Image preview - the first page of the document
>> Download dvp-530-78_612 documenatation <<
Text preview - extract from the document
DVD Player General
A04 - 150
Service
Service
Service Product Service Group BG HENT
Service Information
Already published Service Informations:
Spare parts code no. for Service Category 1 & Over-the-
Counter Exchange sets:
This publication gives a survey of service spare parts for those
typenumbers for which no service manual has been published.
2004 - 04 - 15 3139 785 30700
REMOTE
MODEL CONTROL AUDIO CABLE VIDEO CABLE SCART CABLE MAINS CABLE MISCELLANEOUS
DVP520 3141 017 90220 9965 000 22497 9965 000 22495 9965 000 23298 /00/02 9965 000 20422 Fuse T2A 250V
9965 000 23299 /05
DVP522 3141 017 90220 9965 000 22497 9965 000 22495 9965 000 23298 /69 9965 000 20422 Fuse T2A 250V
DVP530 3141 017 90220 9965 000 22497 9965 000 22495 9965 000 23298 /03/69/78 9965 000 20422 Fuse T2A 250V
9965 000 23299 /05
9965 000 23517 /13
9965 000 23404 /75
DVP530K 3141 017 90180 9965 000 22497 9965 000 22495 9965 000 23406 /93 9965 000 20422 Fuse T2A 250V
9965 000 23403 Karaoke Knob
DVP532K 3141 017 90180 9965 000 22497 9965 000 22495 9965 000 23298 /03/69/78 9965 000 20422 Fuse T2A 250V
9965 000 23517 /13 9965 000 23403 Karaoke Knob
9965 000 23404 /75
2
9965 000 23406 /93
DVP533K 3141 017 90180 9965 000 22497 9965 000 22495 9965 000 23519 /78 9965 000 20422 Fuse T2A 250V
9965 000 23403 Karaoke Knob
DVP534K 3141 017 90180 9965 000 22497 9965 000 22495 9965 000 23298 /03/69 9965 000 20422 Fuse T2A 250V
9965 000 23517 /13 9965 000 23403 Karaoke Knob
9965 000 23404 /75
9965 000 23406 /93
MDV458 3141 017 90341 9965 000 22497 9965 000 22495 9965 000 23519 /17 9965 000 20422 Fuse T2A 250V
MDV560VR 9965 000 23708 9965 000 23711 9965 000 23710 9965 000 23706 /17 9965 000 23712 Fuse T1.6A 250V
9965 000 23707 /17 (alternative) 9965 000 23709 RF Cable
