Image preview - the first page of the document



>> Download LG W3000 2 documenatation <<

Text preview - extract from the document

5. DISASSEMBLY AND ASSEMBLY INSTRUCTION



5. DISASSEMBLY AND ASSEMBLY INSTRUCTION

 5.1 Disassembly
     1. Remove the battery, as shown below.




                                      Figure 5-1. Removing the Battery

     2. Open the cap earphonejack first and push the hook. Then, hold and twist the Front cover.




                                    Figure 5-2. Removing the Cover front




                                               - 98 -
                                      5. DISASSEMBLY AND ASSEMBLY INSTRUCTION



3. Carefully remove the screws, then lift up the both end side of the Cover guide as shown below.




                            Figure 5-3. Disassembly of the Cover guide.

4. Detach the rest components as shown below.




                         Figure 5-4. Disassembly of the rest components




                                          - 99 -
5. DISASSEMBLY AND ASSEMBLY INSTRUCTION



     5. Detach the Speaker as shown below to unlock PCB.




                                    Figure 5-5. Removing PCB & Antenna

     6. Use a tweezers to remove the Battery locker.




                          1             1

                          2                                                 3




                                  Figure 5-6. Removing the Battery locker


                                              - 100 -
                                        5. DISASSEMBLY AND ASSEMBLY INSTRUCTION



5.2 Assembly
   7. Carefully insert the Speaker into PCB as shown below. Black line of Speaker must be above .




                                Figure 5-7. Assembly of PCB & Antenna

   8. Attach the Speaker and Receiver properly, then assemble the rest components.




                 Figure 5-8. Assembly of the Speaker, Receiver and rest components.




                                            - 101 -
5. DISASSEMBLY AND ASSEMBLY INSTRUCTION




     9. Assemble the Rear cover, PCB and Cover guide. Then, attach screws.




                      Figure 5-9. Assembly of the Rear cover, PCB and Cover guide




                                            - 102 -
                                       5. DISASSEMBLY AND ASSEMBLY INSTRUCTION




10. Insert the hooks at the bottom of the Front cover into the Rear cover .Then, assemble the Front
    cover and Rear cover as shown below.




                     Firure 5-10. Assembly of the Front cover and Rear cover




                                          - 103 -
