Image preview - the first page of the document



>> Download CS480_7 documenatation <<

Text preview - extract from the document

                                      EXPLODED VIEW
                                (For StudioWorks 44i, CS480)

                                     19
                                                                                      7

         4       20
    23                                                          8
             3
                                                   B


                                     21

                                                            A
                            5
                                             13

                            16                                                                                             EXPLODED VIEW PARTS LIST
                       15                     17
                                                       18
                                                                                          Ref. No.     Part No.                     Description       Q'ty              Material
    2                                                                                                3091TKA001C   CABINET (StudioWorks 44i, CS480)
                                                                                             1                                                         1
                                                                                                     3091TKA002B   CABINET (CS481XX)

                                                                                             2       2055-10672W   CDT, M34KWW30XX                     1

                                                                                             3        150-A29N     DEGAUSSING COIL                     1
                                                                         9
                                                                                             4       6868T14001A   LEAD WIRE, CDT GROUND               1
                                                        14
                      12
                                                                                             5       6174Z-2001D   FBT, FMMPCII                        1

                                                                                             6       4810TKM011A   BRACKET, MAIN                       1
                                8
                                                                                             7       3809TKA001B   BACK COVER                          1

                                                                                             8         332-102F    SCREW, PTP+4` 20BP(MSWR/FZMY)       6

                                                                                             9       3043TKK009B   TILT/SWIVEL                         1

                                                                                            10       4814TKK018A   SHIELD, BOTTOM                      1     SBHG1-A, T0.6
                                                                             6
                                                                                            11       4814TKK019A   SHIELD, MPR                         1     SPTE-C, T0.3

                                                                                 11         12       6871TMH022A   MAIN PCB ASS'Y                      1

                                                                                            13        407-S86A     PLATE, HEAT SINK FOR Q731, Q753     1     AL, T2.0

                                                                     8                      14       4920TKP012A   PLATE, HEAT SINK FOR IC901          1     AL, T1.5

                                                                                            15        407-S87B     PLATE, HEAT SINK FOR IC601          1     AL

                                                                                            16        407-P09A     PLATE, HEAT SINK FOR D741, D742     1
                                22
                                                                                            17        407-T68G     PLATE, HEAT SINK FOR Q704           1     AL

                                                                                            18       4950TKE002A   PLATE, TERMINAL                     1     TERN SHEET, T1.0
1                                                                                           19       4815TKV004B   VIDEO SHIELD                        1     SPTE-C, T0.3
                                                                10
                                                                                            20       4814TKV004A   COVER SHIELD                        1     SPTE-C, T0.3

                                                                                            21        407-S88A     PLATE, HEAT SINK FOR VIDEO          3     TERN SHEET, T1.0

                                                                                            22       4940TKC006B   VOLUME KNOB                         2

                                                                                            23        339-002B     SCREW, PHP+5` 30BP(FZMY)+GW22       4

                                                                                             A       3313T14001A   CHASSIS ASS'Y, MAIN TOTAL           1

                                                                                             B       6871TVH018A   PCB ASS'Y, VIDEO TOTAL              1
