COLOR MONITOR
SERVICE MANUAL
CHASSIS NO. : LP69G
MODEL:                        M208WA (M208WA-BZH.A**VLP)
           *(   ) **Same model for Service



CAUTION
BEFORE SERVICING THE UNIT,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
                                                             CONTENTS
SPECIFICATIONS ................................................... 2      ADJUSTMENT ...................................................... 17
PRECAUTIONS ....................................................... 8     TROUBLESHOOTING GUIDE .............................. 24
DISASSEMBLY .......................................................12     EXPLODED VIEW...................................................30
BLOCK DIAGRAM ................................................. 14        REPLACEMENT PARTS LIST ...............................32
DESCRIPTION OF BLOCK DIAGRAM...................15                         SCHEMATIC DIAGRAM ..........................................40

                                                       SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement.


1. Application range                                                      3. Test method
       This specification is applied to 20" Wide Monitor TV used
       LP69G chassis.                                                          3.1 Performance : LGE test method followed
                                                                               3.2 Demanded other specification
2. Requirement for Test                                                             Safety : CE, IEC Specification
                                                                                    EMC : CE, IEC
       Each part is tested as below without special appointment.

       (1) Power Voltage : Standard input voltage (100~240V@,
                           50/60Hz)
          *Standard Voltage of each products is marked by models.
       (2) Specification and performance of each parts are followed
           each drawing and specification by part number in
           accordance with BOM.
       (3) The receiver must be operated for about 20 minutes prior
           to the adjustment.


4. General Specification(TV)
4-1. General Specification
    4.1.1 TV
  No                      Item                                      Specification                                    Remark
   1      Video input applicable system        PAL-D/K, B/G, I, SECAM L, NTSC, NTSC 4.43
   2      Receivable Broadcasting System       PAL/SECAM BG                                       (BZH/BTH)
                                               PAL/SECAM DK                                       EU/Non-EU
                                               PAL I                                              (PAL Market)
                                               SECAM L/L'
   3      RF Input Channel                     VHF     : E2 ~ E12
                                               UHF     : E21 ~ E69                                PAL
                                               CATV : S1 ~ S20
                                               HYPER : S21~ S41
                                               L/L' : B, C, D                                     FRANCE
   4      Input Voltage                        100-240V~, 50Hz/60Hz
   5      Market                               EU
   6      Tuning System                        FVS 100 program                                    PAL, 200 PR.(Option)
                                               FS                                                 NTSC
   7      Operating Environment                Temp : 10
