Image preview - the first page of the document
>> Download CH480_9 documenatation <<
Text preview - extract from the document
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
MODEL: 1466LRs DATE: 1999. 6. 5.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION REMARK
MAIN BOARD
CAPACITORs
C203 0CC3300K415 CAPACITOR, CERAMIC (TEMP. COMPENSATE), 33P 50V J NP0 TP
C204 0CK1010K515 CAPACITOR, CERAMIC (HIGH DIELECTRIC), 100PF 50V K B TR
C206 0CK1040K945 CAPACITOR, CERAMIC (HIGH DIELECTRIC), 0.1UF 50V Z F TR
C207 0CE1066F618 CAPACITOR, AL.ELECTROLYTIC, 0UF SMS 16V M FL TP5
C208 0CE1066F618 CAPACITOR, AL.ELECTROLYTIC, 0UF SMS 16V M FL TP5
C401 0CN2210K519 CAPACITOR, TUBULAR(HIGH DIELEC), 220P 50V K B TA52
C402 0CN2210K519 CAPACITOR, TUBULAR(HIGH DIELEC), 220P 50V K B TA52
C403 0CN2210K519 CAPACITOR, TUBULAR(HIGH DIELEC), 220P 50V K B TA52
C404 0CN2210K519 CAPACITOR, TUBULAR(HIGH DIELEC), 220P 50V K B TA52
C601 0CE4766K618 CAPACITOR, AL.ELECTROLYTIC, 47M SMS 50V M FM5 TP(5)
C602 0CE4776H630 CAPACITOR, AL.ELECTROLYTIC, 47OM SMS 25V M FM5
C603 0CN2210K519 CAPACITOR, TUBULAR(HIGH DIELEC), 220P 50V K B TA52
C604 0CE1056P618 CAPACITOR, AL.ELECTROLYTIC, U SMS 160V M FM5 TP5
C605 0CE1066K618 CAPACITOR, AL.ELECTROLYTIC, 0M SMS 50V M FM5 TP(5)
C611 181-288D CAPACITOR, POLYESTER, MKT 100V 473JTR PHS26473
C701 181-288B CAPACITOR, POLYESTER, MKT 100V 104JTR PHS26104
C702 0CC4710K405 CAPACITOR, CERAMIC (TEMP. COMPENSATE), 470P 50V J SL TP
C703 181-288C CAPACITOR, POLYESTER, MKT 100V 224JTR PHS 26224
C704 0CE1066F618 CAPACITOR, AL.ELECTROLYTIC, 0UF SMS 16V M FL TP5
C705 181-288T CAPACITOR, POLYESTER, MKT 100V 223KTR PHS85223
C706 181-288D CAPACITOR, POLYESTER, MKT 100V 473JTR PHS26473
C707 0CK1040K945 CAPACITOR, CERAMIC (HIGH DIELECTRIC), 0.1UF 50V Z F TR
C708 181-314C CAPACITOR, AL.ELECTROLYTIC, 47UF SMSHR (12.5*20) 100V M VNSN BULK
C709 0CK1040K945 CAPACITOR, CERAMIC (HIGH DIELECTRIC), 0.1UF 50V Z F TR
C710 0CQ2221N419 CAPACITOR, POLYESTER, 2200PF 100V J PE NI TP
C711 0CQ1031N419 CAPACITOR, POLYESTER, 0.01U 100V J POLY NI TP
C712 0CE1076F618 CAPACITOR, AL.ELECTROLYTIC, 00UF SMS 16V M TP(5)
C713 181-288T CAPACITOR, POLYESTER, MKT 100V 223KTR PHS85223
C714 0CE4756P618 CAPACITOR, AL.ELECTROLYTIC, 4.7U SMS 160V M FM5 TP5
C715 0CE2276F618 CAPACITOR, AL.ELECTROLYTIC, 220UF SMS 16V M FL TP5
C716 0CE2276F618 CAPACITOR, AL.ELECTROLYTIC, 220UF SMS 16V M FL TP5
C717 181-305U CAPACITOR, POLYPROPYLENE, 364J 19.0*19.0*12.0*10.0 250V J MPP FM10
C718 181-308N CAPACITOR, POLYPROPYLENE, 103J 19.5*13.5*7.5*10.0 630V J PU FM10
C719 181-309X CAPACITOR, POLYPROPYLENE, 542J 31.0*17.0*10.0*20.0 1.6KV J BUP FM20
C720 0CQ1021N419 CAPACITOR, POLYESTER, 1000P 100V J POLY NI TP
C721 0CK1040K945 CAPACITOR, CERAMIC (HIGH DIELECTRIC), 0.1UF 50V Z F TR
C722 0CE2266F618 CAPACITOR, AL.ELECTROLYTIC, 22M SMS 16V M FM5 TP(5)
C723 181-288M CAPACITOR, POLYESTER, MKT 63V 105KTR PHS15105
C724 0CE1076F618 CAPACITOR, AL.ELECTROLYTIC, 00UF SMS 16V M TP(5)
C725 0CK4730K945 CAPACITOR, CERAMIC (HIGH DIELECTRIC), 0.047UF 50V Z F TR
C726 0CK4730K945 CAPACITOR, CERAMIC (HIGH DIELECTRIC), 0.047UF 50V Z F TR
C727 181-288T CAPACITOR, POLYESTER, MKT 100V 223KTR PHS85223
C729 181-305D CAPACITOR, POLYPROPYLENE, 184J 19.0*15.0*8.5*10.0 250V J MPP FM10
C730 181-305U CAPACITOR, POLYPROPYLENE, 364J 19.0*19.0*12.0*10.0 250V J MPP FM10
C731 0CE1056K618 CAPACITOR, AL.ELECTROLYTIC, .0U SMS 50V M FM5 TP5
C732 0CE1056K618 CAPACITOR, AL.ELECTROLYTIC, .0U SMS 50V M FM5 TP5
C733 0CK1040K945 CAPACITOR, CERAMIC (HIGH DIELECTRIC), 0.1UF 50V Z F TR
C734 0CE3366K618 CAPACITOR, AL.ELECTROLYTIC, 33M SMS 50V M FM(5) TP(5)
C802 0CE1056K618 CAPACITOR, AL.ELECTROLYTIC, .0U SMS 50V M FM5 TP5
C903 0CBZTBU002B CAPACITOR, POLYESTER, BULK PCX2 335 474K
C904 181-296F CAPACITOR, AL.ELECTROLYTIC, 330UF SMH(30*40) 400V M VNSN BULK
C905 181-292D CAPACITOR, POLYPROPYLENE, 473J 19.0*17.0*10.0*10.0 800V J MPP FM10
C907 0CE1056N618 CAPACITOR, AL.ELECTROLYTIC, .0M SMS 100V M FM(5) TP(5)
C908 0CE1076H618 CAPACITOR, AL.ELECTROLYTIC, 00M SMS 25V M FM5 TP(5)
C909 0CK5610K515 CAPACITOR, CERAMIC (HIGH DIELECTRIC), 560P 50V K B TS
C910 0CE2276H618 CAPACITOR, AL.ELECTROLYTIC, 220U SMS 25V M FM5 TP(5)
- 35 -
MODEL: 1466LRs DATE: 1999. 6. 5.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION REMARK
C911 0CK6810W515 CAPACITOR, CERAMIC (HIGH DIELECTRIC), 680P 500V K B TS
C912 0CE3356N618 CAPACITOR, AL.ELECTROLYTIC, 3.3M SMS 100V M FM5 TP5
C914 0CE476CN618 CAPACITOR, AL.ELECTROLYTIC, 47UF SHL 100V M FL TP5
C918 0CE106CP618 CAPACITOR, AL.ELECTROLYTIC, 0U SHL 160V M FL TP5
C919 0CE4776F618 CAPACITOR, AL.ELECTROLYTIC, 470U SMS 16V M FM5 TP5
C920 0CE1086F630 CAPACITOR, AL.ELECTROLYTIC, 000M SMS 16V M FM5
C921 0CE2276K630 CAPACITOR, AL.ELECTROLYTIC, 220M SMS 50V M FM5
C922 0CE2276F618 CAPACITOR, AL.ELECTROLYTIC, 220UF SMS 16V M FL TP5
C923 0CE476CQ630 CAPACITOR, AL.ELECTROLYTIC, 47UF SHL 200V M FM5 BULK
C924 0CE3366P630 CAPACITOR, AL.ELECTROLYTIC, 33UF SMS,SG 160V M FM5 BULK
C925 0CE107CP630 CAPACITOR, AL.ELECTROLYTIC, 00UF SHL 160V M FM5 BULK
C926 0CE107CP630 CAPACITOR, AL.ELECTROLYTIC, 00UF SHL 160V M FM5 BULK
C926-1 0CE107CP630 CAPACITOR, AL.ELECTROLYTIC, 00UF SHL 160V M FM5 BULK
C930 0CE2276F618 CAPACITOR, AL.ELECTROLYTIC, 220UF SMS 16V M FL TP5
C932 0CE2266F618 CAPACITOR, AL.ELECTROLYTIC, 22M SMS 16V M FM5 TP(5)
C933 0CC3300K415 CAPACITOR, CERAMIC (TEMP. COMPENSATE), 33P 50V J NP0 TP
C934 0CE4766F618 CAPACITOR, AL.ELECTROLYTIC, 47U SMS 16V M FM5 TP5
DIODEs
D203 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D401 0DZ510009AB DIODE, ZENER, MTZ5.1B TP ROHM-K DO34 500MW 5.1V 20MA
D402 0DZ510009AB DIODE, ZENER, MTZ5.1B TP ROHM-K DO34 500MW 5.1V 20MA
D403 0DZ510009AB DIODE, ZENER, MTZ5.1B TP ROHM-K DO34 500MW 5.1V 20MA
D404 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D405 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D406 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D407 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D702 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D704 0DD100009DE DIODE, RECTIFIER, RGP10G TP G.I DO204AL 400V 1A 30A 150NS 5UA
D706 0DD100009DE DIODE, RECTIFIER, RGP10G TP G.I DO204AL 400V 1A 30A 150NS 5UA
D707 0DD100009DE DIODE, RECTIFIER, RGP10G TP G.I DO204AL 400V 1A 30A 150NS 5UA
D708 0DD400000AE DIODE, RECTIFIER, RG4A BK SANKEN R-TMD 600V 1A 50A 0.1US 500UA
D709 0DD400000AB DIODE, RECTIFIER, RU4DS BK SANKEN L-TMD6.5 1500V 1.5A 50A 0.4US 50
D710 0DD100009DE DIODE, RECTIFIER, RGP10G TP G.I DO204AL 400V 1A 30A 150NS 5UA
D713 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D714 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D715 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D718 0DZ110009AD DIODE, ZENER, MTZJ11B TP ROHM-K DO34 500MW 11V 5MA
D719 0DZ110009AD DIODE, ZENER, MTZJ11B TP ROHM-K DO34 500MW 11V 5MA
D777 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D801 0DZ270009GE DIODE, ZENER, MTZJ27D TP ROHM-K DO34 0.5W 27V 5MA .PF
D901 0DD260000BD DIODE, BRIDGE, D2SBA60 BK SHINDENGEN 600V 1.5A 60A 10UA
D902 0DD100009DA DIODE, RECTIFIER, RGP10J TP G.I DO204AL 600V 1A 30A 250NS 5UA
D903 0DD100009DE DIODE, RECTIFIER, RGP10G TP G.I DO204AL 400V 1A 30A 150NS 5UA
D904 0DD100009DD DIODE, RECTIFIER, RGP10D TP G.I DO204AL 200V 1A 30A 150NS 5UA
D905 0DD100009DD DIODE, RECTIFIER, RGP10D TP G.I DO204AL 200V 1A 30A 150NS 5UA
D906 0DD100009DE DIODE, RECTIFIER, RGP10G TP G.I DO204AL 400V 1A 30A 150NS 5UA
D907 0DD100009AH DIODE, RECTIFIER, ES1FV(1) TP SANKEN E/EO-TMD 1500V 0.5A 20A 1.5US 1
D908 0DD300009AD DIODE, RECTIFIER, RU3CV(1) TP SANKEN R-TMD 1000V 1.5A 20A 0.4US 10
D909 0DD100009DA DIODE, RECTIFIER, RGP10J TP G.I DO204AL 600V 1A 30A 250NS 5UA
D910 0DD300009AD DIODE, RECTIFIER, RU3CV(1) TP SANKEN R-TMD 1000V 1.5A 20A 0.4US 10
D911 0DD100009DE DIODE, RECTIFIER, RGP10G TP G.I DO204AL 400V 1A 30A 150NS 5UA
D912 0DD300900AB DIODE, RECTIFIER, SB30-09 BK SANYO TO220 90V 3A 40A 30NS 0.2MA
D913 0DD150009CB DIODE, RECTIFIER, RGP15D TP G.I DO204AC 200V 1.5A 50A 150NS 5UA
D914 0DD150009CB DIODE, RECTIFIER, RGP15D TP G.I DO204AC 200V 1.5A 50A 150NS 5UA
D915 0DD400609AA DIODE, SWITCHING, 1N4006GP TP G.I DO204AL 800V 1A 30A 2US 5UA
D916 0DD400609AA DIODE, SWITCHING, 1N4006GP TP G.I DO204AL 800V 1A 30A 2US 5UA
D917 0DD400609AA DIODE, SWITCHING, 1N4006GP TP G.I DO204AL 800V 1A 30A 2US 5UA
D918 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D919 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D920 0DD100009DA DIODE, RECTIFIER, RGP10J TP G.I DO204AL 600V 1A 30A 250NS 5UA
D921 0DD100009DA DIODE, RECTIFIER, RGP10J TP G.I DO204AL 600V 1A 30A 250NS 5UA
D922 0DD100009DA DIODE, RECTIFIER, RGP10J TP G.I DO204AL 600V 1A 30A 250NS 5UA
D923 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D925 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
- 36 -
MODEL: 1466LRs DATE: 1999. 6. 5.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION REMARK
D926 0DZ560009CE DIODE, ZENER, MTZJ5.6B TP ROHM-K DO34 500MW 5.6V 5MA 26MM
D931 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D932 0DZ820009AH DIODE, ZENER, MTZJ8.2B TP ROHM-K DO34 500MW 8.2V 5MA
D933 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D934 0DZ620009BB DIODE, ZENER, MTZJ6.2B TP ROHM-K DO34 0.5W 6.2V 5MA .PF
D935 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
ICs
IC201 167-099A IC[HYBRID ], RC ARRAY (11P)
IC202 0IGS080010A IC, LG SEMICONDUCTOR, GVC 08001
IC601 0IPH486630A IC, PHILIPS, TDA4866/V3 D
IC701 0IPH485000A IC, PHILIPS, TDA4850
IC901 0ISK571700B IC, SANKEN, STR-S5717N LF953 BK SWITCHING REGULATOR
IC902 0IKE780500K IC, KEC, KIA7805PI 3P(TO-220IS) 5V,1A
COILs & COREs
L201 125-155B CORE (CIRC), BEAD, BFS3580R2FG SAMWHA 3.5*8.0MM RADIAL
L401 125-155A CORE (CIRC), BEAD, BFD3510R2FG SAMWHA 3.5*10MM RADIAL
L402 125-155A CORE (CIRC), BEAD, BFD3510R2FG SAMWHA 3.5*10MM RADIAL
L403 125-155A CORE (CIRC), BEAD, BFD3510R2FG SAMWHA 3.5*10MM RADIAL
L701 150-235K COIL,CHOKE, DR8*11 3.5MH 0.2MM 345.5T
L702 150-L05B COIL,LINEARITY, DR14*15 14*5T 12UH 0.12*30MM 25.5T
L704 150-518N COIL,CHOKE, DR14*20 180UH 0.12*25MM 57.5T
L705 125-155J CORE (CIRC), BEAD, BFS2550A0FG SAMWHA 2.5*5.0MM AXIAL52MM
L706 125-155J CORE (CIRC), BEAD, BFS2550A0FG SAMWHA 2.5*5.0MM AXIAL52MM
L707 125-155J CORE (CIRC), BEAD, BFS2550A0FG SAMWHA 2.5*5.0MM AXIAL52MM
L902 150-235F COIL, CHOKE, DR10*10 25UH 0.5MM 23.5T
L903 150-494E FILTER(CIRC), LINE, EE2229 20MH MINH 0.4MM 40T .
L904 150-235C COIL, CHOKE, DR8*11 100UH 0.4MM 53.5T
L905 125-155J CORE (CIRC), BEAD, BFS2550A0FG SAMWHA 2.5*5.0MM AXIAL52MM
TRANSISTORs
Q401 0TR319809AA TRANSISTOR, KTC3198-Y(KTC1815) TP KEC TO92 NPN
Q402 0TR114009AB TRANSISTOR, DTC114ES TP ROHM-K SPT NPN
Q601 0TR320609AB TRANSISTOR, KTC3206-Y(KTC2229) TP KEC TO92L NPN
Q602 0TR114009AB TRANSISTOR, DTC114ES TP ROHM-K SPT NPN
Q701 0TR320709AA TRANSISTOR, KTC3207(KTC2482) TP KEC TO92L NPN
Q702 0TR320709AA TRANSISTOR, KTC3207(KTC2482) TP KEC TO92L NPN
Q704 0TR200009AB TRANSISTOR, KTC200-Y TP KEC TO92 NPN
Q706 0TR514900AA TRANSISTOR, 2SC5149 TOSHIBA
Q709 0TR677000AA TRANSISTOR, BD677 SAMSUNG
Q710 0TR319809AA TRANSISTOR, KTC3198-Y(KTC1815) TP KEC TO92 NPN
Q711 0TR949009BA TRANSISTOR, 2SA949-Y TP TOSHIBA TO92M PNP
Q712 0TR319809AA TRANSISTOR, KTC3198-Y(KTC1815) TP KEC TO92 NPN
Q714 0TR127009AA TRANSISTOR, KTA1270-Y(KTA562TM) TP KEC TO92 PNP
Q715 0TR127009AA TRANSISTOR, KTA1270-Y(KTA562TM) TP KEC TO92 PNP
Q720 0TF630000BA FET, IRFS 630 BK SAMSUNG 200V 5.9A TO220F
Q721 0TF630000BA FET, IRFS 630 BK SAMSUNG 200V 5.9A TO220F
Q777 0TR102409AB TRANSISTOR, KTA1024-Y(KTA949) TP KEC TO92L PNP
Q801 0TR319809AA TRANSISTOR, KTC3198-Y(KTC1815) TP KEC TO92 NPN
Q802 0TR319809AA TRANSISTOR, KTC3198-Y(KTC1815) TP KEC TO92 NPN
Q803 0TR319809AA TRANSISTOR, KTC3198-Y(KTC1815) TP KEC TO92 NPN
Q804 0TR319809AA TRANSISTOR, KTC3198-Y(KTC1815) TP KEC TO92 NPN
Q805 0TR114009AB TRANSISTOR, DTC114ES TP ROHM-K SPT NPN
Q806 0TR319809AA TRANSISTOR, KTC3198-Y(KTC1815) TP KEC TO92 NPN
Q807 0TR174009DA TRANSISTOR, 2SC1740-R TP KEC TO92 NPN
Q808 0TR114009AB TRANSISTOR, DTC114ES TP ROHM-K SPT NPN
Q809 0TR114009AB TRANSISTOR, DTC114ES TP ROHM-K SPT NPN
Q810 0TR114009AB TRANSISTOR, DTC114ES TP ROHM-K SPT NPN
Q811 0TR114009AA TRANSISTOR, DTA114ES TP ROHM-K SPT PNP
Q812 0TR114009AB TRANSISTOR, DTC114ES TP ROHM-K SPT NPN
Q813 0TR114009AB TRANSISTOR, DTC114ES TP ROHM-K SPT NPN
Q901 0TR320609AB TRANSISTOR, KTC3206-Y(KTC2229) TP KEC TO92L NPN
Q902 0TR114009AB TRANSISTOR, DTC114ES TP ROHM-K SPT NPN
- 37 -
MODEL: 1466LRs DATE: 1999. 6. 5.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION REMARK
Q903 0TR320609AB TRANSISTOR, KTC3206-Y(KTC2229) TP KEC TO92L NPN
Q904 0TR320609AB TRANSISTOR, KTC3206-Y(KTC2229) TP KEC TO92L NPN
Q905 0TR183700AA TRANSISTOR, 2SA1837 TOSHIBA
Q908 0TR174009DA TRANSISTOR, 2SC1740-R TP KEC TO92 NPN
Q909 0TR174009DA TRANSISTOR, 2SC1740-R TP KEC TO92 NPN
Q910 0TR127309AA TRANSISTOR, KTA1273-Y(KTA966A) TP KEC TO92L PNP
Q911 0TR207300BA TRANSISTOR, KTC-2073 BK KEC TO220AB NPN
Q912 0TR949009BA TRANSISTOR, 2SA949-Y TP TOSHIBA TO92M PNP
Q913 0TR320609AB TRANSISTOR, KTC3206-Y(KTC2229) TP KEC TO92L NPN
Q914 0TR207300BA TRANSISTOR, KTC-2073 BK KEC TO220AB NPN
Q915 0TR949009BA TRANSISTOR, 2SA949-Y TP TOSHIBA TO92M PNP
Q916 0TR320609AB TRANSISTOR, KTC3206-Y(KTC2229) TP KEC TO92L NPN
Q917 0TR114009AB TRANSISTOR, DTC114ES TP ROHM-K SPT NPN
Q918 0TR174009DA TRANSISTOR, 2SC1740-R TP KEC TO92 NPN
Q919 0TR127309AA TRANSISTOR, KTA1273-Y(KTA966A) TP KEC TO92L PNP
Q920 0TR114009AB TRANSISTOR, DTC114ES TP ROHM-K SPT NPN
Q921 0TR200009AB TRANSISTOR, KTC200-Y TP KEC TO92 NPN
Q922 0TR319809AA TRANSISTOR, KTC3198-Y(KTC1815) TP KEC TO92 NPN
Q923 0TR174009DA TRANSISTOR, 2SC1740-R TP KEC TO92 NPN
Q924 0TR114009AB TRANSISTOR, DTC114ES TP ROHM-K SPT NPN
Q925 0TR114009AB TRANSISTOR, DTC114ES TP ROHM-K SPT NPN
Q926 0TR114009AB TRANSISTOR, DTC114ES TP ROHM-K SPT NPN
RESISTORs
R205 0RD1004F609 RESISTOR, FIXED CARBON FILM, 1.0M 1/6W 5 TA52
R206 0RD3301F609 RESISTOR, FIXED CARBON FILM, 3.3K 1/6W 5 TA52
R207 0RD4701F609 RESISTOR, FIXED CARBON FILM, 4.70K 1/6W 5% TA52
R221 0RD1002F609 RESISTOR, FIXED CARBON FILM, 10K 1/6W 5 TA52
R222 0RD1002F609 RESISTOR, FIXED CARBON FILM, 10K 1/6W 5 TA52
R223 0RD0152H609 RESISTOR, FIXED CARBON FILM, 15 1/2W 5 TA52
R224 971-0016 WIRE, JUMP, TIN HDC 0.60H
R401 0RD1801F609 RESISTOR, FIXED CARBON FILM, 1.8K 1/6W 5 TA52
R402 0RD1002F609 RESISTOR, FIXED CARBON FILM, 10K 1/6W 5 TA52
R403 0RD8201F609 RESISTOR, FIXED CARBON FILM, 8.2K 1/6W 5 TA52
R404 0RD1801F609 RESISTOR, FIXED CARBON FILM, 1.8K 1/6W 5 TA52
R405 0RD4702F609 RESISTOR, FIXED CARBON FILM, 47K 1/6W 5 TA52
R406 0RD1000F609 RESISTOR, FIXED CARBON FILM, 100 1/6W 5 TA52
R407 0RD4701F609 RESISTOR, FIXED CARBON FILM, 4.70K 1/6W 5% TA52
R410 0RD4701F609 RESISTOR, FIXED CARBON FILM, 4.70K 1/6W 5% TA52
R411 0RD3301F609 RESISTOR, FIXED CARBON FILM, 3.3K 1/6W 5 TA52
R412 0RD4701F609 RESISTOR, FIXED CARBON FILM, 4.70K 1/6W 5% TA52
R413 0RD3301F609 RESISTOR, FIXED CARBON FILM, 3.3K 1/6W 5 TA52
R601 0RD1001F609 RESISTOR, FIXED CARBON FILM, 1.0K 1/6W 5 TA52
R602 0RD3900H609 RESISTOR, FIXED CARBON FILM, 390 1/2W 5 TA52
R603 0RD1003F609 RESISTOR, FIXED CARBON FILM, 100K 1/6W 5 TA52
R604 0RD2201F609 RESISTOR, FIXED CARBON FILM, 2.2K 1/6W 5 TA52
R605 0RD0151H609 RESISTOR, FIXED CARBON FILM, 1.5 1/2W 5 TA52
R606 0RD6202F609 RESISTOR, FIXED CARBON FILM, 62K 1/6W 5 TA52
R607 0RD1003F609 RESISTOR, FIXED CARBON FILM, 100K 1/6W 5 TA52
R608 0RD3900H609 RESISTOR, FIXED CARBON FILM, 390 1/2W 5 TA52
R609 0RD1002F609 RESISTOR, FIXED CARBON FILM, 10K 1/6W 5 TA52
R610 0RD1002F609 RESISTOR, FIXED CARBON FILM, 10K 1/6W 5 TA52
R611 0RD1003F609 RESISTOR, FIXED CARBON FILM, 100K 1/6W 5 TA52
R612 0RN0101H609 RESISTOR, FIXED METAL FILM, 1.0 1/2W 5 TA52
R614 0RD1001F609 RESISTOR, FIXED CARBON FILM, 1.0K 1/6W 5 TA52
R615 0RD5602F609 RESISTOR, FIXED CARBON FILM, 56K 1/6W 5 TA52
R621 0RD0102G609 RESISTOR, FIXED CARBON FILM, 10 1/4W 5 TA52
R702 0RD3903F609 RESISTOR, FIXED CARBON FILM, 390K 1/6W 5 TA52
R703 0RD8202F609 RESISTOR, FIXED CARBON FILM, 82K 1/6W 5 TA52
R704 0RD1003F609 RESISTOR, FIXED CARBON FILM, 100K 1/6W 5 TA52
R705 0RD2202F609 RESISTOR, FIXED CARBON FILM, 22K 1/6W 5 TA52
R706 0RD2202F609 RESISTOR, FIXED CARBON FILM, 22K 1/6W 5 TA52
R707 0RD1801F609 RESISTOR, FIXED CARBON FILM, 1.8K 1/6W 5 TA52
R708 0RD1003F609 RESISTOR, FIXED CARBON FILM, 100K 1/6W 5 TA52
R709 0RD5600H609 RESISTOR, FIXED CARBON FILM, 560 1/2W 5 TA52
R712 0RD1501F509 RESISTOR, FIXED CARBON FILM, 1.5K 1/6W 2 TA52
- 38 -
MODEL: 1466LRs DATE: 1999. 6. 5.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION REMARK
R713 0RD0221F609 RESISTOR, FIXED CARBON FILM, 2.2 1/6W 5 TA52
R715 0RD1002F509 RESISTOR, FIXED CARBON FILM, 10K 1/6W 2 TA52
R716 0RD1803F609 RESISTOR, FIXED CARBON FILM, 180K 1/6W 5 TA52
R717 0RD9100F609 RESISTOR, FIXED CARBON FILM, 910 1/6W 5 TA52
R718 0RN0680H609 RESISTOR, FIXED METAL FILM, 0.68 1/2W 5 TA52
R720 0RD0472H609 RESISTOR, FIXED CARBON FILM, 47 1/2W 5 TA52
R721 0RD0472H609 RESISTOR, FIXED CARBON FILM, 47 1/2W 5 TA52
R722 0RD1001F609 RESISTOR, FIXED CARBON FILM, 1.0K 1/6W 5 TA52
R724 0RD6200F609 RESISTOR, FIXED CARBON FILM, 620 1/6W 5 TA52
R725 0RD2201F609 RESISTOR, FIXED CARBON FILM, 2.2K 1/6W 5 TA52
R726 0RD1002F609 RESISTOR, FIXED CARBON FILM, 10K 1/6W 5 TA52
R727 0RD4704F609 RESISTOR, FIXED CARBON FILM, 4.7M 1/6W 5 TA52
R728 0RD2204F609 RESISTOR, FIXED CARBON FILM, 2.2M 1/6W 5 TA52
R729 0RD1002F609 RESISTOR, FIXED CARBON FILM, 10K 1/6W 5 TA52
R730 0RD3901F609 RESISTOR, FIXED CARBON FILM, 3.9K 1/6W 5 TA52
R731 0RD1000F609 RESISTOR, FIXED CARBON FILM, 100 1/6W 5 TA52
R733 0RD3000H609 RESISTOR, FIXED CARBON FILM, 300 1/2W 5 TA52
R734 0RD4702F609 RESISTOR, FIXED CARBON FILM, 47K 1/6W 5 TA52
R735 0RD1503F609 RESISTOR, FIXED CARBON FILM, 150K 1/6W 5 TA52
R736 0RD4702F609 RESISTOR, FIXED CARBON FILM, 47K 1/6W 5 TA52
R737 0RD1503F609 RESISTOR, FIXED CARBON FILM, 150K 1/6W 5 TA52
R742 0RD3302F609 RESISTOR, FIXED CARBON FILM, 33K 1/6W 5% TA52
R743 0RD1502F609 RESISTOR, FIXED CARBON FILM, 15K 1/6W 5 TA52
R744 0RD6802H609 RESISTOR, FIXED CARBON FILM, 68K 1/2W 5 TA52
R746 0RD9100F609 RESISTOR, FIXED CARBON FILM, 910 1/6W 5 TA52
R747 0RD6802G609 RESISTOR, FIXED CARBON FILM, 68K 1/4W 5 TA52
R748 0RD1503F509 RESISTOR, FIXED CARBON FILM, 150K 1/6W 2 TA52
R749 0RD3602F609 RESISTOR, FIXED CARBON FILM, 36K 1/6W 5 TA52
R750 0RD0202H609 RESISTOR, FIXED CARBON FILM, 20 1/2W 5 TA52
R751 0RD0202H609 RESISTOR, FIXED CARBON FILM, 20 1/2W 5 TA52
R752 0RD4303F609 RESISTOR, FIXED CARBON FILM, 430K 1/6W 5 TA52
R753 0RD2702F609 RESISTOR, FIXED CARBON FILM, 27K 1/6W 5 TA52
R754 0RD4702F509 RESISTOR, FIXED CARBON FILM, 47K 1/6W 2% TA52
R755 0RD2201F609 RESISTOR, FIXED CARBON FILM, 2.2K 1/6W 5 TA52
R756 0RD1501F609 RESISTOR, FIXED CARBON FILM, 1.5K 1/6W 5 TA52
R757 0RD1002F609 RESISTOR, FIXED CARBON FILM, 10K 1/6W 5 TA52
R758 0RD2204F609 RESISTOR, FIXED CARBON FILM, 2.2M 1/6W 5 TA52
R760 0RD2202F609 RESISTOR, FIXED CARBON FILM, 22K 1/6W 5 TA52
R761 0RD8200F609 RESISTOR, FIXED CARBON FILM, 820 1/6W 5 TA52
R765 0RD1002F609 RESISTOR, FIXED CARBON FILM, 10K 1/6W 5 TA52
R767 0RD6202F609 RESISTOR, FIXED CARBON FILM, 62K 1/6W 5 TA52
R769 0RD2202F609 RESISTOR, FIXED CARBON FILM, 22K 1/6W 5 TA52
R770 0RD6802F609 RESISTOR, FIXED CARBON FILM, 68K 1/6W 5 TA52
R771 0RD4702F609 RESISTOR, FIXED CARBON FILM, 47K 1/6W 5 TA52
R772 0RD8202F609 RESISTOR, FIXED CARBON FILM, 82K 1/6W 5 TA52
R773 0RD1002F509 RESISTOR, FIXED CARBON FILM, 10K 1/6W 2 TA52
R774 0RD1003F609 RESISTOR, FIXED CARBON FILM, 100K 1/6W 5 TA52
R777 0RD2201F609 RESISTOR, FIXED CARBON FILM, 2.2K 1/6W 5 TA52
R781 0RD1002F609 RESISTOR, FIXED CARBON FILM, 10K 1/6W 5 TA52
R801 0RD1001F609 RESISTOR, FIXED CARBON FILM, 1.0K 1/6W 5 TA52
R802 0RD2001F609 RESISTOR, FIXED CARBON FILM, 2.0K 1/6W 5 TA52
R803 0RD6802F609 RESISTOR, FIXED CARBON FILM, 68K 1/6W 5 TA52
R804 0RD3301F609 RESISTOR, FIXED CARBON FILM, 3.3K 1/6W 5 TA52
R805 0RD1802F609 RESISTOR, FIXED CARBON FILM, 18K 1/6W 5 TA52
R806 0RD2001F609 RESISTOR, FIXED CARBON FILM, 2.0K 1/6W 5 TA52
R807 0RD6802F609 RESISTOR, FIXED CARBON FILM, 68K 1/6W 5 TA52
R809 0RD2201F509 RESISTOR, FIXED CARBON FILM, 2.2K 1/6W 2 TA52
R810 0RD4701F609 RESISTOR, FIXED CARBON FILM, 4.70K 1/6W 5% TA52
R811 0RD1002F609 RESISTOR, FIXED CARBON FILM, 10K 1/6W 5 TA52
R812 0RD2201F609 RESISTOR, FIXED CARBON FILM, 2.2K 1/6W 5 TA52
R813 0RD4701F609 RESISTOR, FIXED CARBON FILM, 4.70K 1/6W 5% TA52
R814 0RD1202F609 RESISTOR, FIXED CARBON FILM, 12K 1/6W 5 TA52
R815 0RD1002F609 RESISTOR, FIXED CARBON FILM, 10K 1/6W 5 TA52
R816 0RD1002F609 RESISTOR, FIXED CARBON FILM, 10K 1/6W 5 TA52
R901 0RD4703H609 RESISTOR, FIXED CARBON FILM, 470K 1/2W 5 TA52
R903 180-142V RESISTOR, CEMENT, 4.7 OHM 5W 5% B RWR
- 39 -
MODEL: 1466LRs DATE: 1999. 6. 5.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION REMARK
R904 0RD4702F609 RESISTOR, FIXED CARBON FILM, 47K 1/6W 5 TA52
R905 0RD0332F609 RESISTOR, FIXED CARBON FILM, 33 1/6W 5 TA52
R906 0RD7502H609 RESISTOR, FIXED CARBON FILM, 75K 1/2W 5 TA52
R907 0RD1801F609 RESISTOR, FIXED CARBON FILM, 1.8K 1/6W 5 TA52
R908 0RD1001F609 RESISTOR, FIXED CARBON FILM, 1.0K 1/6W 5 TA52
R909 0RD1002F609 RESISTOR, FIXED CARBON FILM, 10K 1/6W 5 TA52
R910 0RN0680H609 RESISTOR, FIXED METAL FILM, 0.68 1/2W 5 TA52
R911 0RN0680H609 RESISTOR, FIXED METAL FILM, 0.68 1/2W 5 TA52
R912 0RD2202H609 RESISTOR, FIXED CARBON FILM, 22K 1/2W 5 TA52
R913 0RD2202H609 RESISTOR, FIXED CARBON FILM, 22K 1/2W 5 TA52
R914 0RD0272H609 RESISTOR, FIXED CARBON FILM, 27 1/2W 5 TA52
R915 0RD1803G609 RESISTOR, FIXED CARBON FILM, 180K 1/4W 5 TA52
R916 0RD1502F609 RESISTOR, FIXED CARBON FILM, 15K 1/6W 5 TA52
R917 0RD4700F609 RESISTOR, FIXED CARBON FILM, 470 1/6W 5 TA52
R918 0RS3000J665 RESISTOR, FIX METAL FILM OXIDE, 300 1W 5 SF20
R920 0RD6201F609 RESISTOR, FIXED CARBON FILM, 6.2K 1/6W 5 TA52
R921 0RD3901F609 RESISTOR, FIXED CARBON FILM, 3.9K 1/6W 5 TA52
R922 0RD5603H609 RESISTOR, FIXED CARBON FILM, 560K 1/2W 5 TA52
R923 0RD4701F609 RESISTOR, FIXED CARBON FILM, 4.70K 1/6W 5% TA52
R924 0RD4701F609 RESISTOR, FIXED CARBON FILM, 4.70K 1/6W 5% TA52
R925 0RD6801F609 RESISTOR, FIXED CARBON FILM, 6.8K 1/6W 5 TA52
R926 0RD1002F609 RESISTOR, FIXED CARBON FILM, 10K 1/6W 5 TA52
R927 0RD4701F609 RESISTOR, FIXED CARBON FILM, 4.70K 1/6W 5% TA52
R928 0RD3002H609 RESISTOR, FIXED CARBON FILM, 30K 1/2W 5 TA52
R929 0RD3002H609 RESISTOR, FIXED CARBON FILM, 30K 1/2W 5 TA52
R930 0RD3002H609 RESISTOR, FIXED CARBON FILM, 30K 1/2W 5 TA52
R931 0RD3901H609 RESISTOR, FIXED CARBON FILM, 3.9K 1/2W 5 TA52
R933 0RD8200F609 RESISTOR, FIXED CARBON FILM, 820 1/6W 5 TA52
R934 0RS0822J665 RESISTOR, FIX METAL FILM OXIDE, 82 1W 5 SF20
R935 0RD0201H609 RESISTOR, FIXED CARBON FILM, 2.0 1/2W 5 TA52
R936 0RD8200H609 RESISTOR, FIXED CARBON FILM, 820 1/2W 5 TA52
R937 0RD1201H609 RESISTOR, FIXED CARBON FILM, 1.2K 1/2W 5 TA52
R938 0RD7502H609 RESISTOR, FIXED CARBON FILM, 75K 1/2W 5 TA52
R939 0RD8200F609 RESISTOR, FIXED CARBON FILM, 820 1/6W 5 TA52
R941 0RD7502H609 RESISTOR, FIXED CARBON FILM, 75K 1/2W 5 TA52
R942 0RD1002F609 RESISTOR, FIXED CARBON FILM, 10K 1/6W 5 TA52
R945 0RD2201F609 RESISTOR, FIXED CARBON FILM, 2.2K 1/6W 5 TA52
R946 0RD4700F609 RESISTOR, FIXED CARBON FILM, 470 1/6W 5 TA52
R949 0RD4701F609 RESISTOR, FIXED CARBON FILM, 4.70K 1/6W 5% TA52
R951 0RD0752F609 RESISTOR, FIXED CARBON FILM, 75 1/6W 5% TA
R952 0RD4701F609 RESISTOR, FIXED CARBON FILM, 4.70K 1/6W 5% TA52
R961 0RD1002G609 RESISTOR, FIXED CARBON FILM, 10K 1/4W 5 TA52
R971 0RD4703H609 RESISTOR, FIXED CARBON FILM, 470K 1/2W 5 TA52
R999 0RD1000F609 RESISTOR, FIXED CARBON FILM, 100 1/6W 5 TA52
OTHERs
E2 366-167A WAFER, BW-501S BAEEUN 2.36MM H=14.1MM
F901 131-040C FUSE, TIME LAG, 3150MA 250V 5.2X20 CY/GL UL / CSA LITTELFUSE
F901 430-858C FUSE HOLDER, AFC-520 BAE EUN TA
J61 0RD0562H609 RESISTOR, FIXED CARBON FILM, 56 1/2W 5 TA52
LD901 0DL571300AA LED, "SPR571MVW3 TP ROHM GREEN/RED ""10,10MCD"""
PG1 385-141A METAL, GROUND
RL901 141-039A RELAY, JW2HN-DC12V MATSUSHITA 250VAC 5A 12V 44MA 270 OHM
SW701 140-079C SWITCH,LEVER, SLS-1301 SW NON 30 0 HORIZENTAL 100
SW901 140-069A SWITCH,PUSH, SS-160-3 RONG FENG UNIVERSAL 250 5 , VERTICAL 450
T701 151-269K TRANSFORMER,HORIZONTAL DRIVER, EI19 8MH IRON CORE
T702 6174Z-2001A FBT (FLY BACK TRANSFORMER), FMMPC11,MNT
T901 151-520B TRANSFORMER,SMPS, SMPS,EER4042(NY/JS),CP480
TH901 163-053C THERMISTOR ,PTC, J502P53D140M220 JAHWA +/-20 220Vrms
VR709 180-037N VOLUME, EVN-DCAA03B14 (MEC),10KB
X1 156-010A CRYSTAL, CSA3.58MG000TF,MURATA
VIDEO BOARD
CAPACITORs
C301 0CN2230H949 CAPACITOR, TUBULAR(HIGH DIELEC), 22000P 25V Z FTA52
C302 0CN2230H949 CAPACITOR, TUBULAR(HIGH DIELEC), 22000P 25V Z FTA52
- 40 -
MODEL: 1466LRs DATE: 1999. 6. 5.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION REMARK
C303 0CN2230H949 CAPACITOR, TUBULAR(HIGH DIELEC), 22000P 25V Z FTA52
C304 0CE1066F618 CAPACITOR, AL.ELECTROLYTIC, 0UF SMS 16V M FL TP5
C305 0CK1020W515 CAPACITOR, CERAMIC (HIGH DIELECTRIC), 1000P 500V K B TS
C306 0CN1040K949 CAPACITOR, TUBULAR(HIGH DIELEC), 0.1M 50V Z F TA52
C307 0CN1040K949 CAPACITOR, TUBULAR(HIGH DIELEC), 0.1M 50V Z F TA52
C308 0CE3356K618 CAPACITOR, AL.ELECTROLYTIC, 3.3U SMS 50V M FM5 TP5
C309 0CK1040K945 CAPACITOR, CERAMIC (HIGH DIELECTRIC), 0.1UF 50V Z F TR
C310 0CC1210K415 CAPACITOR, CERAMIC (TEMP. COMPENSATE), 120P 50V J NPO TP
C311 0CC1210K415 CAPACITOR, CERAMIC (TEMP. COMPENSATE), 120P 50V J NPO TP
C312 0CC1210K415 CAPACITOR, CERAMIC (TEMP. COMPENSATE), 120P 50V J NPO TP
C313 0CN1040K949 CAPACITOR, TUBULAR(HIGH DIELEC), 0.1M 50V Z F TA52
C314 0CN1040K949 CAPACITOR, TUBULAR(HIGH DIELEC), 0.1M 50V Z F TA52
C315 0CN1040K949 CAPACITOR, TUBULAR(HIGH DIELEC), 0.1M 50V Z F TA52
C316 0CE2266N618 CAPACITOR, AL.ELECTROLYTIC, 22M SMS 100V M FM5 TP5
C317 0CE2266N618 CAPACITOR, AL.ELECTROLYTIC, 22M SMS 100V M FM5 TP5
C318 0CE2266N618 CAPACITOR, AL.ELECTROLYTIC, 22M SMS 100V M FM5 TP5
C319 0CE106CP618 CAPACITOR, AL.ELECTROLYTIC, 0U SHL 160V M FL TP5
C320 0CE1056N618 CAPACITOR, AL.ELECTROLYTIC, .0M SMS 100V M FM(5) TP(5)
C321 0CN4710K519 CAPACITOR, TUBULAR(HIGH DIELEC), 470P 50V K B TA52
C322 0CE1056N618 CAPACITOR, AL.ELECTROLYTIC, .0M SMS 100V M FM(5) TP(5)
C323 0CE1056N618 CAPACITOR, AL.ELECTROLYTIC, .0M SMS 100V M FM(5) TP(5)
C324 0CE1056N618 CAPACITOR, AL.ELECTROLYTIC, .0M SMS 100V M FM(5) TP(5)
C326 0CK2220W515 CAPACITOR, CERAMIC (HIGH DIELECTRIC), 2200P 500V K B TS
C327 181-502A CAPACITOR, CERAMIC (HIGH DIELECTRIC), CK 1KV 103B E DONG IL
C331 0CC2210K415 CAPACITOR, CERAMIC (TEMP. COMPENSATE), 220P 50V J NPO TP
C332 0CK2220W515 CAPACITOR, CERAMIC (HIGH DIELECTRIC), 2200P 500V K B TS
C333 0CK1040K945 CAPACITOR, CERAMIC (HIGH DIELECTRIC), 0.1UF 50V Z F TR
C334 0CK2220K515 CAPACITOR, CERAMIC (HIGH DIELECTRIC), 2200P 50V K B TS
C335 0CE3366F618 CAPACITOR, AL.ELECTROLYTIC, 33U SMS 16V M FM5 TP5
DIODEs
D309 0DZ820009AH DIODE, ZENER, MTZJ8.2B TP ROHM-K DO34 500MW 8.2V 5MA
D311 0DD400309AE DIODE, SWITCHING, 1N4003 TP ROHM-K DO41 200V 1A 30A 400NS 10UA
D312 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D313 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D314 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D315 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D316 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D317 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
D321 0DZ110009AD DIODE, ZENER, MTZJ11B TP ROHM-K DO34 500MW 11V 5MA
D322 0DD247109AA DIODE, DETECTOR, 1S2471 TP ROHM-K DO35 0.3W
ICs
IC301 0IPH488200A IC, PHILIPS, TDA4882
COILs & COREs
L301 0LR0561K515 INDUCTOR, RADIAL LEAD, 5.6UH +-10%
L302 0LR0221K515 INDUCTOR, RADIAL LEAD, 2.2UH +-10%
L303 0LR0101K515 INDUCTOR, RADIAL LEAD, 1.0UH +-10%
L304 0LR0221K515 INDUCTOR, RADIAL LEAD, 2.2UH +-10%
L305 125-155J CORE (CIRC), BEAD, BFS2550A0FG SAMWHA 2.5*5.0MM AXIAL52MM
L307 125-022J CORE (CIRC), BEAD, FERRITE KQ-1 JS 3.5*5.0MM AXIAL62MM
L308 125-022J CORE (CIRC), BEAD, FERRITE KQ-1 JS 3.5*5.0MM AXIAL62MM
L309 125-022J CORE (CIRC), BEAD, FERRITE KQ-1 JS 3.5*5.0MM AXIAL62MM
L310 125-155B CORE (CIRC), BEAD, BFS3580R2FG SAMWHA 3.5*8.0MM RADIAL
L311 971-0016 WIRE, JUMP, TIN HDC 0.60H
L312 125-155J CORE (CIRC), BEAD, BFS2550A0FG SAMWHA 2.5*5.0MM AXIAL52MM
TRANSISTORs
Q301 0TR350200AA TRANSISTOR, 2SC3502 BK SANYO TO126 NPN
Q302 0TR350200AA TRANSISTOR, 2SC3502 BK SANYO TO126 NPN
Q303 0TR350200AA TRANSISTOR, 2SC3502 BK SANYO TO126 NPN
Q304 0TR756009AA TRANSISTOR, 2SD756A TP HITACHI TO92M NPN
Q305 0TR716009AA TRANSISTOR, 2SB716A TP HITACHI TO92M PNP
- 41 -
MODEL: 1466LRs DATE: 1999. 6. 5.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION REMARK
Q306 0TR756009AA TRANSISTOR, 2SD756A TP HITACHI TO92M NPN
Q307 0TR716009AA TRANSISTOR, 2SB716A TP HITACHI TO92M PNP
Q308 0TR756009AA TRANSISTOR, 2SD756A TP HITACHI TO92M NPN
Q309 0TR716009AA TRANSISTOR, 2SB716A TP HITACHI TO92M PNP
Q310 0TR320709AA TRANSISTOR, KTC3207(KTC2482) TP KEC TO92L NPN
Q311 0TR949009BA TRANSISTOR, 2SA949-Y TP TOSHIBA TO92M PNP
RESISTORs
R302 0RD0752F609 RESISTOR, FIXED CARBON FILM, 75 1/6W 5% TA
R303 0RD0752F609 RESISTOR, FIXED CARBON FILM, 75 1/6W 5% TA
R304 0RD0752F609 RESISTOR, FIXED CARBON FILM, 75 1/6W 5% TA
R306 0RD0332G609 RESISTOR, FIXED CARBON FILM, 33 1/4W 5 TA52
R307 0RD1500H609 RESISTOR, FIXED CARBON FILM, 150 1/2W 5 TA52
R308 0RD6804F609 RESISTOR, FIXED CARBON FILM, 6.8M 1/6W 5 TA52
R309 0RD6804F609 RESISTOR, FIXED CARBON FILM, 6.8M 1/6W 5 TA52
R310 0RD6804F609 RESISTOR, FIXED CARBON FILM, 6.8M 1/6W 5 TA52
R311 0RD1000F609 RESISTOR, FIXED CARBON FILM, 100 1/6W 5 TA52
R312 0RD1000F609 RESISTOR, FIXED CARBON FILM, 100 1/6W 5 TA52
R313 0RD1000F609 RESISTOR, FIXED CARBON FILM, 100 1/6W 5 TA52
R314 0RD1001F609 RESISTOR, FIXED CARBON FILM, 1.0K 1/6W 5 TA52
R315 0RD1001F609 RESISTOR, FIXED CARBON FILM, 1.0K 1/6W 5 TA52
R316 0RD1002F609 RESISTOR, FIXED CARBON FILM, 10K 1/6W 5 TA52
R318 0RD0272F609 RESISTOR, FIXED CARBON FILM, 27 1/6W 5 TA52
R319 0RD0332F609 RESISTOR, FIXED CARBON FILM, 33 1/6W 5 TA52
R320 0RD0272F609 RESISTOR, FIXED CARBON FILM, 27 1/6W 5 TA52
R321 0RD0472F609 RESISTOR, FIXED CARBON FILM, 47 1/6W 5% TA
R322 0RD0272F609 RESISTOR, FIXED CARBON FILM, 27 1/6W 5 TA52
R323 0RD1000F609 RESISTOR, FIXED CARBON FILM, 100 1/6W 5 TA52
R324 0RD1000F609 RESISTOR, FIXED CARBON FILM, 100 1/6W 5 TA52
R325 0RD1000F609 RESISTOR, FIXED CARBON FILM, 100 1/6W 5 TA52
R326 0RD1000F609 RESISTOR, FIXED CARBON FILM, 100 1/6W 5 TA52
R327 0RD2701F609 RESISTOR, FIXED CARBON FILM, 2.7K 1/6W 5 TA52
R328 180-329L RESISTOR, CEMENT, 1K OHM 5W 5% B RSR
R329 0RD2701F609 RESISTOR, FIXED CARBON FILM, 2.7K 1/6W 5 TA52
R330 180-329L RESISTOR, CEMENT, 1K OHM 5W 5% B RSR
R331 0RD2701F609 RESISTOR, FIXED CARBON FILM, 2.7K 1/6W 5 TA52
R332 180-329L RESISTOR, CEMENT, 1K OHM 5W 5% B RSR
R333 0RD4702G609 RESISTOR, FIXED CARBON FILM, 47K 1/4W 5 TA52
R334 0RD5601F609 RESISTOR, FIXED CARBON FILM, 5.6K 1/6W 5 TA52
R335 0RD4702G609 RESISTOR, FIXED CARBON FILM, 47K 1/4W 5 TA52
R336 0RD5601F609 RESISTOR, FIXED CARBON FILM, 5.6K 1/6W 5 TA52
R337 0RD4702G609 RESISTOR, FIXED CARBON FILM, 47K 1/4W 5 TA52
R338 0RD5601F609 RESISTOR, FIXED CARBON FILM, 5.6K 1/6W 5 TA52
R339 0RD1503F609 RESISTOR, FIXED CARBON FILM, 150K 1/6W 5 TA52
R340 0RD1001F609 RESISTOR, FIXED CARBON FILM, 1.0K 1/6W 5 TA52
R341 0RD1801F609 RESISTOR, FIXED CARBON FILM, 1.8K 1/6W 5 TA52
R342 0RD1004F609 RESISTOR, FIXED CARBON FILM, 1.0M 1/6W 5 TA52
R343 0RD1004F609 RESISTOR, FIXED CARBON FILM, 1.0M 1/6W 5 TA52
R344 0RD1004F609 RESISTOR, FIXED CARBON FILM, 1.0M 1/6W 5 TA52
R345 0RD4700F609 RESISTOR, FIXED CARBON FILM, 470 1/6W 5 TA52
R346 0RD4700F609 RESISTOR, FIXED CARBON FILM, 470 1/6W 5 TA52
R349 0RD1000H609 RESISTOR, FIXED CARBON FILM, 100 OHM 1/2 W 5% TA52
R350 0RD1000H609 RESISTOR, FIXED CARBON FILM, 100 OHM 1/2 W 5% TA52
R351 0RD1000H609 RESISTOR, FIXED CARBON FILM, 100 OHM 1/2 W 5% TA52
R352 0RD0332G609 RESISTOR, FIXED CARBON FILM, 33 1/4W 5 TA52
R353 0RD0102F609 RESISTOR, FIXED CARBON FILM, 10 OHM 1/6 W 5% TA52
R354 0RD0102F609 RESISTOR, FIXED CARBON FILM, 10 OHM 1/6 W 5% TA52
R355 0RD4700F609 RESISTOR, FIXED CARBON FILM, 470 1/6W 5 TA52
R356 0RD0102F609 RESISTOR, FIXED CARBON FILM, 10 OHM 1/6 W 5% TA52
R357 0RD5602F609 RESISTOR, FIXED CARBON FILM, 56K 1/6W 5 TA52
R358 0RD2702F609 RESISTOR, FIXED CARBON FILM, 27K 1/6W 5 TA52
R359 0RD3902F609 RESISTOR, FIXED CARBON FILM, 39K 1/6W 5 TA52
R360 0RD0102G609 RESISTOR, FIXED CARBON FILM, 10 1/4W 5 TA52
R361 0RD1002F609 RESISTOR, FIXED CARBON FILM, 10K 1/6W 5 TA52
R362 0RD1001F609 RESISTOR, FIXED CARBON FILM, 1.0K 1/6W 5 TA52
- 42 -
MODEL: 1466LRs DATE: 1999. 6. 5.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION REMARK
R364 0RD7501F609 RESISTOR, FIXED CARBON FILM, 7.5K 1/6W 5 TA52
R365 0RD0392G609 RESISTOR, FIXED CARBON FILM, 39 1/4W 5 TA52
R366 0RD0392G609 RESISTOR, FIXED CARBON FILM, 39 1/4W 5 TA52
R367 0RD0392G609 RESISTOR, FIXED CARBON FILM, 39 1/4W 5 TA52
OTHERs
G2 366-167A WAFER, BW-501S BAEEUN 2.36MM H=14.1MM
J302 0RD0472G609 RESISTOR, FIXED CARBON FILM, 47 1/4W 5 TA52
SG301 165-004A SPARK GAP, AG20PT 152F-L3N/S-23 HANDOK RADIAL BULK
SG302 165-004A SPARK GAP, AG20PT 152F-L3N/S-23 HANDOK RADIAL BULK
SG303 165-004A SPARK GAP, AG20PT 152F-L3N/S-23 HANDOK RADIAL BULK
SG304 165-004A SPARK GAP, AG20PT 152F-L3N/S-23 HANDOK RADIAL BULK
SG305 165-004A SPARK GAP, AG20PT 152F-L3N/S-23 HANDOK RADIAL BULK
VR301 180-037N VOLUME, EVN-DCAA03B14 (MEC),10KB
VR302 180-037N VOLUME, EVN-DCAA03B14 (MEC),10KB
VR303 180-038F VOLUME, EVM-EGS AOOB23
VR304 180-038F VOLUME, EVM-EGS AOOB23
VR305 180-038F VOLUME, EVM-EGS AOOB23
VR306 180-037Q VOLUME, EVN-DCAA03B24 (MEC),20KB
VR307 180-037N VOLUME, EVN-DCAA03B14 (MEC),10KB
MISCELLANEOUS
CDT 2055-10672W CDT SET, M34KWW30XX 20N6LD
CDT EARTH 170-C46J CDT EARTH, CPT EARTH (CH480), CPT EARTH
D/COIL 150-A83A DEGAUSSING COIL, "1230MM 12.4 OHM 0.4MM 70T"14"
P/CORD 6410TWP001A POWER CORD, IS-11+1S14 I-SHENG UNIVERSAL 1560MM PC-OUT IVORY
S/CABLE 6866TA9001E SIGNAL CABLE, AT, 7C ,L1220 ,IVORY(CH480), FOR P201,301I
- 43 -
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
