Image preview - the first page of the document
>> Download LG W7000 3 documenatation <<
Text preview - extract from the document
12. EXPLODED VIEW & REPLACEMENT PART LIST
12. EXPLODED VIEW & REPLACEMENT PART LIST
12.1 Exploded View
M33
M36 M37
M32 M35
M26
M25 M30
M23
M22
M34
M19
M31
M15 M16
M13 M14
M29
M12 M24 M27
M21 M28
M6 M20
M3 M18
M1 M10 M17
M5
M11
M7
M9
M8
M2
M4
- 97 -
http://getMANUAL.com
12. EXPLODED VIEW & REPLACEMENT PART LIST
< Parts List Of Exploded View >
No. Location No. Part No. Description QTY Specification Color Service Remark
M1 AWAB01 AWAB0003001 WINDOW ASSY,LCD (SUB) 1 G7000 Sub LCD Window Assy Yes
M2 MIAA00 MIAA0003901 INDICATOR,LED 1 G7000 Yes
M3 ACGJ00 ACGJ0011703 COVER ASSY,FOLDER(UPPER) 1 Titanium Yes
ACGJ0011702 COVER ASSY,FOLDER(UPPER) 1 Cobalt Blue Yes
ACGJ0011701 COVER ASSY,FOLDER(UPPER) 1 Pearl White Yes
M4 MPFF00 MPFF0000101 PLATE,LOGO 1 GT-9771 HANDSET_FLIP DX A A Yes
M5 MHFD00 MHFD0002101 HINGE,FOLDER 1 G7000 5 PHI Yes
M6 SVLM00 SVLM0003201 LCD MODULE 1 MAIN:32.174*42.31,SUB:23.16*18.12 Yes
M7 SUSY00 SUSY0006001 SPEAKER 1 ASSY ,8 ohm,86 dB,15 mm,G7000 SPEAKER Yes
M8 SURY00 SURY0005301 RECEIVER 1 UNIT ,99 dB,32 ohm,13*2.7 ,G7000 Receiver Yes
M9 SJMY00 SJMY0002801 VIBRATOR,MOTOR 1 3.0 V,80 mA,12*15 ,height 2.7+0.1T Yes
M10 SBCL00 SBCL0001001 BATTERY,CELL,LITHIUM 1 3 V,1.2 mAh,COIN ,ASAHI BATTERY (ML414NB/F9D) Yes
M11 SACY00 SACY0004601 PCB ASSY,FLEXIBLE 1 G7000 Receiver Yes
M12 SACY01 SACY0004501 PCB ASSY,FLEXIBLE 1 G7000 LCD Yes
M13 MGAD01 MGAD0006001 GASKET,SHIELD FORM 2 G7000 10x5x1.5t Yes
M14 ACGH00 ACGH0006703 COVER ASSY,FOLDER(LOWER) 1 Yes
M15 GMZZ00 GMZZ0003201 SCREW MACHINE 2 3.5 mm,3.5 mm,MSWR3(FN) ,N ,STR ,- , M1.7X3.5 DIA3.5 Yes
M16 MCCH00 MCCH0003903 CAP,SCREW 2 Titanium Yes
MCCH0003902 CAP,SCREW 2 Cobalt Blue Yes
MCCH0003901 CAP,SCREW 2 Pearl White Yes
M17 MBHY00 MBHY0003503 BUMPER 2 LG-510,511,512 METALIC SILVER DIA 2.4 Yes
M18 AWAB00 AWAB0002901 WINDOW ASSY,LCD 1 G7000 MAIN LCD ASSY, LG Brand, Pearl White Color Yes
M19 ABGC00 ABGC0000701 BUTTON ASSY,SIDE 1 G7000 Yes
M20 ACGK00 ACGK0014703 COVER ASSY,FRONT 1 Titanium Yes
ACGK0014702 COVER ASSY,FRONT 1 Cobalt Blue Yes
ACGK0014701 COVER ASSY,FRONT 1 Pearl White Yes
M21 MDAC00 MDAC0005001 DECO,SIDE 2 G7000 Yes
M22 MCCC00 MCCC0003501 CAP,EARPHONE JACK 1 G7000 Pearl White Color Titanium Yes
MCCC0003502 CAP,EARPHONE JACK 1 G7000 Cobalt Blue Yes
MCCC0003501 CAP,EARPHONE JACK 1 G7000 Pearl White Yes
M23 ABGA00 ABGA0000401 BUTTON ASSY,DIAL 1 G7000 Yes
M24 ADCA00 ADCA0006001 DOME ASSY,METAL 1 G7000 Yes
M25 SAKY00 SAKY0001101 PCB ASSY,SIDEKEY 1 G7000 Yes
M26 SAFY00 SAFY0050101 PCB ASSY,MAIN 1 G7000, GPRS, Blue LED, MAIN PCB(V1.11), EUA_CHN Yes
M27 SUMY00 SUMY0003503 MICROPHONE 1 FPCB ,-40 dB,6*1.8 ,TOLERANCE ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
