Image preview - the first page of the document
>> Download FR-X1A-EXP documenatation <<
Text preview - extract from the document
EXPLODED VIEW
Ref. No. Part No. Description
1 *3720SEM006B MJAF-06000-ZZ1 PANEL-SUB (LG)
2 3090SEM001A MJAF-05990-ZZ1 01 CABINET-TOP
3 3720SEM009A MJAF-07910-ZZ3 01 PANEL-DECO
4 3790SEM029A MJAF-15990-ZZ4 01 WINDOW-LCD
5 4940SE9964A MJAF-07920-ZZ3 03 KNOB-FUNCTION
6 4940SE9966A MJAF-07931-ZZ3 01 KNOB-VOLUME
7 4940SE9965A MJAF-07930-ZZ3 01 KNOB-POWER
8 3720SEP014A MLAF-03151-ZZ2 04 PANEL-FRONT(AL)
9 4930SE0233A MJAF-01710-003 HOLDER-LCD
10 3858SEP001A MAAF-15980-ZZ4 01 FILTER-LCD
11 5040SE0083A MRAG-12980-004 RUBBER-FOOT(F)
12 265-013B MRAG-12880-004 FOOT-RUBBER(B)
13 324-080A MJAG-12890-004 HOLDER-PCB
14 *3140SEP015B MPAC-04720-ZZ3 CHASSIS-BACK(LG)
15 3140SEP013A MPAC-04660-002 CHASSIS-BOTTOM
16 4810SE0738A MPAC-16070-004 BRACKET-CONN.
17 4920SEP001A MLAC-16040-004 RADIATOR
18 4920S-ES02C MEAC-15850-004 RADIATOR-TR
19 4850SE0080A MRAG-12970-004 CUSHION-PCB
20 353-025T FHT2T 3x10 Fe-ZY SCREW-TAPPING
21 353-025E BHT2T 3x6 Fe-ZY SCREW-TAPPING
22 353-025F BHT2T 3x8 Fe-ZY SCREW-TAPPING
23 353-052S PHW2T 3x8 Fe-ZY SCREW-TAPPING
24 353-025G BHT2T 3x10 Fe-ZY SCREW-TAPPING
25 353-025R BHT2T 3x18 Fe-ZY SCREW-TAPPING
26 353-633A BHT3T 4x8 Fe-ZB SCREW-TAPPING
27 353-025C BHT2T 3x10 Fe-ZB SCREW-TAPPING
28 353-100A MMTC-00752-003 SCREW-TAPPING
33 *6410SEE301A KDAC-0500F-3AB POWER-CORD (LG)
34 6170SEF01ZY PTAG-03370-Y4K POWER-TRANS
35 6304SET003B DPLC-00480-00L LCD
*: Refer to the SPPL(Service Parts Price List.)
