Image preview - the first page of the document
>> Download fx4explod 3 documenatation <<
Text preview - extract from the document
DECK MECHANISM
Serviceable Parts List
AB1504 AB1505
Ref. No. Part No. Description
AB15 6730S-F003A Deck Mechanism ASS'Y
AB1501 6768S-AP02C ARM SW (50-239-4027)
AB1501 AB1506 AB1502 6768S-AP02B ARM CS (50-239-4026)
AB1502
AB1507 AB1503 6768S-BP04C BELT BF (02-084-4161)
AB1503 AB1504 6768S-BP04A BELT BFR (02-083-4165)
AB1508 AB1505 6768S-OP01B MOTOR ASS'Y (50-093-4130)
AB1506 6768S-GP02A CLUTCH ASS'Y (50-093-4069)
AB1509
AB1507 6768S-VP01A BOBBIN ASS'Y (50-093-4125)
AB1508 6768S-MP02A BOX SW (50-219-4028)
AB1509 6768S-SP02A SPRING SW (01-082-4646)
AB1510 6768S-AP02A ARM TRIGGER (50-268-3016)
AB1511 6768S-HP03B P HEAD (TC231F)
AB1512 6768S-HP03A R/P HEAD (TC881CB067B)
AB1513 6768S-AP02A SPRING (01-080-4635)
AB1510 AB1514 6768S-XP01B PHOTO INTERRUPTER (SG211V)
AB1515 6768S-TP01B MODE SW (MSW17220 MVQ0)
AB1513
AB1514
AB1511 AB1515
AB1512
- 3-
