1.Retainer SVC Bulletin for 50PQ Series                                                                            -Application Range

 1. Model: 50PQ series Application Module : PDP50G20001.####, PDP50G20324.#### Serial number range 901~906
 2. Symptom: dark bottom half of picture, bottom half unclear picture, bottom half no display
 3. SVC Guide
    -Remove the back cover
  - Insert 12pin retainer for Y Drive boards at connecter pins
 4. If service is for a different type symptom but S/N is in 901~906 range, 12pin retainers need to be inserted during service.




     PDP Module Picture                                                                 Symptom




           Y Drive Top B/D


                             Y SUS B/D               Z SUS B/D




                                                               Z Sub B/D


           Y Drive Bottom B/D




  The People Company                                             1/3                                                 Breakthrough
2.Retainer SVC Guide for 50PQ Series                                              - SVC Guide


                Please see the below SVC guide for Y Drive TOP & Bottom board


                Before                                                   After


                                                                        #1

                                  12pin Retainer (P/N EAG61050702)
                                                                        #2
 YDRV_TOP                         :Required retainer quantity is 6EA



                                                                        #3


                         YSUS



                                                                        #4



 YDRV_BTM
                                                                        #5


                                                                         #6




  The People Company                             2/3                             Breakthrough
2.Retainer SVC Guide for 50PQ Series                                                      - SVC Guide

Push 12pin retainer into place until the latch clicks.
                   YDRV_TOP                                       YDRV_BTM
                                                         Before                     After
        Before                        After



                       Insert 12pin retainer                      Insert 12pin retainer
                       at the pin 1~12 of                         at the pin 1~12 of
                            P109                                       P208


                       Insert 12 pin                              Insert 12 pin
                            retainer                                   retainer
                       at the pin 1~12 of                         at the pin 1~12 of
                            P106                                       P206




                       Insert 12pin retainer                      Insert 12pin retainer
                       at the pin 1~12 of                         at the pin 1~12 of
                            P108                                       P205
