 -- COVER ASSY,FOLDER 1 Please refer to the 'Exploded View' Y Red
4 ACGH00 -- COVER ASSY,FOLDER(LOWER) 1 Please refer to the 'Exploded View' Y Cobalt Blue M11
4 ACGH00 -- COVER ASSY,FOLDER(LOWER) 1 Please refer to the 'Exploded View' Y Metal Silver
4 ACGH00 -- COVER ASSY,FOLDER(LOWER) 1 Please refer to the 'Exploded View' Y Red
5 MBHY00 -- BUMPER 2 Please refer to the 'Exploded View' Y M14
4 MCCH00 -- CAP,SCREW 2 Please refer to the 'Exploded View' Y Cobalt Blue M13
4 MCCH01 -- CAP,SCREW 2 Please refer to the 'Exploded View' Y Metal Silver
4 MCCH02 -- CAP,SCREW 2 Please refer to the 'Exploded View' Y Red
5 MCJH00 MCJH0004203 COVER,FOLDER(LOWER) 1 N
5 MDAF00 MDAF0000702 DECO,FOLDER(LOWER) 1 N Cobalt Blue
5 MDAF00 MDAF0000703 DECO,FOLDER(LOWER) 1 N Metal Silver
5 MDAF00 MDAF0000704 DECO,FOLDER(LOWER) 1 N Red
5 MDAH01 MDAH0000201 DECO,RECEIVER 1 G7000 N
5 MFBB00 MFBB0001901 FILTER,RECEIVER 1 G7000 N
5 MPBG00 MPBG0004801 PAD,LCD 1 G7000 N
5 MPBJ00 MPBJ0003201 PAD,MOTOR 1 G7000 N
5 MTAA00 MTAA0006801 TAPE,DECO 1 G7000 RECEIVER N Pearl White
5 MTAA00 MTAA0006501 TAPE,DECO 1 G7000 FOLDER(LOWER) N Metal Silver
5 MTAA00 MTAA0006401 TAPE,DECO 1 G7000 FRONT N Red
5 MTAA01 MTAA0006501 TAPE,DECO 1 G7000 FOLDER(LOWER) N Pearl White
5 MTAA01 MTAA0006801 TAPE,DECO 1 G7000 RECEIVER N Metal Silver
5 MTAA01 MTAA0006701 TAPE,DECO 2 G7000 SIDE N Red
5 MTAD00 MTAD0010301 TAPE,WINDOW 1 NITTO No.5000NS (t=0.16) N
4 ACGJ00 -- COVER ASSY,FOLDER(UPPER) 1 Please refer to the 'Exploded View' Y Cobalt Blue M2
4 ACGJ00 -- COVER ASSY,FOLDER(UPPER) 1 Please refer to the 'Exploded View' Y Metal Silver
4 ACGJ00 -- COVER ASSY,FOLDER(UPPER) 1 Please refer to the 'Exploded View' Y Red
5 ADBY00 ADBY0001202 DECO ASSY 1 Y Cobalt Blue
5 ADBY00 ADBY0001201 DECO ASSY 1 PROJECTION ASSY (RUSSIA) Y Metal Silver
5 ADBY00 ADBY0001203 DECO ASSY 1 Y Red
6 MDAE00 MDAE0009802 DECO,FOLDER(UPPER) 1 N Cobalt Blue
6 MDAE00 MDAE0009801 DECO,FOLDER(UPPER) 1 PROJECTION N Metal Silver
6 MDAE00 MDAE0009803 DECO,FOLDER(UPPER) 1 N Red
6 MFBC00 MFBC0001901 FILTER,SPEAKER 1 G7010,G7020 COMMON USE N
6 MTAA00 MTAA0016601 TAPE,DECO 1 UPPER DECO(LEATHER ASSY) N
5 MCCZ00 -- CAP 1 Please refer to the 'Exploded View' Y Cobalt Blue M34
5 MCCZ00 -- CAP 1 Please refer to the 'Exploded View' Y Metal Silver
5 MCCZ00 -- CAP 1 Please refer to the 'Exploded View' Y Red
5 MCJJ00 MCJJ0010202 COVER,FOLDER(UPPER) 1 N Cobalt Blue
5 MCJJ00 MCJJ0010201 COVER,FOLDER(UPPER) 1 G7028 (EASTCOM BRAND) N Metal Silver
5 MCJJ00 MCJJ0010203 COVER,FOLDER(UPPER) 1 N Red
5 MDAE00 MDAE0008403 DECO,FOLDER(UPPER) 1 W7020 LG-COLOR DISPLAY (RUSSIA) N
5 MDAY00 MDAY0004201 DECO 1 G7020 G7028 Common use (SUS) N
5 MIAA00 MIAA0006701 INDICATOR,LED 1 G7020 G7028 COMMON USE N
5 MICA00 MICA0001201 INSERT,FRONT 2 LG-G510,511,512 common use, DIA = 1.7mm+2.3t N
5 MMAA00 MMAA0000901 MAGNET,SWITCH 1 G7000 12x2x0.7t N
5 MPBQ00 MPBQ0005501 PAD,LCD(SUB) 1 G7010 & G7020 SUB LCD PAD N
5 MPBZ00 MPBZ0017401 PAD 1 G7010, G7020 INDICATOR PAD (Common use) N
5 MPFD00 MPFD0001001 PLATE,GROUND 1 G7010 N
5 MTAA00 MTAA0015501 TAPE,DECO 1 G7020 folder uppper (Electro Forming) ) N
5 MTAA01 MTAA0015601 TAPE,DECO 1 G7020 FOLDER UPPER SUS (#615 OR#668) N
5 MTAE00 -- TAPE,WINDOW(SUB) 1 Please refer to the 'Exploded View' Y M33
5 MTAZ00 MTAZ0005401 TAPE 1 G7000 MAGNET SWITCH N
- 100 -
12. EXPLODED VIEW & REPLACEMENT PART LIST
Level Location No. Part No. Description QTY Specification Service Color Remark
4 ACGK00 -- COVER ASSY,FRONT 1 Please refer to the 'Exploded View' Y Cobalt Blue M17
4 ACGK00 -- COVER ASSY,FRONT 1 Please refer to the 'Exploded View' Y Metal Silver
4 ACGK00 -- COVER ASSY,FRONT 1 Please refer to the 'Exploded View' Y Red
5 ABGC00 -- BUTTON ASSY,SIDE 1 Please refer to the 'Exploded View' Y M16
5 MCCC00 -- CAP,EARPHONE JACK 1 Please refer to the 'Exploded View' Y Cobalt Blue M19
5 MCCC00 -- CAP,EARPHONE JACK 1 Please refer to the 'Exploded View' Y Pearl White
5 MCCC00 -- CAP,EARPHONE JACK 1 Please refer to the 'Exploded View' Y Red
5 MCJK00 MCJK0006602 COVER,FRONT 1 N Cobalt Blue
5 MCJK00 MCJK0006603 COVER,FRONT 1 N Metal Silver
5 MCJK00 MCJK0006604 COVER,FRONT 1 N Red
5 MDAC00 -- DECO,SIDE 2 Please refer to the 'Exploded View' Y M18
5 MDAG00 MDAG0000902 DECO,FRONT 1 N Cobalt Blue
5 MDAG00 MDAG0000903 DECO,FRONT 1 N Metal Silver
5 MDAG00 MDAG0000904 DECO,FRONT 1 N Red
5 MICA00 MICA0001201 INSERT,FRONT 4 LG-G510,511,512 common use, DIA = 1.7mm+2.3t N
5 MPBH00 MPBH0001101 PAD,MIKE 1 G7000 FRONT N
5 MTAA00 MTAA0006401 TAPE,DECO 1 G7000 FRONT N
5 MTAA01 MTAA0006701 TAPE,DECO 2 G7000 SIDE N
4 GMZZ00 -- SCREW MACHINE 2 Please refer to the 'Exploded View' Y M12
4 MGAD00 MGAD0006001 GASKET,SHIELD FORM 2 G7000 10x5x1.5t N
4 MHFD00 -- HINGE,FOLDER 1 Please refer to the 'Exploded View' Y M3
4 MTAB00 MTAB0005101 TAPE,PROTECTION 1 G7000 FOLDER UPPER PROTECTION TAPE Y
4 MTAB01 MTAB0005001 TAPE,PROTECTION 1 G7000 MAIN LCD WINDOW PROTECTION TAPE N
4 MTAB02 MTAB0005201 TAPE,PROTECTION 1 G7000 sublcd window tape N
4 MWAC00 -- WINDOW,LCD 1 Please refer to the 'Exploded View' Y M15
4 MWAF00 -- WINDOW,LCD(SUB) 1 Please refer to the 'Exploded View' Y M1
4 SACY00 -- PCB ASSY,FLEXIBLE 1 Please refer to the 'Exploded View' Y M9
5 SACY00 -- RECEIVER 1 Please refer to the 'Exploded View' Y M6
5 SBCL00 -- BATTERY,CELL,LITHIUM 1 Please refer to the 'Exploded View' Y M8
5 SJMY00 -- VIBRATOR,MOTOR 1 Please refer to the 'Exploded View' Y M7
5 SPCY00 SPCY0007304 PCB,FLEXIBLE 1 POLYI ,0.3 mm,DOUBLE ,G7000 Receiver N
5 SUSY00 -- SPEAKER 1 Please refer to the 'Exploded View' Y M5
4 SACY01 -- PCB ASSY,FLEXIBLE 1 Please refer to the 'Exploded View' Y M10
5 ENBY00 ENBY0011001 CONNECTOR,BOARD TO BOARD 1 30 PIN,0.5 mm,STRAIGHT , ,B to B CNT (SOCKET) N
5 ENBY01 ENBY0010901 CONNECTOR,BOARD TO BOARD 1 30 PIN,0.5 mm,STRAIGHT , ,B to B CNT (HEAER) N
5 SPCY00 SPCY0007202 PCB,FLEXIBLE 1 POLYI ,0.3 mm,DOUBLE ,G7000 LCD N
4 SPCY00 SPCY0013401 PCB,FLEXIBLE 1 FR-1 ,0.07 mm,DOUBLE ,GND FPCB N
4 SVLM00 -- LCD MODULE 1 Please refer to the 'Exploded View' Y M4
3 ACGM00 -- COVER ASSY,REAR 1 Please refer to the 'Exploded View' Y Cobalt Blue M27
3 ACGM00 -- COVER ASSY,REAR 1 Please refer to the 'Exploded View' Y Metal Silver
3 ACGM00 -- COVER ASSY,REAR 1 Please refer to the 'Exploded View' Y Red
4 ACFY00 -- CONTACT ASSY,ANTENNA 1 Please refer to the 'Exploded View' Y M29
5 MBIA00 MBIA0000301 BUSHING,ANTENNA 1 G7000 (KS-D-5101 C3603B ), N
3 MCCF00 MCCF0002002 CAP,MOBILE SWITCH 1 Please refer to the 'Exploded View' Y Cobalt Blue M30
3 MCCF01 MCCF0002003 CAP,MOBILE SWITCH Please refer to the 'Exploded View' Metal Silver
3 MCCF02 MCCF0002005 CAP,MOBILE SWITCH Please refer to the 'Exploded View' Red
5 MCIA00 MCIA0003701 CONTACT,ANTENNA 1 G7000 N
4 MCJN00 MCJN0005402 COVER,REAR 1 N Cobalt Blue
4 MCJN00 MCJN0005403 COVER,REAR 1 N Metal Silver
4 MCJN00 MCJN0005404 COVER,REAR 1 N Red
4 MGAD00 MGAD0011901 GASKET,SHIELD FORM 1 (2.8X7.5X0.3t) N
4 MGAD01 MGAD0012001 GASKET,SHIELD FORM 1 (6.0X6.0X3.0t) N
4 MIDZ00 MIDZ0008001 INSULATOR 1 G7000 BB INSULATOR N
4 MIDZ01 MIDZ0008101 INSULATOR 1 G7000 RF INSULATOR N
4 MLEA00 -- LOCKER,BATTERY 1 Please refer to the 'Exploded View' Y Cobalt Blue M25
- 101 -
Level Location No. Part No. Description QTY Specification Service Color Remark
4 MLEA00 -- LOCKER,BATTERY 1 Please refer to the 'Exploded View' Y Metal Silver
4 MLEA00 -- LOCKER,BATTERY 1 Please refer to the 'Exploded View' Y Red
4 MPBH00 MPBH0001201 PAD,MIKE 1 G7000 BACK N
4 MSAZ00 MSAZ0007603 SHEET 1 FDK Company(PE72 11.0*11.0*0.25t) N
4 MSAZ01 MSAZ0007602 SHEET 1 FDK Company (PE72 4.2*11.8 0.25t) N
4 MSDB00 MSDB0001701 SPRING,COIL 1 G7000 N
4 MWAZ00 -- WINDOW 1 Please refer to the 'Exploded View' Y M26
3 ADCA00 -- DOME ASSY,METAL 1 Please refer to the 'Exploded View' Y M21
3 GMZZ00 -- SCREW MACHINE 4 Please refer to the 'Exploded View' Y M31
3 MLAK00 MLAK0006301 LABEL,MODEL 1 LG (30.5x21.54-1R) Y
3 SAKY00 -- PCB ASSY,SIDEKEY 1 Please refer to the 'Exploded View' Y M22
3 SUMY00 -- MICROPHONE 1 Please refer to the 'Exploded View' Y M24
2 SBPP00 -- BATTERY PACK,LI-POLYMER 1 Please refer to the 'Exploded View' Y Cobalt Blue M32
2 SBPP00 -- BATTERY PACK,LI-POLYMER 1 Please refer to the 'Exploded View' Y Metal Silver
2 SBPP00 -- BATTERY PACK,LI-POLYMER 1 Please refer to the 'Exploded View' Y Red
2 SNGF00 -- ANTENNA,GSM,FIXED 1 Please refer to the 'Exploded View' Y Cobalt Blue M28
2 SNGF00 -- ANTENNA,GSM,FIXED 1 Please refer to the 'Exploded View' Y Metal Silver
2 SNGF00 -- ANTENNA,GSM,FIXED 1 Please refer to the 'Exploded View' Y Red
- 102 -
< Main PCB >
Leve Location No. Part No. Description QTY Specification Service Remark
3 SAFY00 -- PCB ASSY,MAIN 1 Please refer to 'Exploded View' Y M23
4 SAFA00 SAFA0015702 PCB ASSY,MAIN,AUTO 1 65K color PCB ASSY MAIN AUTO N
5 BPF600 SFSY0012301 FILTER,SAW 1 1842.5 MHz,2.0*2.5*1.0 ,SMD ,DCS BAND Y
5 BPF601 SFSY0012201 FILTER,SAW 1 942.5 MHz,2.0*2.5*1.0 ,SMD ,GSM BAND Y
5 BPF602 SFSY0014101 FILTER,SAW 1 897 MHz,2.0*2.0*1.8 ,SMD , Y
5 C100 ECTZ0003901 CAP,TANTAL,CHIP,MAKER 1 10 uF,16V ,M ,STD ,ETC ,R/TP Y
5 C101 ECCH0000179 CAP,CERAMIC,CHIP 1 22 nF,16V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C103 ECCH0000130 CAP,CERAMIC,CHIP 1 150 pF,50V,J,SL,TC,1005,R/TP Y
5 C104 ECCH0000379 CAP,CERAMIC,CHIP 1 2.2 uF,6.3V ,K ,X5R ,HD ,2012 ,R/TP Y
5 C105 ECCH0000122 CAP,CERAMIC,CHIP 1 47 pF,50V,J,NP0,TC,1005,R/TP Y
5 C106 ECCH0000122 CAP,CERAMIC,CHIP 1 47 pF,50V,J,NP0,TC,1005,R/TP Y
5 C107 ECCH0000122 CAP,CERAMIC,CHIP 1 47 pF,50V,J,NP0,TC,1005,R/TP Y
5 C108 ECCH0000143 CAP,CERAMIC,CHIP 1 1 nF,50V,K,X7R,HD,1005,R/TP Y
5 C109 ECZH0003902 CAP,CHIP,MAKER 1 0.1 uF,50V ,K ,X7R ,HD ,2012 ,R/TP Y
5 C110 ECCH0000276 CAP,CERAMIC,CHIP 1 1 uF,10V,Z,Y5V,HD,1608,R/TP Y
5 C118 ECCH0000186 CAP,CERAMIC,CHIP 1 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP Y
5 C119 ECCH0000186 CAP,CERAMIC,CHIP 1 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP Y
5 C120 ECCH0000186 CAP,CERAMIC,CHIP 1 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP Y
5 C124 SEVY0004901 VARISTOR 1 5.6 V, ,SMD ,CAP=370pF+-30% Y
5 C202 ECCH0000114 CAP,CERAMIC,CHIP 1 20 pF,50V,J,NP0,TC,1005,R/TP Y
5 C203 ECCH0000114 CAP,CERAMIC,CHIP 1 20 pF,50V,J,NP0,TC,1005,R/TP Y
5 C204 ECCH0000113 CAP,CERAMIC,CHIP 1 18 pF,50V,J,NP0,TC,1005,R/TP Y
5 C205 ECCH0000143 CAP,CERAMIC,CHIP 1 1 nF,50V,K,X7R,HD,1005,R/TP Y
5 C206 ECCH0000161 CAP,CERAMIC,CHIP 1 33 nF,16V,K,X7R,HD,1005,R/TP Y
5 C211 ECCH0000135 CAP,CERAMIC,CHIP 1 270 pF,50V ,K ,X7R ,HD ,1005 ,R/TP Y
5 C213 ECCH0000135 CAP,CERAMIC,CHIP 1 270 pF,50V ,K ,X7R ,HD ,1005 ,R/TP Y
5 C215 ECCH0001811 CAP,CERAMIC,CHIP 1 0.22 uF,50V ,Z ,Y5V ,HD ,1005 ,R/TP Y
5 C216 ECCH0000276 CAP,CERAMIC,CHIP 1 1 uF,10V,Z,Y5V,HD,1608,R/TP Y
5 C217 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C218 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C219 ECCH0000379 CAP,CERAMIC,CHIP 1 2.2 uF,6.3V ,K ,X5R ,HD ,2012 ,R/TP Y
5 C220 ECCH0000379 CAP,CERAMIC,CHIP 1 2.2 uF,6.3V ,K ,X5R ,HD ,2012 ,R/TP Y
5 C221 ECCH0000379 CAP,CERAMIC,CHIP 1 2.2 uF,6.3V ,K ,X5R ,HD ,2012 ,R/TP Y
5 C222 ECCH0000379 CAP,CERAMIC,CHIP 1 2.2 uF,6.3V ,K ,X5R ,HD ,2012 ,R/TP Y
5 C223 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C224 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C225 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C226 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C227 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C228 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C229 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C230 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C231 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C232 ECTZ0003101 CAP,TANTAL,CHIP,MAKER 1 33 uF,10V ,M ,STD ,ETC ,R/TP Y
5 C233 ECCH0000128 CAP,CERAMIC,CHIP 1 100 pF,50V,J,NP0,TC,1005,R/TP Y
5 C234 ECCH0000379 CAP,CERAMIC,CHIP 1 2.2 uF,6.3V ,K ,X5R ,HD ,2012 ,R/TP Y
5 C300 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C301 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C304 ECCH0000161 CAP,CERAMIC,CHIP 1 33 nF,16V,K,X7R,HD,1005,R/TP Y
5 C400 ECCH0000122 CAP,CERAMIC,CHIP 1 47 pF,50V,J,NP0,TC,1005,R/TP Y
5 C401 ECCH0000379 CAP,CERAMIC,CHIP 1 2.2 uF,6.3V ,K ,X5R ,HD ,2012 ,R/TP Y
5 C402 ECCH0000122 CAP,CERAMIC,CHIP 1 47 pF,50V,J,NP0,TC,1005,R/TP Y
5 C404 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C405 ECCH0000122 CAP,CERAMIC,CHIP 1 47 pF,50V,J,NP0,TC,1005,R/TP Y
5 C406 ECCH0000122 CAP,CERAMIC,CHIP 1 47 pF,50V,J,NP0,TC,1005,R/TP Y
5 C407 ECCH0000122 CAP,CERAMIC,CHIP 1 47 pF,50V,J,NP0,TC,1005,R/TP Y
5 C408 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C409 ECCH0000122 CAP,CERAMIC,CHIP 1 47 pF,50V,J,NP0,TC,1005,R/TP Y
5 C410 ECCH0000189 CAP,CERAMIC,CHIP 1 680 pF,50V ,J ,X7R ,HD ,1005 ,R/TP Y
5 C411 ECCH0000189 CAP,CERAMIC,CHIP 1 680 pF,50V ,J ,X7R ,HD ,1005 ,R/TP Y
5 C412 ECCH0000189 CAP,CERAMIC,CHIP 1 680 pF,50V ,J ,X7R ,HD ,1005 ,R/TP Y
- 103 -
12. EXPLODED VIEW & REPLACEMENT PART LIST
Leve Location No. Part No. Description QTY Specification Service Remark
5 C413 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C414 ECCH0000122 CAP,CERAMIC,CHIP 1 47 pF,50V,J,NP0,TC,1005,R/TP Y
5 C415 ECCH0000122 CAP,CERAMIC,CHIP 1 47 pF,50V,J,NP0,TC,1005,R/TP Y
5 C416 ECCH0001811 CAP,CERAMIC,CHIP 1 0.22 uF,50V ,Z ,Y5V ,HD ,1005 ,R/TP Y
5 C417 ECCH0000379 CAP,CERAMIC,CHIP 1 2.2 uF,6.3V ,K ,X5R ,HD ,2012 ,R/TP Y
5 C418 ECCH0000179 CAP,CERAMIC,CHIP 1 22 nF,16V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C419 ECCH0000155 CAP,CERAMIC,CHIP 1 10 nF,16V,K,X7R,HD,1005,R/TP Y
5 C421 ECCH0000113 CAP,CERAMIC,CHIP 1 18 pF,50V,J,NP0,TC,1005,R/TP Y
5 C422 ECCH0000122 CAP,CERAMIC,CHIP 1 47 pF,50V,J,NP0,TC,1005,R/TP Y
5 C423 ECCH0000122 CAP,CERAMIC,CHIP 1 47 pF,50V,J,NP0,TC,1005,R/TP Y
5 C424 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C425 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C426 ECCH0000143 CAP,CERAMIC,CHIP 1 1 nF,50V,K,X7R,HD,1005,R/TP Y
5 C427 ECCH0000122 CAP,CERAMIC,CHIP 1 47 pF,50V,J,NP0,TC,1005,R/TP Y
5 C428 ECCH0000143 CAP,CERAMIC,CHIP 1 1 nF,50V,K,X7R,HD,1005,R/TP Y
5 C450 ECCH0003401 CAP,CERAMIC,CHIP 1 10 uF,6.3V ,Z ,Y5V ,HD ,2012 ,R/TP Y
5 C500 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C501 ECCH0000143 CAP,CERAMIC,CHIP 1 1 nF,50V,K,X7R,HD,1005,R/TP Y
5 C502 ECCH0000124 CAP,CERAMIC,CHIP 1 56 pF,50V,J,NP0,TC,1005,R/TP Y
5 C503 ECCH0000276 CAP,CERAMIC,CHIP 1 1 uF,10V,Z,Y5V,HD,1608,R/TP Y
5 C504 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C505 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C600 ECCH0000122 CAP,CERAMIC,CHIP 1 47 pF,50V,J,NP0,TC,1005,R/TP Y
5 C601 ECCH0000111 CAP,CERAMIC,CHIP 1 12 pF,50V,J,NP0,TC,1005,R/TP Y
5 C602 ECCH0000143 CAP,CERAMIC,CHIP 1 1 nF,50V,K,X7R,HD,1005,R/TP Y
5 C603 ECTZ0003801 CAP,TANTAL,CHIP,MAKER 1 470 uF,6.3V ,M ,L_ESR ,ETC ,R/TP Y
5 C604 ECCH0000117 CAP,CERAMIC,CHIP 1 27 pF,50V,J,NP0,TC,1005,R/TP Y
5 C605 ECCH0000111 CAP,CERAMIC,CHIP 1 12 pF,50V,J,NP0,TC,1005,R/TP Y
5 C608 ECCH0000117 CAP,CERAMIC,CHIP 1 27 pF,50V,J,NP0,TC,1005,R/TP Y
5 C609 ECCH0000117 CAP,CERAMIC,CHIP 1 27 pF,50V,J,NP0,TC,1005,R/TP Y
5 C611 ECCH0000103 CAP,CERAMIC,CHIP 1 1.5 pF,50V,C,NP0,TC,1005,R/TP Y
5 C613 ECCH0000701 CAP,CERAMIC,CHIP 1 1.2 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP Y
5 C614 ECCH0000137 CAP,CERAMIC,CHIP 1 330 pF,50V ,K ,X7R ,HD ,1005 ,R/TP Y
5 C615 ECFD0000101 CAP,FILM,MPP 1 8200 pF,16V ,J ,NI ,SMD ,2012 mm,R/TP Y
5 C619 ECCH0000143 CAP,CERAMIC,CHIP 1 1 nF,50V,K,X7R,HD,1005,R/TP Y
5 C620 ECCH0000117 CAP,CERAMIC,CHIP 1 27 pF,50V,J,NP0,TC,1005,R/TP Y
5 C621 ECCH0000117 CAP,CERAMIC,CHIP 1 27 pF,50V,J,NP0,TC,1005,R/TP Y
5 C622 ECCH0000117 CAP,CERAMIC,CHIP 1 27 pF,50V,J,NP0,TC,1005,R/TP Y
5 C623 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C624 ECCH0000379 CAP,CERAMIC,CHIP 1 2.2 uF,6.3V ,K ,X5R ,HD ,2012 ,R/TP Y
5 C625 ECFD0000601 CAP,FILM,MPP 1 1 nF,16V ,J ,NI ,SMD ,1608 mm,R/TP Y
5 C626 ECTZ0003401 CAP,TANTAL,CHIP,MAKER 1 4.7 uF,6.3V ,M ,STD ,2012 ,R/TP Y
5 C627 ECCH0000143 CAP,CERAMIC,CHIP 1 1 nF,50V,K,X7R,HD,1005,R/TP Y
5 C628 ECCH0000143 CAP,CERAMIC,CHIP 1 1 nF,50V,K,X7R,HD,1005,R/TP Y
5 C629 ECCH0000117 CAP,CERAMIC,CHIP 1 27 pF,50V,J,NP0,TC,1005,R/TP Y
5 C632 ECCH0000181 CAP,CERAMIC,CHIP 1 4.7 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP Y
5 C633 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C634 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C635 ECTZ0003401 CAP,TANTAL,CHIP,MAKER 1 4.7 uF,6.3V ,M ,STD ,2012 ,R/TP Y
5 C636 ECTZ0003101 CAP,TANTAL,CHIP,MAKER 1 33 uF,10V ,M ,STD ,ETC ,R/TP Y
5 C637 ECCH0000120 CAP,CERAMIC,CHIP 1 39 pF,50V,J,NP0,TC,1005,R/TP Y
5 C638 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C641 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C642 ECCH0000112 CAP,CERAMIC,CHIP 1 15 pF,50V,J,NP0,TC,1005,R/TP Y
5 C643 ECCH0000108 CAP,CERAMIC,CHIP 1 7 pF,50V,D,NP0,TC,1005,R/TP Y
5 C645 ECCH0000108 CAP,CERAMIC,CHIP 1 7 pF,50V,D,NP0,TC,1005,R/TP Y
5 C646 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C647 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C648 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C649 ECCH0000104 CAP,CERAMIC,CHIP 1 3 pF,50V,C,NP0,TC,1005,R/TP Y
5 C657 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C658 ECCH0000180 CAP,CERAMIC,CHIP 1 3.3 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP Y
5 C660 ECCH0000180 CAP,CERAMIC,CHIP 1 3.3 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP Y
5 C661 ECCH0000379 CAP,CERAMIC,CHIP 1 2.2 uF,6.3V ,K ,X5R ,HD ,2012 ,R/TP Y
- 104 -
12. EXPLODED VIEW & REPLACEMENT PART LIST
Leve Location No. Part No. Description QTY Specification Service Remark
5 C662 ECCH0000104 CAP,CERAMIC,CHIP 1 3 pF,50V,C,NP0,TC,1005,R/TP Y
5 C663 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C664 ECCH0000379 CAP,CERAMIC,CHIP 1 2.2 uF,6.3V ,K ,X5R ,HD ,2012 ,R/TP Y
5 C665 ECCH0000155 CAP,CERAMIC,CHIP 1 10 nF,16V,K,X7R,HD,1005,R/TP Y
5 C666 ECCH0000143 CAP,CERAMIC,CHIP 1 1 nF,50V,K,X7R,HD,1005,R/TP Y
5 C667 ECCH0000143 CAP,CERAMIC,CHIP 1 1 nF,50V,K,X7R,HD,1005,R/TP Y
5 C669 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C670 ECCH0000144 CAP,CERAMIC,CHIP 1 1.2 nF,50V,K,X7R,HD,1005,R/TP Y
5 C671 ECFD0000701 CAP,FILM,MPP 1 12 nF,16V ,J ,NI ,SMD ,3216 mm,R/TP Y
5 C672 ECCH0000248 CAP,CERAMIC,CHIP 1 1.2 nF,50V,K,X7R,HD,1608,R/TP Y
5 C673 ECCH0000256 CAP,CERAMIC,CHIP 1 5.6 nF,50V,K,X7R,HD,1608,R/TP Y
5 C674 ECFD0000601 CAP,FILM,MPP 1 1 nF,16V ,J ,NI ,SMD ,1608 mm,R/TP Y
5 C675 ECCH0000143 CAP,CERAMIC,CHIP 1 1 nF,50V,K,X7R,HD,1005,R/TP Y
5 C679 ECCH0000111 CAP,CERAMIC,CHIP 1 12 pF,50V,J,NP0,TC,1005,R/TP Y
5 C680 ECCH0000143 CAP,CERAMIC,CHIP 1 1 nF,50V,K,X7R,HD,1005,R/TP Y
5 C681 ECCH0000181 CAP,CERAMIC,CHIP 1 4.7 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP Y
5 C682 ECCH0000181 CAP,CERAMIC,CHIP 1 4.7 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP Y
5 C683 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C685 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 C686 ECCH0000111 CAP,CERAMIC,CHIP 1 12 pF,50V,J,NP0,TC,1005,R/TP Y
5 C687 ECCH0000379 CAP,CERAMIC,CHIP 1 2.2 uF,6.3V ,K ,X5R ,HD ,2012 ,R/TP Y
5 C690 ECCH0000101 CAP,CERAMIC,CHIP 1 0.5 pF,50V,C,NP0,TC,1005,R/TP Y
5 C691 ECCH0000144 CAP,CERAMIC,CHIP 1 1.2 nF,50V,K,X7R,HD,1005,R/TP Y
5 C692 ECCH0000143 CAP,CERAMIC,CHIP 1 1 nF,50V,K,X7R,HD,1005,R/TP Y
5 C698 ECCH0000182 CAP,CERAMIC,CHIP 1 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP Y
5 D100 EDSY0005201 DIODE,SWITCHING 1 SMD ,30 V,1.5 A,R/TP , Y
5 D200 EDSY0010401 DIODE,SWITCHING 1 1-1G1A ,40 V,300 A,R/TP ,Silicon Epitaxial Schottky Barrier Type Diode Y
5 D201 EDSY0010401 DIODE,SWITCHING 1 1-1G1A ,40 V,300 A,R/TP ,Silicon Epitaxial Schottky Barrier Type Diode Y
5 D202 EDSY0010401 DIODE,SWITCHING 1 1-1G1A ,40 V,300 A,R/TP ,Silicon Epitaxial Schottky Barrier Type Diode Y
5 D401 EDSY0009901 DIODE,SWITCHING 1 ESC ,80 V,300 A,R/TP ,1.6*0.8*0.6(t) Y
5 D501 EDLH0004502 DIODE,LED,CHIP 1 BLUE ,1608 ,R/TP ,0.35T Y
5 D502 EDLH0004502 DIODE,LED,CHIP 1 BLUE ,1608 ,R/TP ,0.35T Y
5 D503 EDLH0004502 DIODE,LED,CHIP 1 BLUE ,1608 ,R/TP ,0.35T Y
5 D505 EDLH0004502 DIODE,LED,CHIP 1 BLUE ,1608 ,R/TP ,0.35T Y
5 D506 EDLH0004502 DIODE,LED,CHIP 1 BLUE ,1608 ,R/TP ,0.35T Y
5 D507 EDLH0004502 DIODE,LED,CHIP 1 BLUE ,1608 ,R/TP ,0.35T Y
5 D508 EDLH0004502 DIODE,LED,CHIP 1 BLUE ,1608 ,R/TP ,0.35T Y
5 D511 EDLH0004502 DIODE,LED,CHIP 1 BLUE ,1608 ,R/TP ,0.35T Y
5 D512 EDLH0004502 DIODE,LED,CHIP 1 BLUE ,1608 ,R/TP ,0.35T Y
5 D513 EDLH0004502 DIODE,LED,CHIP 1 BLUE ,1608 ,R/TP ,0.35T Y
5 D514 EDLH0004502 DIODE,LED,CHIP 1 BLUE ,1608 ,R/TP ,0.35T Y
5 D517 EDLH0004502 DIODE,LED,CHIP 1 BLUE ,1608 ,R/TP ,0.35T Y
5 D518 EDLH0004502 DIODE,LED,CHIP 1 BLUE ,1608 ,R/TP ,0.35T Y
5 D519 EDLH0004502 DIODE,LED,CHIP 1 BLUE ,1608 ,R/TP ,0.35T Y
5 D520 EDLH0004502 DIODE,LED,CHIP 1 BLUE ,1608 ,R/TP ,0.35T Y
5 D521 EDSY0005301 DIODE,SWITCHING 1 SC-70 ,80 V,0.1 A,R/TP , Y
5 D600 EDSY0010301 DIODE,SWITCHING 1 SOT-143 ,4 V,.11 A,R/TP ,Silicon Dual Schottky Diode Y
5 D601 EDVY0001201 DIODE,VARIABLE CAP 1 UFP ,4.65 pF,R/TP ,diode capacitance:C1:4.65~5.15pF/C4:1.85~2.15pF Y
5 D602 EDVY0001401 DIODE,VARIABLE CAP 1 CMPAK ,4.50 pF,R/TP ,diode capacitance:C1:4.50~5.00pF/C3:1.85~2.80pF Y
5 HSP402 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 J100 ENSY0007601 CONN,SOCKET 1 6 PIN,ETC ,SOCKET ,2.54 mm,G7000 SIM CNT (2.4t) Y
5 J101 ENRY0000901 CONNECTOR,I/O 1 24 PIN,0.5 mm,ETC , , Y
5 J102 ENBY0010901 CONNECTOR,BOARD TO BOARD 1 30 PIN,0.5 mm,STRAIGHT , ,B to B CNT (HEAER) Y
5 J400 ENJE0002301 CONN,JACK/PLUG,EARPHONE 1 3,5 PIN,G7000 EAR JACK 3 pole, 5 pin KSD Y
5 L100 SFBH0007102 FILTER,BEAD,CHIP 1 10 ohm,1005 ,Ferrite Bead Y
5 L102 SFBH0007102 FILTER,BEAD,CHIP 1 10 ohm,1005 ,Ferrite Bead Y
5 L103 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L104 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L105 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L106 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L107 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L108 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L109 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L110 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
- 105 -
12. EXPLODED VIEW & REPLACEMENT PART LIST
Leve Location No. Part No. Description QTY Specification Service Remark
5 L111 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L112 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L113 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L114 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L115 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L116 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L117 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L118 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L119 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L120 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L124 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L190 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L500 ELCH0005009 INDUCTOR,CHIP 1 100 nH,J ,1005 ,R/TP , Y
5 L502 ELCH0005009 INDUCTOR,CHIP 1 100 nH,J ,1005 ,R/TP , Y
5 L600 ECCH0000112 CAP,CERAMIC,CHIP 1 15 pF,50V,J,NP0,TC,1005,R/TP Y
5 L601 ELCH0005003 INDUCTOR,CHIP 1 12 nH,J ,1005 ,R/TP , Y
5 L602 ELCH0005002 INDUCTOR,CHIP 1 2.7 nH,S ,1005 ,R/TP , Y
5 L603 ELCH0005002 INDUCTOR,CHIP 1 2.7 nH,S ,1005 ,R/TP , Y
5 L605 ELCH0001402 INDUCTOR,CHIP 1 18 nH,J,1005,R/TP Y
5 L606 ELCH0001402 INDUCTOR,CHIP 1 18 nH,J,1005,R/TP Y
5 L608 ELCH0001405 INDUCTOR,CHIP 1 3.3 nH,S,1005,R/TP Y
5 L609 ELCH0005012 INDUCTOR,CHIP 1 3.9 nH,S ,1005 ,R/TP , Y
5 L610 SFBH0007101 FILTER,BEAD,CHIP 1 120 ohm,1005 ,Ferrite Bead Y
5 L611 ELCH0001003 INDUCTOR,CHIP 1 6.8 nH,J,1005,R/TP Y
5 L612 ELCH0001003 INDUCTOR,CHIP 1 6.8 nH,J,1005,R/TP Y
5 L632 ELCH0001405 INDUCTOR,CHIP 1 3.3 nH,S,1005,R/TP Y
5 L633 ELCH0001405 INDUCTOR,CHIP 1 3.3 nH,S,1005,R/TP Y
5 L635 ELCH0005013 INDUCTOR,CHIP 1 4.7 nH,S ,1005 ,R/TP , Y
5 N600 SCHY0000101 COUPLER,RF HYBRID 1 19.0 dB,0.35 dB,24.0 dB,2.0*1.25*0.95 ,SMD ,DUAL COUPLER Y
5 Q100 EQFP0003301 TR,FET,P-CHANNEL 1 SOT-6 ,1.6 W,30 V,2.4 A,R/TP ,use for charge P- CHANNEL FET Y
5 Q101 EQBN0007001 TR,BJT,NPN 1 SC-70 ,0.1 W,R/TP , Y
5 Q500 EQBN0004801 TR,BJT,NPN 1 SMT6 ,0.2 W,R/TP , Y
5 Q502 EQBN0007001 TR,BJT,NPN 1 SC-70 ,0.1 W,R/TP , Y
5 Q503 EQBN0007001 TR,BJT,NPN 1 SC-70 ,0.1 W,R/TP , Y
5 Q504 EQBN0007001 TR,BJT,NPN 1 SC-70 ,0.1 W,R/TP , Y
5 Q506 EQBN0007101 TR,BJT,NPN 1 EMT3 ,0.15 W,R/TP ,LOW FREQUENCY Y
5 R100 ERHY0000265 RES,CHIP 1 20K ohm,1/16W,J,1005,R/TP Y
5 R101 ERHY0000265 RES,CHIP 1 20K ohm,1/16W,J,1005,R/TP Y
5 R102 ERHY0000299 RES,CHIP 1 33000 ohm,1/16W ,J ,1005 ,R/TP Y
5 R103 ERNR0000403 RES,ARRAY,R 1 10000 ohm, ohm,8 PIN,J ,1/32 W ,SMD ,R/TP Y
5 R104 ERHY0000261 RES,CHIP 1 10K ohm,1/16W,J,1005,R/TP Y
5 R105 ERHY0000220 RES,CHIP 1 100 ohm,1/16W,J,1005,R/TP Y
5 R106 ERNR0000401 RES,ARRAY,R 1 47 ohm, ohm,8 PIN,J ,1/32 W ,SMD ,R/TP Y
5 R107 ERHY0000202 RES,CHIP 1 4.7 ohm,1/16W,J,1005,R/TP Y
5 R108 ERHY0000202 RES,CHIP 1 4.7 ohm,1/16W,J,1005,R/TP Y
5 R109 ERHY0000226 RES,CHIP 1 220 ohm,1/16W,J,1005,R/TP Y
5 R110 ERNR0000401 RES,ARRAY,R 1 47 ohm, ohm,8 PIN,J ,1/32 W ,SMD ,R/TP Y
5 R111 ERHY0000241 RES,CHIP 1 1K ohm,1/16W,J,1005,R/TP Y
5 R112 ERNR0000401 RES,ARRAY,R 1 47 ohm, ohm,8 PIN,J ,1/32 W ,SMD ,R/TP Y
5 R114 ERHY0000296 RES,CHIP 1 1M ohm,1/16W,J,1005,R/TP Y
5 R115 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R116 ERHY0001102 RES,CHIP 1 0.2 ohm,1/4W ,F ,2012 ,R/TP Y
5 R117 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R118 ERHY0000250 RES,CHIP 1 3.3K ohm,1/16W,J,1005,R/TP Y
5 R120 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R121 ERHY0000250 RES,CHIP 1 3.3K ohm,1/16W,J,1005,R/TP Y
5 R122 ERHY0000261 RES,CHIP 1 10K ohm,1/16W,J,1005,R/TP Y
5 R123 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R124 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R150 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R151 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R152 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R201 ERHY0000287 RES,CHIP 1 220K ohm,1/16W,J,1005,R/TP Y
5 R202 ERHY0000299 RES,CHIP 1 33000 ohm,1/16W ,J ,1005 ,R/TP Y
- 106 -
12. EXPLODED VIEW & REPLACEMENT PART LIST
Leve Location No. Part No. Description QTY Specification Service Remark
5 R203 ERHY0000261 RES,CHIP 1 10K ohm,1/16W,J,1005,R/TP Y
5 R204 ERHY0000231 RES,CHIP 1 390 ohm,1/16W,J,1005,R/TP Y
5 R205 ERHY0000231 RES,CHIP 1 390 ohm,1/16W,J,1005,R/TP Y
5 R206 ERHY0000231 RES,CHIP 1 390 ohm,1/16W,J,1005,R/TP Y
5 R207 ERHY0000231 RES,CHIP 1 390 ohm,1/16W,J,1005,R/TP Y
5 R208 ERHY0000265 RES,CHIP 1 20K ohm,1/16W,J,1005,R/TP Y
5 R209 ERHY0000296 RES,CHIP 1 1M ohm,1/16W,J,1005,R/TP Y
5 R211 ERHY0000265 RES,CHIP 1 20K ohm,1/16W,J,1005,R/TP Y
5 R219 ERHY0000282 RES,CHIP 1 120K ohm,1/16W,J,1005,R/TP Y
5 R220 ERHY0000261 RES,CHIP 1 10K ohm,1/16W,J,1005,R/TP Y
5 R222 ERHY0000261 RES,CHIP 1 10K ohm,1/16W,J,1005,R/TP Y
5 R225 ERHY0000296 RES,CHIP 1 1M ohm,1/16W,J,1005,R/TP Y
5 R227 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R228 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R229 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R231 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R250 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R280 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R281 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R282 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R283 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R300 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R302 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R303 ERHY0000201 RES,CHIP 1 0 ohm,1/16W,J,1005,R/TP Y
5 R305 ERHY0000261 RES,CHIP 1 10K ohm,1/16W,J,1005,R/TP Y
5 R400 ERHY0000241 RES,CHIP 1 1K ohm,1/16W,J,1005,R/TP Y
5 R401 ERHY0006701 RES,CHIP 1 2400 ohm,1/16W ,J ,1005 ,R/TP Y
5 R402 ERHY0000243 RES,CHIP 1 1.2K ohm,1/16W,J,1005,R/TP Y
5 R404 ERHY0000264 RES,CHIP 1 18K ohm,1/16W,J,1005,R/TP Y
5 R405 ERHY0000280 RES,CHIP 1 100K ohm,1/16W,J,1005,R/TP Y
5 R407 ERHY0000286 RES,CHIP 1 200K ohm,1/16W,J,1005,R/TP Y
5 R408 ERHY0000202 RES,CHIP 1 4.7 ohm,1/16W,J,1005,R/TP Y
5 R409 ERHY0000202 RES,CHIP 1 4.7 ohm,1/16W,J,1005,R/TP Y
5 R410 ERHY0000202 RES,CHIP 1 4.7 ohm,1/16W,J,1005,R/TP Y
5 R414 ERHY0000299 RES,CHIP 1 33000 ohm,1/16W ,J ,1005 ,R/TP Y
5 R415 ERHY0000271 RES,CHIP 1 39K ohm,1/16W,J,1005,R/TP Y
5 R417 ERHY0000261 RES,CHIP 1 10K ohm,1/16W,J,1005,R/TP Y
5 R418 ERHY0000250 RES,CHIP 1 3.3K ohm,1/16W,J,1005,R/TP Y
5 R419 ERHY0000258 RES,CHIP 1 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
