Image preview - the first page of the document



>> Download CS767_3 documenatation <<

Text preview - extract from the document

                                 CONTROL LOCATIONS




                                         2    3              4    5 6 7

                               1



                                                         MAIN



                                              11



                                                   12




                            10                           9         8          FBT



                                         13        VIDEO
                                         14
                                                                  15
                                                                  16


                                                                  17


No.   Ref. No.        Control Function                   No.           Ref. No.           Control Function
1     SW901      POWER SWITCH                                10        VR901        +B ADJUST
2     VR702      CONTRAST                                    11        VR704        SUB-CONTRAST
3     VR201      BRIGHT                                      12        VR703        ABL
4     SW804      DEGAUSSING                                  13        VR301        G-DRIVE
5     SW802      UP                                          14        VR302        R-DRIVE
                                   RECALL
6     SW803      DOWN                                        15        VR303        R-BIAS
7     SW801      SELECT                                      16        VR304        G-BIAS
8     VR501      HIGH VOLTAGE ADJUSTMENT                     17        VR305        SUB-BRIGHT
9     VR701      H-RASTER CENTER



                                                   -5-
