Image preview - the first page of the document



>> Download HD785460_ET-SB-EX-SI_1384519990 documenatation <<

Text preview - extract from the document

                                                                Coffee Maker Senseo "Latte Select"
                                                                                                                               HD7854/60
                                                                                                                               HD7854/69




   Philips Consumer Lifestyle




  Service Manual
   PRODUCT INFORMATION
   - This product meets the requirements regarding                                     - Standby power (switched off )   : 1 W
     interference suppression on radio and TV.                                         - Standby power                   :  30 W
   - After the product has been repaired, it should function                             (switched on 30 min)              (room temperature)
     properly and has to meet the safety requirements as                               - Pressure Coffee system          :  1.6Bar
     officially laid down at this moment.                                              - Pressure Steam system           :  1 Bar
                                                                                       - Contents water reservoir        : 1200 cc/mL
   TECHNICAL INFORMATION                                                               - Contents milk reservoir         : 120 cc/mL
   - Voltage                              :   220 - 240 V                              - Auto shut off                   : 30 min
   - Frequency                            :   50 - 60 Hz                               - Variable Coffee volume          : Min, Normal and Max
   - Power consumption                    :   2650 W                                                                       (see Table)
             Boiler                       :   1450 W                                   - Colour setting                  : Deep Black
             Steam heater                 :   1200 W                                   - Sap coding                      : HD7854/60


                                                           Coffee volume overview



                                              Min cc/mL         Normal cc/mL            Max cc/mL
                    France version               60                   100                  140
                    General version              60                   125                  145

                       Coffee/Milk                                                        Indication temperature for chosen Coffee/Milk receipe
                                          Volume (cc)              Weight (g)
                         receipe                                                               very depended from milk inlet temperature.
                                                cc           max. (g)       min. (g)                              (
