Image preview - the first page of the document



>> Download philips_hd7850_hd7860_[ET] documenatation <<

Text preview - extract from the document

                                                              Coffee Maker Senseo "Latte Select"
                                                                                                                            HD7850/60




   Philips Consumer Lifestyle




  Service Manual
   PRODUCT INFORMATION
   - This product meets the requirements regarding
     interference suppression on radio and TV.                                                                     Coffee volume overview

   - After the product has been repaired, it should function
     properly and has to meet the safety requirements as
                                                                                                       Min cc/mL       Normal cc/mL       Max cc/mL
     officially laid down at this moment.
                                                                                 France version            80               100               140

   TECHNICAL INFORMATION                                                         General version           80               122               145

   - Voltage                              :   220 - 240 V                                                               Indication temperature for
   - Frequency                            :   50 - 60 Hz                          Coffee/Milk receipe volume           chosen Coffee/Milk receipe,
   - Power consumption                    :   2650 W                                  all versions cc/mL              very depended from milk inlet
              Boiler                      :   1450 W                                                                        temperature. (
