Image preview - the first page of the document
>> Download hfe_philips_dvd620_623_633_service documenatation <<
Text preview - extract from the document
DVD-Video Player DVD620-623-633
DVD620 /001 /021 /051
DVD623 /001 /021 /051
DVD633 /001 /021 /051
CL 16532162_000.eps
070102
Contents Page
1 Technical Specs and Connection Facilities 2
2 Safety Instructions, Warnings, Notes,
and Service Hints 3
3 Directions for Use 6
4 Mechanical- and Dismantling Instructions 16
5 Diagnostic Software, Trouble Shooting and Test
Instructions 18
6 Wiring-, Block Diagrams
Block Diagram 37
Wiring Diagram 38
7 Electrical Diagrams and Print-Layouts Diagram PWB
Power Supply Unit 39 40
AV Board: Video & SCART (Diagram A1) 41 45-51
AV Board: Audio (Diagram A2) 42 45-51
AV Board: Front (Diagram A3) 43 45-51
AV Board: Regulated Supply (Diagram A4) 44 45-51
Front Controls (Diagram C) 52 52
Front Standby-On (Diagram S) 52 52
8 Alignments (Not Applicable)
53
9 Circuit-, IC Descriptions, and 53
List of Abbreviations 56
10 Spare Parts List 58
Published by MW 0261 Service PaCE Printed in the Netherlands Subject to modification EN 3122 785 12210
EN 2 1. DVD 620 /0X1 Technical Specifications & Connection Facilities
1. Technical Specifications & Connection Facilities
Specifications
PLAYBACK SYSTEM AUDIO PERFORMANCE
DVD Video DA Converter 24 bits
Video CD & SVCD DVD fs 96 kHz 4 Hz - 22 kHz
CD (CD-Recordable and CD-Rewritable) fs 48 kHz 4 Hz - 22 kHz
CD/VCD fs 44.1 kHz 4 Hz - 20 kHz
TV STANDARD (PAL/50Hz) (NTSC/60Hz) SVCD fs 48 kHz 4 Hz - 22 kHz
Number of lines 625 525 fs 44.1 kHz 4 Hz - 20 kHz
Playback Multistandard (PAL/NTSC) Signal-Noise (1kHz) 110 dB
Dynamic Range (1kHz) 95 dB
VIDEO PERFORMANCE Crosstalk (1kHz) 110 dB
Distortion and Noise (1kHz) 90 dB
Video output 1 Vpp into 75 ohm
RGB (SCART) output 0.7 Vpp into 75 ohm
Black Level Shift On/Off CONNECTIONS
Video Shift Left/Right SCART Euroconnector
Video Output Cinch (yellow)
AUDIO FORMAT Audio L+R output Cinch (white/red)
Digital Output 1 coaxial
Digital MPEG Compressed
IEC958 for CDDA / LPCM
Digital
IEC1937 for MPEG1/2 / Dolby
Dolby Digital 16, 20, 24 bits
Digital
PCM fs, 44.1, 48 kHz
Analogue Stereo Sound
Dolby Surround-compatible downmix from Dolby Digital CABINET
multi-channel sound Dimensions (w x h x d) 435 x 75 x 210.5 mm
3D Sound for virtual 5.1 channel sound on 2 speakers Weight Approximately 1.9 Kg
* typical playing time for movie with 2 spoken languages and
3 subtitle languages
Specifications subject to change without prior notice
Maintenance
Cleaning the Cabinet Cleaning the disc lens
