Image preview - the first page of the document



>> Download LG_flatron_w2284f_CHASSIS_LM84DSM documenatation <<

Text preview - extract from the document

                                                                                                   Internal Use Only
                                                                                     Website:http://biz.LGservice.com




                                COLOR MONITOR
                                SERVICE MANUAL
                                CHASSIS NO. : LM 84D
                                MODEL:                              W2284F(W2284F-PFT.K***A**)
                                              (     ) **Same model for Service


                                CAUTION
                                BEFORE SERVICING THE UNIT,
                                READ THE SAFETY PRECAUTIONS IN THIS MANUAL.




Downloaded from www.Manualslib.com manuals search engine
                                                                            CONTENTS
             SPECIFICATIONS ................................................... 2       ADJUSTMENT ...................................................... 13
             PRECAUTIONS ....................................................... 4      TROUBLESHOOTING GUIDE .............................. 15
             TIMING CHART ....................................................... 8
                                                                                        EXPLODED VIEW...................................................19
             DISASSEMBLY ........................................................ 9
             BLOCK DIAGRAM ................................................. 10         REPLACEMENT PARTS LIST ...............................21
             DESCRIPTION OF BLOCK DIAGRAM...................11                          SCHEMATIC DIAGRAM ......................................... 23



                                                                       SPECIFICATIONS
             1. LCD CHARACTERISTICS                                                     4. MAX. RESOLUTION
                Type                 : TFT Color LCD Module                                Analog                      : 1680 x 1050@60Hz
                Active Display Area : 22 inch diagonal                                     Digital                     : 1680 x 1050@60Hz
                Pixel Pitch          : 0.282(H) x 0.282 (V)
                Size                 : 493.7(H) x 320.1(V) x 16.5(D)                    5. POWER SUPPLY
                Color Depth          : 16.7M colors                                        5-1. Power Adaptor(Built-in Power)
                Electrical Interface : LVDS                                                     Input : AC 100-240V~, 50/60Hz, 1.0A
                Surface Treatment    : AG(Haze 25%), Hard Coating(3H)
                Operating Mode       : Normally White                                        5-2. Power Consumption
                Backlight Unit       : 4 CCFL
                                                                                                 MODE       H/V SYNC VIDEO POWER CONSUMPTION LED COLOR
             2. OPTICAL CHARACTERISTICS                                                                                       less than 50 W(max)
                2-1. Viewing Angle by Contrast Ratio 5                                      POWER ON (NORMAL) ON/ON ACTIVE                           BLUE
                                                                                                                              less than 45 W(typ)
               Left : +75
