Image preview - the first page of the document
>> Download Training LCD ML012_ML024_ML027_ML041B_D_MF02HA_ML038A_B_C documenatation <<Text preview - extract from the document ide
Wo rld w TV
LCD
Welcome to
LCD TV
(PAL & NTSC Chassis with LCD screen !)
CIS
Europe
N.America
China
Middle-East
Asia
Africa
S.America
Oceania
iGsnGGiG{ 1 LG DID ENGINEERING DEPT.
ide
CONTENTS Wo rld w TV
LCD
LCD TV CHASSIS APPLICATION NOTE
1. TV COLOR SYSTEM
2. TV SOUND SYSTEM
3. Special feature
-SCART
-V-CHIP
-CAPTION
-TELETEXT
-Etc..
4. ADJUSTMENT & OPTION TABLE
5. MODEL NAME DONATION
6. GENERAL SPEC.
7. Chassis SPEC.
8. BLOCK DIAGRAM
iGsnGGiG{ 2 LG DID ENGINEERING DEPT.
ide
TV Color System Wo rld w TV
LCD
NTSC(National Television System Committee)
`Developed in USA, on 1953
` Video signal(R,G,B) from Camera is converted to Y,I,Q signal.
` Y Signal : Luminance signal Video R Y
Y=0.30R+0.59G+0.11B signals
` I Signal: Chrominance Signal(I=0.60R-0.28G-0.32B) from G Matrix I
`Q Signal: 90
