Image preview - the first page of the document
LG_F-W_Scaler_UpVersion_5.6_[SM]


>> Download LG_F-W_Scaler_UpVersion_5.6_[SM] documenatation <<

Text preview - extract from the document
                               SERVICE BULLETIN
                                                                                                    No. : 0IVL20050008
                                                                                                    Date : 2005-02-15
                   Factory Factory Model Suffix             Model No.            Factory Factory Model Suffix                      Model No.
     Model
                   EKHQ     RT-26LZ50        AMPLKLA RT-26LZ50                   EKHQ        RT-26LZ50             ARPLKPA RT-26LZ50

                   Buyer Name Buyer Code           Buyer Name Buyer Code                    Buyer Name Buyer Code
     Buyer
                   LGEUS          US000001         LGEAI               US000002

EFFECTIVE DATE 2005-02-14                                  EFFECTIVE FROM(SERIAL NO.)                               All range
    Subject        RT-23/26/32LZ50 F/W - SCALER UPVERSION 5.6
                          Before Change                                       After Change
No. Loc No.                                                                                                           Note K-Code Remark
                Part No        DESC./SPEC.                     Part No                 DESC./SPEC.

Reason Of Change
                   RT-23/26/32LZ50          Autobahn Model.

SCALER VERSION upgraded for Picture Quality (5.4->5.6). Adjustment
sequence & PC pattern changed.

Refer to the attached file (Adjustment Spec), except for the RT Commercial Model.




RT232632LZ50_Ver5.6_5646_050207_1250.bin
RT232632LZ50_Ver5.6_5646_050207_1250.hex
RT-23_26_32LZ50.pdf

    ** FILE THIS SERVICE BULLETIN WITH YOUR SERVICE MANUAL
                 NOTE(**) : INTERCHANGEABILITY CODE                                                              KEY-WORD CODE
        Parts                     Set
        Original           Early        Original or new parts may be used in early or late production sets.
                                                                                                              1. To improve performance
    A
                                        Use original parts until exhausted, then stock new parts.             2. To improve productivity
        New                Late

        Original           Early        Original parts may be used in early production sets only.             3. To improve reliability
    B                                   New parts may be used in early or late production sets.
                                        Use original parts where possible, then stock new parts.
        New                Late                                                                               4. Change of material or dimension

        Original           Early        New parts only may be used in early or late production sets.          5. Addition
    C
                                        Stock new parts.
        New                Late                                                                               6. Deletion

        Original           Early        Original parts only may be used in early production sets.             7. Correction
    D                                   New parts may be used in late production sets only.
                                        Stock original and new parts.
        New                Late

                                                                     CHIEF ENGINEER ,
                                                                             Factory.
