Image preview - the first page of the document
>> Download philips_saeco_hd8423_hd8425_hd8427 documenatation <<
Text preview - extract from the document
Coffee Machine
HD8423
Service HD8425
HD8427
Service
Service
Exploded View
Contents Table
External / Front panel / 1/2
Water system 2/2
All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system or transmitted, in any form or by any means, electronic, mechanical,
photocopying, or otherwise without the prior permission of Saeco.
Published by Saeco International Group Subject to modification EN 421940000019.0
2012-Dic-04
Exp. E71093 Rev.00-04/12/12
25 60 59 38 48
22 45 7
48 48
26 31
20
23 19
18 21
17 35
16 58
51
15 24 3
14 40
13 41
33
11 33 1
12 10
52
2 33
48
9 52 8 5
47 6
47 30 36
39
4
53 42 29 34
54 55 32
56
46
28
57
43 44 49
47 47
50
27 27 50
37 47 27
HD8423/01-09 HD8425/01-09 Cod. 10004290-4291-4292-4293
HD8427/01-09 10004295-4296
POS CODE 12NC DESCRIPTION NOTE POS CODE 12NC DESCRIPTION NOTE
01 11026897 996530067997 CHROM.WATER-STEAM KNOB S/SCR.ABC ASSY. 37 13001366 996530067995 DISPLAY BOX ABC/M PSA POEMIA CLASS WE
02 11026901 996530068005 AS.MANOPOLA COMANDI.ABC CROM. 13001367 996530067982 DISPLAY BOX ABC/B PSA POEMIA FOCUS WE
03 11024799 996530068001 TRANSP.WATER CONTAINER S/SCR.ABC ASSY. 13001431 996530068653 DISPLAY BOX ABC/B PSA POEMIA FOCUS CEE
04 147660562 996530016894 GREY PISTON FOR WATER CONTAINER VALVE 13001432 996530068658 DISPLAY BOX ABC/M PSA POEMIA CLASS CEE
05 140324362 996530013507 OR ORM 0060-30 SILICONE 13001452 996530069919 DISPLAY BOX ABC/T PSA POEMIA TOP WE
06 126764718 996530011626 SS WATER CONTAINER VALVE SPRING 13001453 996530069922 DISPLAY BOX ABC/T PSA POEMIA TOP CEE
07 11024822 996530067981 BLACK HANDLE WATER CONTAINER ABC 38 11029997 996530073024 BLACK SB BOARD SUPPORT COVER ABC.
08 11026909 996530068007 CHROM/BLK FRONT PANEL S/SCR.ABC/B ASSY. FOCUS 39 11024828 996530067992 SS GRATE FOR DRIP TRAY ABC/M-T CLASS - TOP
11025458 996530068006 CHROM/SS FRONT PANEL S/SCR.ABC/M-T ASSY. CLASS - TOP 40 11024301 996530067434 ADHES.SILVER PLATE LOGO PHILIPS CLASS - TOP
09 11026924 996530067961 BLACK ALUM. PRES.FILTERHOLDER ABC ASSY. 41 11011406 996530006054 ADHES.SILVER PLATE LOGO SAECO P0057 CLASS - TOP
10 123591309 996530011272 BRASS SPACER FOR PRES.FILTERHOLDER 42 15003441 996530073036 MANUAL PSA POEMIA SB ABC 12L.WE
11 129730721 996530013032 TCB SCREW PZ/SW 4X12 UNI 8112 SS 15003442 996530073043 MANUAL PSA POEMIA SB ABC 12L.CEE
12 11025501 996530067966 BLACK PRES.FILTERHOLDER HANDLE ABC 43 11024827 996530067962 BLACK DRIP TRAY ABC/B-M FOCUS CLASS
13 11025502 996530067996 CHROM FILTERHOLDER HANDLE CAP ABC 11027795 996530069923 SS/SILVER DRIP TRAY ABC/T ASSY TOP
14 126769918 996530011684 SS SPRING FOR PRES.FILTERHOLDER PIN L=13 44 11029994 996530072996 STEEL CASING BOTTOM V2 ABC
15 126768418 996530011667 SS.SPRING FOR CAM PRESS.FILTERHOLDER 45 11025503 996530067983 BLACK GROUND COFFEE MEASURE ABC
16 229181800 996530031265 GREY PRES.FILTERHOLDER PIN SUPPORT ASSY. 46 13001377 996530068003 CARTON LOWER INSERT BOX ABC
17 126835818 996530011811 SS.SPRING FILTERHOLD.HAND.PRES/MEC. 47 129912504 996530013147 SCREW TCBR TORX 10 3,5X14 PLAST.ZN-N
18 17000097 996530009582 ALUM/POL.V2 PRES/MECC.FILTERHOLDER 48 129913902 996530013164 SCREW TCB TORX 10 3X12 PLAST.ZN-B
19 145847762 996530015878 BROWN PRESS.FILTERHOLDER CONVEYOR SEAL 49 148600600 996530017451 BLACK POWER CABLE CLAMP MAGIC ESP/COM.
20 142862959 996530015136 GREY CONVEYOR HOLE 1,7 PRES.FILTERHOLDER 50 12000450 996530007819 SCREW TCBR TORX 10 3,5X12 PLAST.ZN-N
21 0701.031.150 996530044417 GREY WATER VALVE GACO DIM 14 SEAL COVER 51 145842900 996530015823 NBR WATER CONT.VALVE GACO DIM14 SEAL
22 124650221 996530011332 2CUP FILTER 54,5X25 W/O.NOT.HOLE D=48 52 DM0814 996530054358 STEEL SPRING FOR KNOB TYMER
23 20007036 996530069505 SPARES KIT POD FILTER + SPRING ABC 53 13001520 996530070487 CARTON UPPER INSERT BOX ABC
24 11029993 996530073039 BLACK CASING V2 ABC FOCUS - CLASS 54 13001497 996530070505 CARTON CENTRAL INSERT BOX ABC
11030377 996530073041 SS/SILVER CASING V2 ABC/T ASSY. TOP 55 13001496 996530070503 CARTON FILTERHOLDER PROTECT.INSERT ABC
25 11024798 996530067998 BLACK WATER CONTAINER LID ABC/B-M. FOCUS - CLASS 56 13001514 996530070493 TRANSP.HANDLE FOR DISPLAY BOX ABC
11027797 996530069918 SS/GREY WATER CONTAINER LID ABC/T ASSY TOP 57 13001515 996530070495 DISPLAY BOX HANDLE REINFORCEMENT ABC
26 11024829 996530067988 BLACK CASING COVER ABC/B-M FOCUS 58 11029644 996530070492 NOMEX PROTECTION FOR ROTARY SWITCH ABC
11027796 996530069921 SS/GREY CASING COVER ABC/T ASSY. TOP 59 11028902 996530072995 CPU+SW ECO-SWITCH RELE DRIV.KBO 230V ASS
11029357 996530070496 SS/BLACK CASING COVER ABC/M ASSY. CLASS 60 11029996 996530073001 BLK SB BOARD SUPPORT ABC
27 147623750 996530016889 BLACK ROUND FOOT
28 11001769 996530001012 BLACK PANNARELLO COVER P0049 FOCUS
11001621 996530000926 SS PANNARELLO COVER P0049 CLASS - TOP
29 11001620 996530000925 BLACK PANNARELLO INNER TUBE P0049
30 11007194 996530004127 BLACK STEAM TUBE HANDGRIP G0053
31 11025662 996530067977 GUARN.H=11,3 60SH PORTAF.PRES.MEC/CAL.IN
32 17800167 996530068652 BLACK POWER CABLE SCHUKO L=1550
33 11026889 996530067957 GREEN NEON LAMP ABC
34 11028459 996530070502 BLACK REAR LOWER CASING COVER ABC FOCUS - CLASS
11029464 996530072955 GREY REAR LOWER CASING COVER ABC TOP
35 12001755 996530073037 ROTARY SWITCH R11CX1200 ABC
36 12001819 996530073042 BLACK ON-OFF BIPOLAR SWITCH KBO
PSA POEMIA SB TABLE 1/2
Exp. E71093 Rev.00-04/12/12
33
29 30 29
40 2
28 28 1
32 27 4
37
31 3
26 5
45
21
25 35
38
35 22
24 21
23
15 48
14 16 41 44
20 19
18
18
36
17
13
39 34
12 43
43
11
10 42 44
9
8
6
6
7 6 39
46
47
39
HD8423/01-09 HD8425/01-09 Cod. 10004290-4291-4292-4293
HD8427/01-09 10004295-4296
POS CODE 12NC DESCRIPTION NOTE POS CODE 12NC DESCRIPTION NOTE
01 17000512 996530067964 L-F/BRASS V2 STEAM FAUCET ABC ASSY. 44 149205850 996530018056 BLACK TYPE ULKA PUMP W/BEVEL SUPPORT
02 9011.144 996530048885 SS FORK FOR TUBE D=4 45 126764018 996530011619 SS SPRING D=1 STEAM TUBE HOLDER JUN.
03 11025139 996530067991 L-F/BRASS STEAM FAUCET FOR SS BOILER ABC 46 11007493 996530004363 T CONNECTOR FOR BOILER P604
04 WGADM0041/031 996530063888 OR 2018 VITON 70 SH 47 147920150 996530017348 90◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
