EXPLODED VIEW
1.CABINET
Ref. No. Part No. Description
1 3858SEX012A YBAP-14150-ZZ4 01 LABEL-DISC
2 3720SEP015A MLAF-03160-ZZ2 04 PANEL-FRONT(AL)
3 5040SE0083A MRAG-12980-004 FOOT-RUBBER(F)
4 3720SEM010A MJAF-07910-ZZ3 01 PANEL-DECO
5 3720SEM007A MJAF-06010-ZZ1 04 PANEL-SUB
6 4940SE9967A MJAF-07950-ZZ3 03 KNOB-SKIP
7 5040S-0004A MMTC-00752-003 RUBBER-CUSHION
8 4910S-0001C MJAG-12861-004 GEAR-DAMPER
9 327-118A AMAF-16010-ZZ4 01 CLAMPER-ASS'Y
10 3580SEC001A MJAF-03170-ZZ2 01 DOOR-CD
11 3790SEM030A MAAF-07940-ZZ3 01 WINDOW-CD
12 3090SEM002A MJAF-06020-ZZ1 01 CABINET-TOP
13 4940SE9969A MJAG-12850-004 KNOB-EJECT
14 4940SE9968A MJAF-16000-ZZ4 01 KNOB-OPEN
15 4970SEN029A MMAC-16050-004 SPRING-DOOR
16 4980SE0002A MJAG-02894-004 SUPPORT-PCB
17 3140SEP014A MPAC-04670-002 CHASSIS-BOTTOM
18 265-013B MRAG-12880-004 RUBBER-FOOT(B)
19 3140SEP016B MPAC-04730-ZZ3 CHASSIS-BACK (LG)
20 353-100A MMTC-00752-003 SCREW-WASHER
21 353-052S PHWT2T 3 x 8 Fe-ZY SCREW-TAPPING
22 353-025F BHT2T 3 x 8 Fe-ZY SCREW-TAPTITE
23 353-025G BHT2T 3 x 10 Fe-ZY SCREW-TAPTITE
24 353-025T FHT2T 3 x 10 Fe-ZY SCREW-TAPTITE
25 353-025C BHT2T 3 x 10 Fe-ZB SCREW-TAPTITE
1
2.CD MECHANISM (CMS-B31TG6)
Ref. No. Part No. Description
- 6717SCP001A CD CMS-B31TG6
2 6756S-O001A MOTOR
4 6756S-G001A GEAR
6 6756S-T001A SWITCH
9 6756S-X001A PICK-UP
